Scheme 92
Scheme 93
| Callout | Component Name |
|---|---|
| 1 | Turn Signal/Multifunction Switch |
| 2 | Steering Wheel Controls - Left |
| 3 | Instrument Panel Cluster (IPC) |
| 4 | Steering Wheel Controls - Right |
| 5 | Windshield Wiper/Washer Switch |
| 6 | Ignition Switch |
| 7 | Ambient Light Sensor |
| 8 | Hazard Switch |
| 9 | Radio |
| 10 | Inflatable Restraint I/P Module |
| 11 | Rear Window Defogger Switch |
| 12 | Traction Control Switch (NW7/NW9) |
| 13 | Cigar Lighter |
| 14 | A/C Request Switch |
| 15 | HVAC Control Module |
| 16 | Inflatable Restraint Steering Wheel Module |
| 17 | Fog Lamp Switch |
| 18 | I/P Dimmer Switch |
| 19 | Adjustable Pedals Position Switch |
Callouts For (Scheme 93)
Scheme 94
| Callout | Component Name |
|---|---|
| 1 | Auxiliary Power Outlet (NW7/NW9) |
Callouts For (Scheme 94)
Scheme 95
| Connector Part Information OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (M-GY) Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Power Outlet Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | RD/WH | 40 | Battery Positive Voltage |
| B | Not Used | ||
| C | BK | 1150 | Ground |
Auxiliary Power Outlet
