Engine Mechanical - 3.5L: Component Locations Pontiac G6 I

Mechanical 28 illustrations ~505 words

New Special Tools Required

No changes for 2005.

Scheme 81

Scheme 81: Lubrication Description

Full pressure lubrication, through a full flow oil filter, is furnished by a gear type oil pump. The oil is drawn up through the pickup screen and the tube. The oil passes through the pump to the oil filter.

The oil filter is a full flow paper element unit. An oil filter bypass is used in order to ensure oil supply during the following conditions

  1. On a cold start
  2. If the filter is plugged
  3. If the filter develops excessive pressure drop

The bypass is designed to open at 69-83 kPa (10-12 psi).

A priority oil delivery system supplies oil first to the crankshaft journals. The oil from the crankshaft main bearings is supplied to the connecting rod bearings by intersecting the passages drilled in the crankshaft. The passages supply the oil to the crankshaft main bearings and the camshaft bearings through the intersecting vertical drilled holes. The oil passages from the camshaft journals supply oil to the hydraulic lifters.

The piston oil nozzle lubricates the pistons and cylinder walls in cylinders 5 and 6. A non serviceable check valve integrated into the nozzle prevents oil bleed down from the nozzle when the engine is not running.

The hydraulic lifters pump oil up through the pushrods to the rocker arms. The cast dams in the crankcase casting direct the oil that drains back from the rocker arms in order to supply the camshaft lobes. The camshaft chain drive is lubricated by indirect oil splash.

Scheme 82

Scheme 82

Scheme 83

Scheme 83

Special Tools

Special Tools Illustration Tool Number/ Description EN 46359 Puller End Protector J 7872 Magnetic Base Dial Indicator J 8001 Dial Indicator Set J 8037 Ring Compressor J 8087 Cylinder Bore Gauge J 8087 Cylinder Bore Gage J 8089 Carbon Removal Brush J 8520 Cam Lobe Lift Indicator J 9666 Valve Spring Tester J 21882 Oil Suction Pipe Installer J 22144 Oil Suction Pipe Installer J 22794 Spark Plug Port Adapter J 24086-C Piston Pin Remover/Installer Set J 24270 Cylinder Bore Ridge Reamer J 25087-C Oil Pressure Tester and Pump Primer J 28428-E High-Intensity Black Light Kit J 28467-B Universal Engine Support Fixture J 29113 Balancer and Crank Sprocket Puller J 33049 Camshaft Bearing Remover/Installer Set J 33049 Camshaft Bearing Service Set J 34686 Rear Main Seal Installer J 35468 Cover Aligner and Seal Installer J 35667-A Cylinder Head Leakdown Tester J 36462 Engine Support Adapter Leg J 37088-A Fuel Line Disconnect Tool Set J 37096 Flywheel Holder J 38606 Valve Spring Compressor J 38606 Valve Spring Compressor J 41556 Connecting Rod Guide J 41816 Crankshaft Balancer Remover J 41816-A Crankshaft Balancer Remover J 45059 Angle Meter J 45299 Engine Preluber

Scheme 84

Scheme 84: Special Tools

Scheme 85

Scheme 85

Scheme 86

Scheme 86

Scheme 87

Scheme 87

Scheme 88

Scheme 88

Scheme 89

Scheme 89

Scheme 90

Scheme 90

Scheme 91

Scheme 91

Scheme 92

Scheme 92

Scheme 93

Scheme 93

Scheme 94

Scheme 94

Scheme 95

Scheme 95

Scheme 96

Scheme 96

Scheme 97

Scheme 97

Scheme 98

Scheme 98

Scheme 99

Scheme 99

Scheme 100

Scheme 100

Scheme 101

Scheme 101

Scheme 102

Scheme 102

Scheme 103

Scheme 103

Scheme 104

Scheme 104

Scheme 105

Scheme 105

Scheme 106

Scheme 106

Scheme 107

Scheme 107

Scheme 108

Scheme 108
