Starting System: Specifications Pontiac Firebird IV

Starter 1 illustration

STARTER SPECIFICATIONS

EngineStarter MotorAmps
3.8LPG260(1) 30-50
5.7LPG260(1) 30-50
(1) At 11.5 volts.
(1)At 11.5 volts.

HOLD-IN WINDINGS SPECIFICATIONS

EngineStarter MotorAmps
3.8LPG260(1) 30-50
5.7LPG260(1) 30-50
(1) At 11.5 volts.
(1)At 11.5 volts.

PULL-IN WINDINGS SPECIFICATIONS

ApplicationStarter(1) AmpsRPM
3.8LPG260(2) 60-1202900-3400
5.7LPG260(2) 60-1202900-3400
(1) At 10 volts. (2) At 11.5 volts.
(1)At 10 volts.
(2)At 11.5 volts.

STARTER NO-LOAD TEST SPECIFICATIONS

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
EGR Pipe Bolts21 (28)
Starter Mounting Bolts
3.8L35 (47)
5.7L35 (47)
In. Lbs. (N.m)
Intake Manifold Bolts & Studs89 (10)
Solenoid Terminals Inner Nuts71 (8)
Solenoid To Starter Bolts & Screws70 (7)

TORQUE SPECIFICATIONS

Fig. 10: Starting System Wiring Diagram (Camaro & Firebird)
Scheme 10: Starting System Wiring Diagram (Camaro & Firebird)
