Configurable Customer Control System Pontiac G6 I final

Scheme 1

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

Diagnostic Instructions

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

Circuit/System Description

The radio supplies voltage to the audio steering wheel control switches and monitors the return signal. Each switch state is associated to a set resistance value and when pressed a specific voltage drop occurs across the resistor unique to the switch. The radio identifies the switch selection and activates the feature.

Conditions for Running the DTC

1. Battery voltage is between 9-16 volts
2. The ignition is ON.

Conditions for Setting the DTC

The radio detects a short to voltage in the steering wheel control signal circuit.

Action Taken When the DTC Sets

The steering wheel control switch functions are inoperative.

Conditions for Clearing the DTC

1. The conditions for setting the DTC are no longer present.
2. A history DTC clears after 100 malfunction-free ignition cycles.

Diagnostic Aids

Before diagnosis of the steering wheel controls, ensure the primary controls of the associated component are functioning properly.

Reference Information

Schematic Reference

1. «Steering Wheel Secondary/Configurable Control Schematics»(/pontiac/g6/i-final-2010-2010/remont/memory-modules/#configurable-customer-control-system)
2. «Radio/Navigation System Schematics»(/pontiac/g6/i-final-2010-2010/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems)

Connector End View Reference

Component Connector End Views

Description and Operation

Steering Wheel Controls Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

Ensure the primary controls of the associated component are functioning properly.

Circuit/System Testing

1. Ignition OFF, disconnect the harness connector at the right steering wheel control switch.
2. Ignition ON, radio ON, test for 9.2-10.2 volts between the voltage reference circuit terminal 2 and ground. If less than the specified range, test the voltage reference circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the radio. If greater than the specified range, test the voltage reference circuit for a short to voltage. If the circuit tests normal, replace the radio.
3. Test for 9.2-10.2 volts between the voltage reference circuit terminal 2 and the signal circuit terminal 4. If less than the specified range, test the signal circuit for an open/high resistance. If the circuit tests normal, replace the radio. If greater than the specified range, test the signal circuit for a short to voltage. If the circuit tests normal, replace the radio.
4. Ignition OFF, disconnect the X1 harness connector at the radio.
5. Test for infinite resistance between the signal circuit terminal 4 and ground. If less than the specified value, test the signal circuit for a short to ground.
6. If all circuits test normal, test or replace the right steering wheel control switch.

Component Testing

1. Disconnect the harness connector at the right steering wheel control switch.
2. Connect a DMM between terminals 2 and 4 of the right steering wheel control switch. If not within the specified ranges, replace the right steering wheel control switch.

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Steering Wheel Control Switch Assembly Replacement (Cruise Control and Radio Switch)»(/pontiac/g6/i-final-2010-2010/remont/memory-modules/#configurable-customer-control-system)
2. «Control Module References»(/pontiac/g6/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for radio replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The radio supplies voltage to the audio steering wheel control switches and monitors the return signal. Each switch state is associated to a set resistance value and when pressed a specific voltage drop occurs across the resistor unique to the switch. The radio identifies the switch selection and activates the feature.

1. Battery voltage is between 9-16 volts
2. The ignition is ON.

The radio detects a short to voltage in the steering wheel control signal circuit.

The steering wheel control switch functions are inoperative.

1. The conditions for setting the DTC are no longer present.
2. A history DTC clears after 100 malfunction-free ignition cycles.

Before diagnosis of the steering wheel controls, ensure the primary controls of the associated component are functioning properly.

Schematic Reference

1. «Steering Wheel Secondary/Configurable Control Schematics»(/pontiac/g6/i-final-2010-2010/remont/memory-modules/#configurable-customer-control-system)
2. «Radio/Navigation System Schematics»(/pontiac/g6/i-final-2010-2010/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems)

Connector End View Reference

Component Connector End Views

Description and Operation

Steering Wheel Controls Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the left and right steering wheel control switches.
2. Ignition ON, radio ON, test for 9.8-10.2 volts between the voltage reference circuit terminal 1 and ground. If greater than the specified range, test the voltage reference circuit for a short to voltage. If the circuit tests normal, replace the radio. If less than the specified range, test the voltage reference circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the radio.
3. Test for greater than 9 volts between the voltage reference circuit terminal 5 and the signal circuit terminal 4. If less than the specified range, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the radio.
4. Ignition OFF, disconnect the X1 harness connector at the radio.
5. Test for infinite resistance between the signal circuit terminal 1 and ground. If less than the specified value, test the signal circuit for a short to ground.
6. Ignition ON, test for less than 1 volt between ground and the voltage reference circuit terminal 1 at the left steering wheel control switch. If greater than the specified range, test the voltage reference circuit for a short to voltage.
7. Ignition ON, test for infinite resistance between ground and the voltage reference circuit terminal 1 at the left steering wheel control switch. If not the specified value, test the voltage reference circuit for a short to ground.
8. Test for less than 1 ohm between the voltage reference circuit terminal 1 at the left steering wheel control switch and the voltage reference circuit terminal 5 at the right steering wheel control switch. If greater than the specified range, test the voltage reference circuit for a an open/high resistance.
9. If all circuits test normal, test or replace the left or right steering wheel control switch.

1. Disconnect the harness connector at the right or left steering wheel control switch.
2. Connect a DMM between terminal 1 and terminal 4 of either the left or right steering wheel control switch. If any of the resistance measurements for the individual switches are not within the specified resistance values, replace the right steering wheel control switch.

Left Steering Wheel Switch Resistance

Right Steering Wheel Switch Resistance

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Steering Wheel Control Switch Assembly Replacement (Cruise Control and Radio Switch)»(/pontiac/g6/i-final-2010-2010/remont/memory-modules/#configurable-customer-control-system)
2. «Control Module References»(/pontiac/g6/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for radio replacement, setup, and programming

Symptoms - Secondary and Configurable Customer Controls

Visual/Physical Inspection

1. Inspect for aftermarket devices which may affect the operation of the Steering Wheel Controls System. Refer to «Checking Aftermarket Accessories»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__checking-aftermarket-accessories) .
2. Inspect for easily accessible or visible system components for obvious damage or conditions which may cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to Steering Wheel Controls Malfunction (3-Spoke) or Steering Wheel Controls Malfunction (4-Spoke) in order to diagnose the symptom.

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The radio supplies voltage to the audio steering wheel control switches and monitors the return signal. Each switch state is associated to a set resistance value and when pressed a specific voltage drop occurs across the resistor unique to the switch. The radio identifies the switch selection and activates the feature.

1. Ensure the primary controls of the associated component are functioning properly before diagnosis of the steering wheel controls.
2. Review schematic when testing switch resistance values.

Schematic Reference

1. «Steering Wheel Secondary/Configurable Control Schematics»(/pontiac/g6/i-final-2010-2010/remont/memory-modules/#configurable-customer-control-system)
2. «Radio/Navigation System Schematics»(/pontiac/g6/i-final-2010-2010/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems)

Connector End View Reference

Component Connector End Views

Description and Operation

Steering Wheel Controls Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ensure the primary controls of the associated component are functioning properly.

1. Ignition OFF, disconnect the harness connector at the right steering wheel control switch.
2. Ignition ON, radio ON, test for 9.2-10.2 volts between the voltage reference circuit terminal 2 and ground. If less than the specified range, test the voltage reference circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the radio. If greater than the specified range, test the voltage reference circuit for a short to voltage. If the circuit tests normal, replace the radio.
3. Test for 9.2-10.2 volts between the voltage reference circuit terminal 2 and the signal circuit terminal 4. If less than the specified range, test the signal circuit for an open/high resistance. If the circuit tests normal, replace the radio. If greater than the specified range, test the signal circuit for a short to voltage. If the circuit tests normal, replace the radio.
4. Ignition OFF, disconnect the X1 harness connector at the radio.
5. Test for infinite resistance between the signal circuit terminal 4 and ground. If less than the specified value, test the signal circuit for a short to ground.
6. If all circuits test normal, test or replace the right steering wheel control switch.

1. Disconnect the harness connector at the right steering wheel control switch.
2. Connect a DMM between terminals 2 and 4 of the right steering wheel control switch. If not within the specified resistance ranges, replace the right steering wheel control switch.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Steering Wheel Control Switch Assembly Replacement (Cruise Control and Radio Switch)»(/pontiac/g6/i-final-2010-2010/remont/memory-modules/#configurable-customer-control-system)
2. «Control Module References»(/pontiac/g6/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for radio replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/g6/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The radio supplies voltage to the audio steering wheel control switches and monitors the return signal. Each switch state is associated to a set resistance value and when pressed a specific voltage drop occurs across the resistor unique to the switch. The radio identifies the switch selection and activates the feature.

Ensure the primary controls of the associated component are functioning properly before diagnosis of the steering wheel controls.

Schematic Reference

1. «Steering Wheel Secondary/Configurable Control Schematics»(/pontiac/g6/i-final-2010-2010/remont/memory-modules/#configurable-customer-control-system)
2. «Radio/Navigation System Schematics»(/pontiac/g6/i-final-2010-2010/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems)

Connector End View Reference

Component Connector End Views

Description and Operation

Steering Wheel Controls Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/g6/i-final-2010-2010/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the left and right steering wheel control switches.
2. Ignition ON, radio ON, test for 9.8-10.2 volts between the voltage reference circuit terminal 1 and ground. If greater than the specified range, test the voltage reference circuit for a short to voltage. If the circuit tests normal, replace the radio. If less than the specified range, test the voltage reference circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the radio.
3. Test for greater than 9 volts between the voltage reference circuit terminal 5 and the signal circuit terminal 4. If less than the specified range, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the radio.
4. Ignition OFF, disconnect the X1 harness connector at the radio.
5. Test for infinite resistance between the signal circuit terminal 1 and ground. If less than the specified value, test the signal circuit for a short to ground.
6. Ignition ON, test for less than 1 volt between ground and the voltage reference circuit terminal 1 at the left steering wheel control switch. If greater than the specified range, test the voltage reference circuit for a short to voltage
7. Ignition ON, test for infinite resistance between ground and the voltage reference circuit terminal 1 at the left steering wheel control switch. If not the specified value, test the voltage reference circuit for a short to ground.
8. Test for less than 1 ohm between the voltage reference circuit terminal 1 at the left steering wheel control switch and the voltage reference circuit terminal 5 at the right steering wheel control switch. If greater than the specified range, test the voltage reference circuit for a an open/high resistance.
9. If all circuits test normal, test or replace the left or right steering wheel control switch.

1. Disconnect the harness connector at the right or left steering wheel control switch.
2. Connect a DMM between terminal 1 and terminal 4 of either the left or right steering wheel control switch. If any of the resistance measurements for the individual switches are not within the specified resistance values, replace the right steering wheel control switch.

Left Steering Wheel Switch Resistance

Right Steering Wheel Switch Resistance

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Steering Wheel Control Switch Assembly Replacement (Cruise Control and Radio Switch)»(/pontiac/g6/i-final-2010-2010/remont/memory-modules/#configurable-customer-control-system)
2. «Control Module References»(/pontiac/g6/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for radio replacement, setup, and programming

Scheme 2

Steering Wheel Controls Description and Operation

The audio steering wheel control switches duplicate the function of the primary controls of the associated component, through a network of multiple momentary contact switches and a series of resistors. The radio supplies voltage to the switches and monitors the return signal for a specific voltage drop to occur unique to the one pressed. The radio then identifies the switch selected to activate the feature, otherwise sends a serial data message that is received by the component controlled, activating the feature.

This section is intended to diagnosis the circuits between the radio and the audio steering wheel control switches. If the primary control for the device is inoperative, refer to the appropriate section for the component the steering wheel control switch is functioning.
