Contents Section: Frames, Subframes & Crossmembers All sections

Frame & Underbody Pontiac G6 I final

Frames, Subframes & Crossmembers 4 illustrations ~4252 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Frame Brace Bolts50 N.m37 lb ft
Stabilizer Link Nut65 N.m48 lb ft
Steering Knuckle Pinch Bolt
First Pass50 N.m Reverse 3/4 turn37 lb ft Reverse 3/4 turn
Final Pass50 N.m+60°37 lb ft+60°
Suspension Cradle to Body Bolts
First Pass100 N.m74 lb ft
Final Pass+90°
Wheelhouse Liner Nuts5 N.m44 lb in

Alignment Checking

Use a measuring tram gauge as an accurate method of determining the alignment of the underbody. The tram gauge set required to perform the recommended measuring checks must include a vertical pointer capable of reaching 457 mm (18 in).

The following 2 types of measurement may be made using a tram gauge

  1. Direct point to point measurements
  2. Measurements calculated on a horizontal plane (datum line) parallel to the underbody

Dimensions that are measured to gauge holes are measured to the center of the holes and flush to the adjacent metal surface unless otherwise specified. It is recommended that the diagonal dimensions be cross body checked on both sides in order to verify the dimensional accuracy of the vehicle underbody. Set vertical pointers equally as needed per your application.

Special Tools

J 39580 Engine Support Stand. See Special Tools .

Removal Procedure

  1. Support the radiator and condenser from above.
  2. Raise the vehicle on a hoist. Refer to «Lifting and Jacking the Vehicle»(/pontiac/g6/i-final-2010-2010/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  3. Remove the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  4. Remove the engine splash shields. Refer to «Engine Splash Shield Replacement - Left Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) and «Engine Splash Shield Replacement - Right Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  5. Remove the radiator air lower baffle. Refer to «Radiator Air Lower Baffle and Deflector Replacement»(/pontiac/g6/i-final-2010-2010/remont/cooling-system-mechanical/#engine-cooling-system) .
  6. Disconnect the antilock brake system (ABS) sensor from the wheel speed sensor and frame.
  7. Remove the lower ball joints from the steering knuckles.
  8. Remove the tie rod ends from the steering knuckles. Refer to «Steering Linkage Outer Tie Rod Replacement»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  9. Remove both stabilizer links from the stabilizer bar.
  10. Remove the power steering gear mounting bolts and secure the gear out of the way using mechanics wire or equivalent, being sure not to overextend the intermediate shaft. Refer to «Steering Gear Replacement (Electronic Power Steering)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LY7)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LZ4, LZ9)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  11. Remove the engine mount nuts from the frame. Refer to «Engine Mount Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-35l-repair-instructions-on-vehicle) for the 3.5L engine or «Engine Mount Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-39l-repair-instructions-on-vehicle) for the 3.9L engine.
  12. Remove the front transmission mount bolt from the frame. Refer to «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  13. Remove the left transmission mount nuts from the frame. Refer to «Transmission Mount Replacement - Left Side (2.4L)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) or «Transmission Mount Replacement - Left Side (3.5L)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Mount Replacement - Left Side (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  14. Remove the rear transmission mount bracket nuts from the frame. Refer to «Transmission Rear Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Rear Mount Bracket Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  15. Remove the brake lines from the retainers on the frame.
  16. Remove the catalytic converter. Refer to «Catalytic Converter Replacement - Left Side (LY7)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Left Side (LZ4)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Left Side (LZ9)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Right Side (LY7)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Right Side (LZ4)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Right Side (LZ9 w/RPO M15)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Right Side (LZ9 w/RPO MT2)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) .
  17. Remove the power steering gear mounting bolts and secure the gear out of the way using mechanics wire or equivalent. Refer to «Steering Gear Replacement (Electronic Power Steering)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LY7)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LZ4, LZ9)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) . Ensure NOT to overextend the intermediate shaft.
  18. Lower the vehicle until the frame contacts the J 39580 . See «Special Tools»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  19. Remove the frame reinforcement bolts (2) and frame brace bolts (1).
  20. Remove the front frame bolts (1).
  21. Remove the rear frame bolts (5).
  22. Remove the frame reinforcements (2).
  23. Raise the vehicle off of the frame.
  24. Remove the following components if replacing the frame: The lower control arms-Refer to «Lower Control Arm Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) . The stabilizer shaft-Refer to «Stabilizer Shaft Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-rear/#rear-suspension-system) .

Installation Procedure

  1. Install the following components on the suspension crossmember if removed: The stabilizer shaft-Refer to «Stabilizer Shaft Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-rear/#rear-suspension-system) . The lower control arms-Refer to «Lower Control Arm Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) .
  2. Lower the vehicle on to the frame.
  3. Install the power steering gear mounting bolts. Refer to «Steering Gear Replacement (Electronic Power Steering)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LY7)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LZ4, LZ9)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  4. Install the frame reinforcements (2).
  5. Install the rear frame bolts (5) and tighten the bolts to 100 N.m (74 lb ft) plus 90 degree rotation.
  6. Install the front frame bolts (1) and tighten the bolts to 100 N.m (74 lb ft) plus 90 degree rotation.
  7. Install the frame reinforcement bolts (2) and frame brace bolts (1) and tighten to 50 N.m (37 lb ft).
  8. Install the cradle support bolts and tighten to 100 N.m (74 lb ft).
  9. Raise the vehicle.
  10. Install the brake lines to the retainers on the frame.
  11. Install the rear transmission mount bracket nuts. Refer to «Transmission Rear Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Rear Mount Bracket Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  12. Install the left transmission mount nuts to the frame. Refer to «Transmission Mount Replacement - Left Side (2.4L)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) or «Transmission Mount Replacement - Left Side (3.5L)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Mount Replacement - Left Side (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  13. Install the front transmission mount bracket bolt. Refer to «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  14. Install the engine mount nuts to the frame. Refer to «Engine Mount Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-35l-repair-instructions-on-vehicle) for the 3.5L engine or «Engine Mount Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-39l-repair-instructions-on-vehicle) for the 3.9L engine.
  15. Install the power steering gear mounting bolts. Refer to «Steering Gear Replacement (Electronic Power Steering)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LY7)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LZ4, LZ9)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  16. Install both stabilizer links to the stabilizer bar and tighten the nut to 65 N.m (48 lb ft) plus 180 degree rotation.
  17. Install the tie rod ends to the steering knuckles. Refer to «Steering Linkage Outer Tie Rod Replacement»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  18. Install the lower ball joints to the steering knuckles. Tighten the ball stud to steering knuckle pinch nut to 50 N.m (37 lb ft). Reverse the nut 3/4 of a turn. Tighten to 50 N.m (37 lb ft) plus 60 degrees.
  19. Install the rear catalytic converter. Refer to «Catalytic Converter Replacement - Left Side (LY7)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Left Side (LZ4)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Left Side (LZ9)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) and «Catalytic Converter Replacement - Right Side (LY7)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Right Side (LZ4)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Right Side (LZ9 w/RPO M15)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Right Side (LZ9 w/RPO MT2)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) .
  20. Connect the ABS sensor to the wheel speed sensor and frame.
  21. Install the radiator air lower baffle. Refer to «Radiator Air Lower Baffle and Deflector Replacement»(/pontiac/g6/i-final-2010-2010/remont/cooling-system-mechanical/#engine-cooling-system) .
  22. Install the engine splash shields. Refer to «Engine Splash Shield Replacement - Left Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) and «Engine Splash Shield Replacement - Right Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  23. Install the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  24. Remove the engine support fixture.
  25. Bleed the power steering system. Refer to «Power Steering System Bleeding»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .

J 39580 Engine Support Stand. See Special Tools .

  1. Install the engine support fixture. Refer to «Engine Support Fixture»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-35l-repair-instructions-on-vehicle) .
  2. Raise the vehicle on a hoist. Refer to «Lifting and Jacking the Vehicle»(/pontiac/g6/i-final-2010-2010/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  3. Remove the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  4. Remove the engine splash shields. Refer to «Engine Splash Shield Replacement - Left Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) and «Engine Splash Shield Replacement - Right Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  5. Remove the radiator air lower baffle. Refer to «Radiator Air Lower Baffle and Deflector Replacement»(/pontiac/g6/i-final-2010-2010/remont/cooling-system-mechanical/#engine-cooling-system) .
  6. Disconnect the antilock brake system (ABS) sensor from the wheel speed sensor and frame.
  7. Remove the lower ball joints from the steering knuckles.
  8. Remove the tie rod ends from the steering knuckles. Refer to «Steering Linkage Outer Tie Rod Replacement»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  9. Remove both stabilizer links from the stabilizer bar. Refer to «Stabilizer Shaft Link Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) .
  10. Remove the power steering gear mounting bolts and secure the gear out of the way using mechanic wire or equivalent, being sure not to overextend the intermediate shaft. Refer to «Steering Gear Replacement (Electronic Power Steering)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  11. Remove the front transmission mount bolt from the frame. Refer to «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) .
  12. Remove the left transmission mount nuts from the frame. Refer to «Transmission Mount Replacement - Left Side (2.4L)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) .
  13. Remove the rear transmission mount bracket nuts from the frame. Refer to «Transmission Rear Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) .
  14. Remove the brake lines from the retainers on the frame.
  15. Lower the vehicle until the frame contacts the J 39580 . See «Special Tools»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  16. Remove the reinforcement bolts (1).
  17. Remove the front frame bolts (1).
  18. Remove the rear frame bolts (4).
  19. Remove the frame reinforcements (3).
  20. Raise the vehicle off of the frame.
  21. Remove the following components if replacing the frame: The lower control arms-Refer to «Lower Control Arm Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) . The stabilizer shaft-Refer to «Stabilizer Shaft Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-rear/#rear-suspension-system) .
  1. Install the following components on the suspension crossmember if removed: The stabilizer shaft-Refer to «Stabilizer Shaft Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-rear/#rear-suspension-system) . The lower control arms-Refer to «Lower Control Arm Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) .
  2. Lower the vehicle on to the frame.
  3. Install the frame reinforcements (3).
  4. Install the rear frame bolts (4). Tighten: Tighten the bolts to 100 N.m (74 lb ft) plus 90 degree rotation.
  5. Install the front frame bolts (1). Tighten: Tighten the bolts to 100 N.m (74 lb ft) plus 90 degree rotation.
  6. Install the cradle support bolts (1). Tighten: Tighten the bolts to 100 N.m (74 lb ft).
  7. Raise the vehicle.
  8. Install the brake lines to the retainers on the frame.
  9. Install the rear transmission mount bracket nuts. Refer to «Transmission Rear Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) .
  10. Install the left transmission mount nuts to the frame. Refer to «Transmission Mount Replacement - Left Side (2.4L)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) .
  11. Install the front transmission mount bracket bolt. Refer to «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) .
  12. Install the power steering gear mounting bolts. Refer to «Steering Gear Replacement (Electronic Power Steering)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  13. Install both stabilizer links to the stabilizer bar. Tighten: Tighten the stabilizer link nut to 65 N.m (48 lb ft).
  14. Install the tie rod ends to the steering knuckles. Refer to «Steering Linkage Outer Tie Rod Replacement»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  15. Install the lower ball joints to the steering knuckles. Tighten: Tighten the ball stud to steering knuckle pinch nut to 50 N.m (37 lb ft). Reverse the nut 3/4 of a turn. Tighten to 50 N.m (37 lb ft) plus 60 degrees.
  16. Connect the ABS sensor to the wheel speed sensor and frame.
  17. Install the radiator air lower baffle. Refer to «Radiator Air Lower Baffle and Deflector Replacement»(/pontiac/g6/i-final-2010-2010/remont/cooling-system-mechanical/#engine-cooling-system) .
  18. Install the engine splash shields. Refer to «Engine Splash Shield Replacement - Left Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) and «Engine Splash Shield Replacement - Right Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  19. Install the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  20. Remove the engine support fixture.
  21. Bleed the power steering system. Refer to «Power Steering System Bleeding»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .

J 39580 Engine Support Stand. See Special Tools .

  1. Install the engine support fixture. Refer to «Engine Support Fixture»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
  2. Support the radiator and condenser from above.
  3. Raise the vehicle on a hoist. Refer to «Lifting and Jacking the Vehicle»(/pontiac/g6/i-final-2010-2010/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  4. Remove the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  5. Remove the radiator air lower baffle. Refer to «Radiator Air Lower Baffle and Deflector Replacement»(/pontiac/g6/i-final-2010-2010/remont/cooling-system-mechanical/#engine-cooling-system) .
  6. Remove the engine splash shields. Refer to «Engine Splash Shield Replacement - Left Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) and «Engine Splash Shield Replacement - Right Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  7. Remove the lower ball joints from the steering knuckles. Refer to «Lower Control Arm Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) .
  8. Remove the tie rod ends from the steering knuckles. Refer to «Steering Linkage Outer Tie Rod Replacement»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  9. Remove both stabilizer links from the stabilizer bar. Refer to «Stabilizer Shaft Link Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) .
  10. Remove the power steering gear mounting bolts and secure the gear out of the way using mechanic's wire or equivalent, being sure not to overextend the intermediate shaft. Refer to «Steering Gear Replacement (Hydraulic Power Steering LY7)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  11. Remove the engine mount fasteners from the frame. Refer to «Engine Mount Replacement - Right Side»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
  12. Remove the front transmission mount bolt from the frame. Refer to «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-6t706t75-repair-instructions-on-vehicle) .
  13. Remove the left transmission mount fasteners from the frame. Refer to «Transmission Mount Replacement - Left Side»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-6t706t75-repair-instructions-on-vehicle) .
  14. Remove the rear transmission mount bracket fasteners from the frame. Refer to «Transmission Rear Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-6t706t75-repair-instructions-on-vehicle) .
  15. Remove the brake lines from the retainers on the frame.
  16. Remove the power steering outlet pipe/hose from the frame. Refer to «Power Steering Gear Outlet Pipe/Hose Replacement (LY7)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Power Steering Gear Outlet Pipe/Hose Replacement (LZ4, LZ9)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  17. Remove the rear catalytic converter. Refer to «Catalytic Converter Replacement - Left Side (LY7)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Right Side (LY7)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) .
  18. Lower the vehicle until the frame contacts the J 39580 . See «Special Tools»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  19. Remove the reinforcement bolts (1).
  20. Remove the front frame bolts (1).
  21. Remove the rear frame bolts (4).
  22. Remove the frame reinforcements (3).
  23. Raise the vehicle off of the frame.
  24. Remove the following components if replacing the frame: The lower control arms-Refer to «Lower Control Arm Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) . The stabilizer shaft-Refer to «Stabilizer Shaft Replacement (Sedan/Coupe)»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) or «Stabilizer Shaft Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) .
  1. Install the following components on the suspension crossmember if removed: The stabilizer shaft-Refer to «Stabilizer Shaft Replacement (Sedan/Coupe)»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) or «Stabilizer Shaft Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) . The lower control arms-Refer to «Lower Control Arm Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) .
  2. Lower the vehicle on to the frame.
  3. Install the frame reinforcements (3).
  4. Install the front frame bolts. Hand tighten ONLY.
  5. Install the reinforcement bolts. Hand tighten ONLY.
  6. Tighten the rear frame bolts (4). Tighten: Tighten the bolts to 100 N.m (74 lb ft) plus 180 degrees rotation.
  7. Tighten the front frame bolts (1) to specifications. Tighten: Tighten the bolts to 100 N.m (74 lb ft) plus 180 degrees rotation.
  8. Install the reinforcement bolts (1). Tighten: Tighten the bolts to 100 N.m (74 lb ft).
  9. Raise the vehicle.
  10. Install the power steering outlet pipe/hose to the frame. Refer to «Power Steering Gear Outlet Pipe/Hose Replacement (LY7)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  11. Install the brake lines to the retainers on the frame.
  12. Install the rear transmission mount bracket fasteners. Refer to «Transmission Rear Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-6t706t75-repair-instructions-on-vehicle) .
  13. Install the left transmission mount fasteners to the frame. Refer to «Transmission Mount Replacement - Left Side»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-6t706t75-repair-instructions-on-vehicle) .
  14. Install the front transmission mount bracket bolt. Refer to «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-6t706t75-repair-instructions-on-vehicle) .
  15. Install the engine mount fasteners to the frame. Refer to «Engine Mount Replacement - Right Side»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
  16. Install the power steering gear mounting fasteners. Refer to «Steering Gear Replacement (Electronic Power Steering)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LY7)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  17. Install both stabilizer links to the stabilizer bar. Tighten: Tighten the stabilizer link nut to 65 N.m (48 lb ft) plus 180 degrees rotation.
  18. Install the tie rod ends to the steering knuckles. Refer to «Steering Linkage Outer Tie Rod Replacement»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  19. Install the lower ball joints to the steering knuckles. Tighten: Reverse the nut 3/4 of a turn Tighten the ball stud to steering knuckle pinch nut to 50 N.m (37 lb ft). Tighten to 50 N.m (37 lb ft) plus 60 degrees.
  20. Install the rear catalytic converter. Refer to «Catalytic Converter Replacement - Left Side (LY7)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Right Side (LY7)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement - Right Side (LZ4)»(/pontiac/g6/i-final-2010-2010/remont/exhaust/#engine-exhaust-system) .
  21. Install the radiator air lower baffle. Refer to «Radiator Air Lower Baffle and Deflector Replacement»(/pontiac/g6/i-final-2010-2010/remont/cooling-system-mechanical/#engine-cooling-system) .
  22. Install the engine splash shields. Refer to «Engine Splash Shield Replacement - Left Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) and «Engine Splash Shield Replacement - Right Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  23. Install the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  24. Lower the vehicle.
  25. Remove the temporary radiator and condenser support.
  26. Remove the engine support fixture.

J 39580 Engine Support Stand. See Special Tools .

  1. Install the engine support fixture. Refer to «Engine Support Fixture»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-35l-repair-instructions-on-vehicle) for the 3.5L engine or «Engine Support Fixture»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-39l-repair-instructions-on-vehicle__engine-support-fixture) for the 3.9L engine.
  2. Raise the vehicle on a hoist. Refer to «Lifting and Jacking the Vehicle»(/pontiac/g6/i-final-2010-2010/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  3. Remove the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  4. Remove the engine splash shields. Refer to «Engine Splash Shield Replacement - Left Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) and «Engine Splash Shield Replacement - Right Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  5. Remove the radiator air lower baffle. Refer to «Radiator Air Lower Baffle and Deflector Replacement»(/pontiac/g6/i-final-2010-2010/remont/cooling-system-mechanical/#engine-cooling-system) .
  6. Disconnect the antilock brake system (ABS) sensor from the wheel speed sensor and frame.
  7. Remove the lower ball joints from the steering knuckles. Refer to «Lower Control Arm Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) .
  8. Remove the tie rod ends from the steering knuckles. Refer to «Steering Linkage Outer Tie Rod Replacement»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  9. Remove both stabilizer links from the stabilizer bar.
  10. Remove the power steering gear mounting bolts and secure the gear out of the way using mechanics wire or equivalent, being sure not to overextend the intermediate shaft. Refer to «Steering Gear Replacement (Electronic Power Steering)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LZ4, LZ9)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  11. Remove the engine mount nuts from the frame. Refer to «Engine Mount Replacement (Coupe)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-35l-repair-instructions-on-vehicle) or «Engine Mount Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-35l-repair-instructions-on-vehicle) for the 3.5L engine or «Engine Mount Replacement (Coupe)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-39l-repair-instructions-on-vehicle) or «Engine Mount Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-39l-repair-instructions-on-vehicle) for the 3.9L engine.
  12. Remove the front transmission mount bolt from the frame. Refer to «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  13. Remove the left transmission mount nuts from the frame. Refer to «Transmission Mount Replacement - Left Side (2.4L)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) or «Transmission Mount Replacement - Left Side (3.5L)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Mount Replacement - Left Side (Sedan/Coupe)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) or «Transmission Mount Replacement - Left Side (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  14. Remove the rear transmission mount bracket nuts from the frame. Refer to «Transmission Rear Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Rear Mount Bracket Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  15. Remove the brake lines from the retainers on the frame.
  16. Lower the vehicle until the frame contacts the J 39580 . See «Special Tools»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  17. Remove the reinforcement bolts (1).
  18. Remove the front frame bolts (1).
  19. Remove the rear frame bolts (4).
  20. Remove the frame reinforcements (3).
  21. Raise the vehicle off of the frame.
  22. Remove the following components if replacing the frame: The lower control arms-Refer to «Lower Control Arm Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) . The stabilizer shaft-Refer to «Stabilizer Shaft Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-rear/#rear-suspension-system) .
  1. Install the following components on the suspension crossmember if removed: The stabilizer shaft-Refer to «Stabilizer Shaft Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-rear/#rear-suspension-system) . The lower control arms-Refer to «Lower Control Arm Replacement»(/pontiac/g6/i-final-2010-2010/remont/suspension-front/#front-suspension-system) .
  2. Lower the vehicle on to the frame.
  3. Install the frame reinforcements (3).
  4. Install the rear frame bolts (4). Tighten: Tighten the bolts to 100 N.m (74 lb ft) plus 90 degree rotation.
  5. Install the front frame bolts (1). Tighten: Tighten the bolts to 100 N.m (74 lb ft) plus 90 degree rotation.
  6. Install the cradle support bolts (1). Tighten: Tighten the bolts to 100 N.m (74 lb ft).
  7. Raise the vehicle.
  8. Install the brake lines to the retainers on the frame.
  9. Install the rear transmission mount bracket nuts. Refer to «Transmission Rear Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Rear Mount Bracket Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  10. Install the left transmission mount nuts to the frame. Refer to «Transmission Mount Replacement - Left Side (2.4L)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) or «Transmission Mount Replacement - Left Side (3.5L)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Mount Replacement - Left Side (Sedan/Coupe)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) or «Transmission Mount Replacement - Left Side (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  11. Install the front transmission mount bracket bolt. Refer to «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t45-e-repair-instructions-on-vehicle) for the 4T45-E transmission, or «Transmission Front Mount Replacement»(/pontiac/g6/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-4t65-e-repair-instructions-on-vehicle) for the 4T65-E transmission.
  12. Install the engine mount nuts to the frame. Refer to «Engine Mount Replacement (Coupe)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-35l-repair-instructions-on-vehicle) or «Engine Mount Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-35l-repair-instructions-on-vehicle) for the 3.5L engine or «Engine Mount Replacement (Coupe)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-39l-repair-instructions-on-vehicle) or «Engine Mount Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-39l-repair-instructions-on-vehicle) for the 3.9L engine.
  13. Install the power steering gear mounting bolts. Refer to «Steering Gear Replacement (Electronic Power Steering)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) or «Steering Gear Replacement (Hydraulic Power Steering LZ4, LZ9)»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  14. Install both stabilizer links to the stabilizer bar. Tighten: Tighten the stabilizer link nut to 65 N.m (48 lb ft) plus 180 degree rotation.
  15. Install the tie rod ends to the steering knuckles. Refer to «Steering Linkage Outer Tie Rod Replacement»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  16. Install the lower ball joints to the steering knuckles. Tighten: Tighten the ball stud to steering knuckle pinch nut to 50 N.m (37 lb ft). Reverse the nut 3/4 of a turn. Tighten to 50 N.m (37 lb ft) plus 60 degrees.
  17. Connect the ABS sensor to the wheel speed sensor and frame.
  18. Install the radiator air lower baffle. Refer to «Radiator Air Lower Baffle and Deflector Replacement»(/pontiac/g6/i-final-2010-2010/remont/cooling-system-mechanical/#engine-cooling-system) .
  19. Install the engine splash shields. Refer to «Engine Splash Shield Replacement - Left Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) and «Engine Splash Shield Replacement - Right Side»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  20. Install the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  21. Remove the engine support fixture.
  22. Bleed the power steering system. Refer to «Power Steering System Bleeding»(/pontiac/g6/i-final-2010-2010/remont/manual-power-steering/#power-steering-system) .
  1. Install the engine support fixture. Refer to «Engine Support Fixture»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-35l-repair-instructions-on-vehicle) .
  2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/pontiac/g6/i-final-2010-2010/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  3. Remove the support brace mounting bolts (1), for vehicles equipped with the 3.5L (LZ4) or 3.9L (LZ9) engines.
  4. Remove the support brace (2), for vehicles equipped with the 3.5L (LZ4) or 3.9L (LZ9) engines.
  5. Remove the floor tunnel panel brace mounting bolts.
  6. Remove the mounting bolts for the exhaust shield.
  7. Remove the floor tunnel panel brace.
  8. Remove the mounting bolts for the rear crossmember brace.
  9. Remove the rear crossmember brace.
  1. Position the support brace (2) on the cradle, for vehicles equipped with the 3.5L (LZ4) or 3.9L (LZ9) engines.
  2. Install the support brace bolts (1). Tighten: Tighten the bolts to 100 N.m (73 lb ft) plus 180 degrees rotation.
  3. Position the floor tunnel panel brace on the vehicle.
  4. Hand tighten the mounting bolts.
  5. Install the tunnel panel brace mounting bolts. Tighten: Tighten the bolts to 50 N.m (37 lb ft).
  6. Install the remaining tunnel panel mounting bolts. Tighten: Tighten the bolts to 50 N.m (37 lb ft).
  7. Position the rear crossmember brace on the vehicle.
  8. Install the crossmember brace mounting bolts. Tighten: Tighten the bolts to 50 N.m (37 lb ft).
  9. Lower the vehicle.
  10. Remove the engine support fixture. Refer to «Engine Support Fixture»(/pontiac/g6/i-final-2010-2010/remont/mechanical/#engine-mechanical-35l-repair-instructions-on-vehicle) .

Tools Required

J-45725 Frame Bushing Installer. See Special Tools .

  1. Remove the frame. Refer to «Frame Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) or «Frame Replacement (Coupe 2.4L)»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) or «Frame Replacement (3.6L)»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) or «Frame Replacement (Coupe 3.5L, 3.9L)»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  2. Remove cradle bushing with a rubber mallet.
  1. Install clamp J-45725 onto the bushing leaving about an 1/8 inch from the bottom of the bushing. See «Special Tools»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  2. Align the split of the bushing to the front of the frame.
  3. Using J-45725 install the bushing until the entire radius of the bushing is halfway recessed in the cradle. See «Special Tools»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  4. Remove the J-45725 clamp. See «Special Tools»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  5. Install the bushing using the J-45725 until the lip of the bushing is fully seated to the bottom of the cradle assembly. See «Special Tools»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  6. Install the frame. Refer to «Frame Replacement (Convertible)»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) or «Frame Replacement (Coupe 2.4L)»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) or «Frame Replacement (3.6L)»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) or «Frame Replacement (Coupe 3.5L, 3.9L)»(/pontiac/g6/i-final-2010-2010/remont/frames-subframes-crossmembers/#frame-underbody) .
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/pontiac/g6/i-final-2010-2010/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  3. Remove the left front wheelhousing, pre-cut the liner in the area (1) to remove.
  4. Remove the right front wheel. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  5. Remove the right front wheelhousing, pre-cut the liner in the area (1) to remove.
  6. Remove the push-in retainers from the front fender liner.
  7. Remove the fender liner.
  1. Position the front fender liner to the fender. If replacing the wheelhousing liner with a new one, refer to step 4 in the removal.
  2. Install the front fender liner with the push-in retainers.
  3. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/pontiac/g6/i-final-2010-2010/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the rear tires and wheels. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  3. Remove the rear wheel housing, pre-cut the liner in the areas (1, 2) to remove.
  4. Remove the rear wheelhouse liner-to-rear wheelhouse retainers.
  5. Remove the rear wheelhouse liner nuts.
  6. Remove the rear wheelhouse liner from the vehicle.
  1. Install the rear wheelhouse liner to the vehicle. If replacing the wheelhousing liners with a new one, refer to step 3 in the removal.
  2. Install the rear wheelhouse liner fasteners.
  3. Install the rear wheelhouse liner nuts. Tighten: Tighten the nut to 5 N.m (44 lb in).
  4. Install the rear tires and wheels. Refer to «Tire and Wheel Removal and Installation»(/pontiac/g6/i-final-2010-2010/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
  5. Lower the vehicle.

Scheme 1

Scheme 1: Engine Splash Shield Replacement - Left Side
Scheme 1: Engine Splash Shield Replacement - Left Side
CalloutComponent Name
Preliminary Procedures Remove the tire/wheel assembly. Refer to Tire and Wheel Removal and Installation . Loosen the side radiator air baffle and deflector from the engine splash shield. Refer to Radiator Air Side Baffle and Deflector Replacement .
1Left Engine Splash Shield Plastic Retainers (Qty: 3)
2Left Engine Splash Shield

Scheme 2

Scheme 2: Engine Splash Shield Replacement - Right Side
Scheme 2: Engine Splash Shield Replacement - Right Side
CalloutComponent Name
Preliminary Procedures Remove the tire/wheel assembly. Refer to Tire and Wheel Removal and Installation . Loosen the side radiator air baffle and deflector from the engine splash shield. Refer to Radiator Air Side Baffle and Deflector Replacement .
1Right Engine Splash Shield Plastic Retainers (Qty: 5)
2Right Engine Splash Shield

Scheme 3

Scheme 3: Drivetrain and Front Suspension Frame Reinforcement Replacement (Convertible)
Scheme 3: Drivetrain and Front Suspension Frame Reinforcement Replacement (Convertible)
CalloutComponent Name
Preliminary Procedure: Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
1Floor Tunnel Panel Brace Bolt CAUTION: Refer to Fastener Caution . Tighten: 50 N.m (37 lb ft)
2Front Support Bolt Tip: Place a suitable jackstand under the rear portion of the front support prior to the removal of the bolt. Tighten: 100 N.m (74 lb ft) plus 180 degrees rotation
3Reinforcement Assembly Bolt (Qty: 2) Tighten: 50 N.m (37 lb ft)
4Reinforcement Assembly Tip: Pull downward on the floor tunnel panel brace and the rear portion of the front frame brace to gain clearance for the removal and installation of the reinforcement.
CAUTION
Refer to Fastener Caution .

Illustration Tool Number/ Description J 39580 Engine Support Stand J 45725 Frame Bushing Installer

Scheme 4

Scheme 4: Special Tools
Scheme 4: Special Tools
