Removal & Installation
- Raise window halfway. Remove door panel and watershield. Support window by inserting rubber wedges between window and inner door panel. Remove window rear guide channel nuts.
- Move rear guide channel to gain access to regulator rivets. Drill out window regulator rivets. Disconnect regulator motor connector. Remove regulator assembly with motor attached.
- Drill hole in regulator sector gear and backplate. (Scheme 1) Install bolt and nut to lock sector gear into position. Drill o ut rivets and remove fragments. Remove regulator motor. To install, reverse removal procedure.
Scheme 1
Using a thin-blade screwdriver, pry between switch and door panel for spring clip (if equipped). Press down on clip to release switch and pry outward. Disconnect electrical connector and remove switch. To install, reverse removal procedure.
