Wheel Alignment Specifications & Procedures: Specifications Pontiac Firebird IV

Wheel Alignment 1 illustration

RIDING HEIGHT SPECIFICATIONS

Maximum variation between side-to-side and front-to-rear should not exceed .47" (12 mm).

Application(1) Front Dimension "A" In. (mm)(2) Rear Dimension "B" In. (mm)
Camaro & Firebird8.0 (204)8.2 (208)
(1) Location "A" is measured 32.6" (828 mm) from center of front axle. Dimension "A" is measured from floor to rocker panel. (Scheme 1) (2) Location "B" is measured 17.2" (438 mm) from center of rear axle. Dimension "B" is measured from floor to rocker panel. (Scheme 1)
(1)Location "A" is measured 32.6" (828 mm) from center of front axle. Dimension "A" is measured from floor to rocker panel. (Scheme 1)
(2)Location "B" is measured 17.2" (438 mm) from center of rear axle. Dimension "B" is measured from floor to rocker panel. (Scheme 1)

RIDING HEIGHT SPECIFICATIONS

Scheme 1

Scheme 1

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Lower Control Arm-To-Crossmember Nut75 (102)
Tie Rod End Lock Nut35 (47)

TORQUE SPECIFICATIONS

ApplicationPreferredRange
Camber (1)
Front0.40.1 To 0.9
Rear00.6 To 0.6
Caster (1)5.04.5 To 5.5
Toe-In (1)
Front00.1 To 0.1
Rear00.15 To 0.15
Toe-In (2)
Front00.2 To 0.2 (- 2.5 To 2.5)
Rear00.3 To 0.3 (- 4.0 To 4.0)
(1) Measurement is in degrees. (2) Measurement is in inches (mm).
(1)Measurement is in degrees.
(2)Measurement is in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS
