Fuse Block & Flasher Locations. Scheme 1
Scheme 1: Fuse Block & Flasher Locations
| Application | Location |
|---|
| Bonneville, Grand Prix & Safari Wagon |
| Fuse Block | (2) Left Instrument Panel |
| Hazard Flasher | On Fuse Block |
| Turn Signal Flasher | On Fuse Block |
| Fiero |
| Fuse Block | (2) Left Instrument Panel |
| Hazard Flasher | Convenience Center |
| Turn Signal Flasher | (3) Left of Steering Column |
| Firebird & Trans Am |
| Fuse Block | (3) Left of Steering Column |
| Hazard Flasher | Convenience Center |
| Turn Signal Flasher | Above Convenience Center |
| Grand Am |
| Fuse Block | (2) Left Instrument Panel |
| Hazard Flasher | (5) Center Instrument Panel |
| Turn Signal Flasher | (3) Left of Steering Column |
| Sunbird |
| Fuse Block | (2) Left Instrument Panel |
| Hazard Flasher | Convenience Center |
| Turn Signal Flasher | (5) Right of Steering Column |
| 1000 |
| Fuse Block | (2) Left Instrument Panel |
| Hazard Flasher | On Fuse Block |
| Turn Signal Flasher | (2) Left Instrument Column |
| 6000 |
| Fuse Block | (6) Behind Glove Box |
| Hazard Flasher | Convenience Center |
| Turn Signal Flasher | (5) Right of Steering Column |
| (1) Numbers refer to locations on Graphic. (Scheme 1) |
| (1) | Numbers refer to locations on Graphic. (Scheme 1) |
FUSE BLOCK & FLASHER LOCATIONS (1)
