Lighting Systems: Specifications Pontiac G6 I

Exterior Lights 24 illustrations ~191 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Fog Lamp Nuts2.5 N.m22 lb in
Headlamp Bolts2 N.m18 lb in
High Mounted Stop Lamp Bolts2 N.m18 lb in
HVAC Control Screws2.5 N.m22 lb in
License Lamp Screws2 N.m18 lb in
Tail Lamp Screws2 N.m18 lb in

Fastener Tightening Specifications

Lighting Systems Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs

Scheme 1

Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics
Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics

Scheme 2

Scheme 2: Fog Lights Schematics
Scheme 2: Fog Lights Schematics

Scheme 3

Scheme 3: Exterior Lights Schematics
Scheme 3: Exterior Lights Schematics

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7: Interior Lights Schematics
Scheme 7: Interior Lights Schematics

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10: Interior Lights Dimming Schematics
Scheme 10: Interior Lights Dimming Schematics

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13: Lighting Systems Component Views
Scheme 13: Lighting Systems Component Views
CalloutComponent Name
1Marker Lamp - RF
2Park/Turn Signal/DRL Lamp - RF
3Headlamp - Low Beam - Right
4Headlamp - High Beam - Right
5Cellular/Navigation and Digital Radio Antenna (UE1/U2K)
6Headlamp - High Beam - Left
7Headlamp - Low Beam - Left
8Park/Turn Signal/DRL Lamp - LF
9Marker Lamp - LF
10Fog Lamp - LF
11Fog Lamp - RF

Callouts For (Scheme 13)

Scheme 14

Scheme 14
Scheme 14
CalloutComponent Name
1Courtesy/Reading Lamp - LF
2Cellular Microphone (UE1)
3Sunroof Switch (CF5/C3Y)
4Courtesy/Reading Lamp - RF
5Dome/Reading Lamp (w/o C3Y)
6Sunroof (CF5/C3Y)
7Vanity Mirror Lamp - Right (DH6)
8Inside Rearview Mirror
9OnStar Keypad (UE1)
10Vanity Mirror Lamp - Left (DH6)

Callouts For (Scheme 14)

Scheme 15

Scheme 15
Scheme 15
CalloutComponent Name
1Turn Signal/Multifunction Switch
2Steering Wheel Controls - Left
3Instrument Panel Cluster (IPC)
4Steering Wheel Controls - Right
5Windshield Wiper/Washer Switch
6Ignition Switch
7Ambient Light Sensor
8Hazard Switch
9Radio
10Inflatable Restraint I/P Module
11Rear Window Defogger Switch
12Traction Control Switch (NW7/NW9)
13Cigar Lighter
14A/C Request Switch
15HVAC Control Module
16Inflatable Restraint Steering Wheel Module
17Fog Lamp Switch
18I/P Dimmer Switch
19Adjustable Pedals Position Switch

Callouts For (Scheme 15)

Scheme 16

Scheme 16
Scheme 16
CalloutComponent Name
1Brake Pedal Position Sensor
2Adjustable Pedals Position Sensor

Callouts For (Scheme 16)

Scheme 17

Scheme 17
Scheme 17
CalloutComponent Name
1A/T Shift Lock Control Solenoid
2Transmission Range Indicator Lamp

Callouts For (Scheme 17)

Scheme 18

Scheme 18
Scheme 18
CalloutComponent Name
1Courtesy Lamp - LR

Callouts For (Scheme 18)

CalloutComponent Name
1Rear Compartment Courtesy Lamp

Callouts For see scheme 19

CalloutComponent Name
1Courtesy Lamp - RR

Callouts For see scheme 20

Scheme 19

Scheme 19
Scheme 19
CalloutComponent Name
1Rear Compartment Courtesy Lamp

Callouts For (Scheme 19)

Scheme 20

Scheme 20
Scheme 20
CalloutComponent Name
1Marker Lamp - Left
2Tail/Stop and Turn Signal Lamp - Left
3Backup Lamp - Left
4Antenna
5Cellular/Navigation and Digital Radio Antenna (UE1/U2K)
6Rear Window Defogger Grid
7Backup Lamp - Right
8Tail/Stop and Turn Signal Lamp - Right
9Marker Lamp - Right
10License Lamp

Callouts For (Scheme 20)

Scheme 21

Scheme 21
Scheme 21
CalloutComponent Name
1Marker Lamp - Left
2Tail/Stop and Turn Signal Lamp - Right
3Backup Lamp - Left
4Center High Mounted Stop Lamp (CHMSL)
5Rear Window Defogger Grid
6Backup Lamp - Right
7Tail/Stop and Turn Signal Lamp - Right
8Marker Lamp - Right
9Rear Compartment Lid Release Switch - Exterior
10License Lamp

Callouts For (Scheme 21)

Scheme 22

Scheme 22: A/T Shift Indicator Lamp
Scheme 22: A/T Shift Indicator Lamp
Connector Part Information OEM: 12162083 Service: 8901283 Description: 2-Way F Lamp Socket Bulb Base Type W2 Axial (BK) Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Lighting Systems Connector End Views

PinWire ColorCircuit No.Function
ABK8Instrument Panel Lamp Supply Voltage (Coupe/Sedan)
BK/WH8Instrument Panel Lamp Supply Voltage (Convertible)
BBK150Ground

A/T Shift Indicator Lamp

Scheme 23

Scheme 23: Ambient Light Sensor (C60)
Scheme 23: Ambient Light Sensor (C60)
Connector Part Information OEM: 12047662 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK) Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A (GY)

Lighting Systems Connector End Views

PinWire ColorCircuit No.Function
AL-GN/BK1137DRL Ambient Light Sensor Signal
BYE/BK1138DRL Ambient Light Sensor Low Reference

Ambient Light Sensor (C60)

Scheme 24

Scheme 24: Backup Lamp - Left
Scheme 24: Backup Lamp - Left
Connector Part Information OEM: 16530675 Service: See Catalog Description: 2-Way F (BK) Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Lighting Systems Connector End Views

PinWire ColorCircuit No.Function
AL-GN1550Ground
L-GN1550Ground (Convertible)
BBN24Backup Lamp Supply Voltage

Backup Lamp - Left
