Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Accelerator Pedal Bracket Nuts | 10 N.m | 89 lb in |
| Accelerator Pedal Nuts | 10 N.m | 89 lb in |
| Adjustable Brake Pedal Motor Mounting Screws | 3 N.m | 27 lb in |
| Brake Pedal Assembly to Cowl Mounting Nuts | 15 N.m | 11 lb ft |
| Brake Pedal Bracket Bolts | 25 N.m | 18 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Adjustable Pedals Schematics
Scheme 2
Scheme 2: Adjustable Pedals Component Views
| Callout | Component Name |
|---|
| 1 | Turn Signal/Multifunction Switch |
| 2 | Steering Wheel Controls - Left |
| 3 | Instrument Panel Cluster (IPC) |
| 4 | Steering Wheel Controls - Right |
| 5 | Windshield Wiper/Washer Switch |
| 6 | Ignition Switch |
| 7 | Ambient Light Sensor |
| 8 | Hazard Switch |
| 9 | Radio |
| 10 | Inflatable Restraint I/P Module |
| 11 | Rear Window Defogger Switch |
| 12 | Traction Control Switch (NW7/NW9) |
| 13 | Cigar Lighter |
| 14 | A/C Request Switch |
| 15 | HVAC Control Module |
| 16 | Inflatable Restraint Steering Wheel Module |
| 17 | Fog Lamp Switch |
| 18 | I/P Dimmer Switch |
| 19 | Adjustable Pedals Position Switch |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Power Steering Control Module |
| 2 | Adjustable Pedals Module |
| 3 | Brake Pedal Position Sensor |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Brake Pedal Position Sensor |
| 2 | Adjustable Pedals Position Sensor |
Scheme 5
| Callout | Component Name |
|---|
| 1 | Accelerator Pedal Position (APP) Sensor |
| 2 | Adjustable Pedals Actuator (JF4) |
| 3 | Air Temperature Actuator |
Scheme 6
Scheme 6: Adjustable Pedal Module
| Connector Part Information OEM: 12064862 Service: 12126438 Description: 8-Way F Metri-Pack 150 Series (BK) |
Adjustable Pedals Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | L-BU | 5499 | Adjustable Pedal Enable Signal |
| B | PK | 5289 | Adjustable Pedals Position Sensor Signal |
| C | | | Not Used |
| D | BN/WH | 5288 | Adjustable Pedals Position Sensor Low Reference |
| E | BK/WH | 651 | Ground |
| F | WH | 5287 | Adjustable Pedals Position Sensor 5-Volt Reference |
| G | L-GN | 5980 | Adjustable Pedal Inhibit Signal |
| H | RD/WH | 740 | Battery Positive Voltage |
Scheme 7
Scheme 7: Adjustable Pedal Actuator
| Connector Part Information OEM: 15300027 Service: Description: 2-Way F Metri-Pack 280 Series Sealed (BK) |
Adjustable Pedals Actuator Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | YE | 5129 | Adjustable Pedal Actuator Rearward Control |
| B | PU | 5130 | Adjustable Pedal Actuator Forward Control |
Adjustable Pedal Actuator
Scheme 8
Scheme 8: Adjustable Pedal Position Sensor
| Connector Part Information OEM: 15326877 Service: 88987845 Description: 3-Way F Global Terminal 280 Series (BK) |
Adjustable Pedals Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | PK | 5289 | Adjustable Pedals Position Sensor Signal |
| B | BN/WH | 5288 | Adjustable Pedals Position Sensor Low Reference |
| C | WH | 5287 | Adjustable Pedals Position Sensor 5-Volt Reference |
Adjustable Pedal Position Sensor
Scheme 9
Scheme 9: Adjustable Pedal Position Switch
| Connector Part Information OEM: 15332141 Service: 88986249 Description: 6-Way F Global Terminal 150 Series (BK) |
Adjustable Pedals Position Switch Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | RD/WH | 740 | Battery Positive Voltage |
| B | YE | 5129 | Adjustable Pedal Actuator Rearward Control |
| C | BK | 650 | Ground |
| D | GY | 8 | Instrument Panel Lamp Supply Voltage |
| E | L-BU | 5499 | Adjustable Pedal Enable Signal |
| F | PU | 5130 | Adjustable Pedal Actuator Forward Control |
Adjustable Pedal Position Switch
