COMPONENT LOCATIONS
Note. Component location tables for Saturn vehicles are not available. Refer to appropriate illustrations. (Scheme 15)- (Scheme 21).
COMPONENT LOCATIONS (2.2L VIN 4 & VIN F, & 2.4L VIN T - CAVALIER & SUNFIRE - GASOLINE)
| Component | Location |
|---|---|
| A/C Compressor Clutch Relay | Left Side Of Engine Compartment, In Underhood Fuse/Relay Center |
| A/C Refrigerant Pressure Sensor | Right Front Of Engine Compartment, Below Coolant Surge Tank |
| Camshaft Position Sensor | Rear Center Of Engine |
| Convenience Center | Right Upper Side Of Instrument Panel |
| Cooling Fan Relay | Left Side Of Engine Compartment, In Underhood Fuse/Relay Center |
| Crankshaft Position Sensor | Rear Center Of Engine, Below CMP Sensor |
| Cruise Control Module | Right Rear Of Engine Compartment |
| Data Link Connector | Lower Left Side Of Instrument Panel |
| Engine Coolant Level Switch | Right Side Of Engine Compartment, On Surge Tank |
| Engine Coolant Temperature Sensor | Right Top Of Engine |
| Engine Oil Pressure Sensor | Rear Center Of Engine |
| EVAP Canister Purge Solenoid | Right Front Of Engine |
| EVAP Canister Vent Solenoid | Under Rear Of Vehicle |
| Fuel Injectors | Top Front Of Engine, On Fuel Rail |
| Fuel Pump Relay | Left Side Of Engine Compartment, In Underhood Fuse/Relay Center |
| Fuel Tank Pressure Sensor | On Fuel Tank |
| Idle Air Control Valve | Front Of Throttle Body |
| Intake Air Temperature Sensor | In Left Front Of Engine Compartment |
| Ignition Control Module | Left Top Of Engine |
| Knock Sensor | Rear Center Of Engine, Next To CKP Sensor |
| Manifold Absolute Pressure Sensor | Left Side Of Throttle Body |
| Post-Converter Oxygen Sensor | Under Rear Passenger Compartment, Rear Of Catalytic Converter |
| Powertrain Control Module | Top Right Of Engine Compartment, Behind Fascia |
| Pre-Converter Oxygen Sensor | In Exhaust Manifold |
| Throttle Position Sensor | Left Top Of Throttle Body |
| Transaxle Range Switch | Top Of Transaxle |
| Underhood Fuse/Relay Center | Left Side Of Engine Compartment |
| Vehicle Speed Sensor (A/T) | On Rear Of Transmission |
COMPONENT LOCATIONS (2.2L VIN 4 & VIN F, & 2.4L VIN T - CAVALIER & SUNFIRE - GASOLINE)
COMPONENT LOCATIONS (2.2L VIN 4 - CAVALIER - CNG)
Note. Component locations for 2.2L VIN 4 - CAVALIER - CNG vehicles apply to CNG components only. For gasoline components, see COMPONENT LOCATIONS (2.2L VIN 4 & 2.4L VIN T - CAVALIER & SUNFIRE - GASOLINE) table.
| Component | Location |
|---|---|
| AF Fuel Pump Relay | Below Left Headlight |
| Alternate Fuel Engine Control Unit | Behind Left Front Fascia, Below Headlight |
| CNG Fuse | Underhood Fuse Block |
| Fuel Gauge Relay | Below Left Headlight |
| Fuel Gauge Selector Switch | Left Of Steering Column On Instrument Panel |
| Fuel Pressure Sensor | Left Side Of Trunk On HPL |
| Fuel Temperature Sensor | Left Side Of Trunk Part Of HPL |
| Gas Mass Sensor/Mixture Control Valve | Top Center Of Engine |
| High Pressure Lock-Off Solenoid | Left Side Of Trunk |
| Ignition Relay | Below Left Headlight |
| Lock-Off Relay | Below Left Headlight |
| Low Pressure Lock-Off Solenoid | Top Right Of Engine |
COMPONENT LOCATIONS (2.2L VIN 4 - CAVALIER - CNG)
COMPONENT LOCATIONS (2.2L VIN F - ALERO & GRAND AM)
| Component | Location |
|---|---|
| A/C Compressor Clutch Relay | Left Side Of Engine Compartment, In Underhood Junction Block |
| A/C Refrigerant Pressure Sensor | Front Of Engine Compartment |
| Camshaft Position Sensor | Top Rear Of Engine |
| Cooling Fan Control Relays No. 1 & 2 | Left Side Of Engine Compartment, In Underhood Junction Block |
| Crankshaft Position Sensor | Lower Left Side Of Engine, Near Oil Filter |
| Cruise Control Module | Right Side Of Engine Compartment |
| Data Link Connector | Lower Left Side Of Instrument Panel |
| Engine Coolant Level Switch | Right Side Of Engine Compartment |
| Engine Coolant Temperature Sensor | Top Rear Of Engine |
| Engine Oil Pressure Sensor | Top Left Of Engine |
| EVAP Canister Purge Solenoid | Lower Front Of Engine |
| EVAP Canister Vent Solenoid | Under Rear Of Vehicle |
| Fuel Injectors | Top Front Of Engine, On Fuel Rail |
| Fuel Pump Relay | Left Side Of Engine Compartment, In Underhood Junction Block |
| Fuel Tank Pressure Sensor | Under Rear Of Vehicle |
| Idle Air Control Valve | Top Front Of Engine |
| Ignition Control Module | Top Left Of Engine |
| Intake Air Temperature Sensor | Top Left Side Of Engine Compartment |
| Knock Sensor | Top Left Of Engine Of Engine |
| Left Instrument Panel Junction Block | Left Side Of Instrument Panel |
| Manifold Absolute Pressure Sensor | Top Front Of Engine |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Below Left Side Of Instrument Panel, Near Steering Column |
| Pre-Converter Oxygen Sensor | In Exhaust Manifold |
| Right Instrument Panel Junction Block | Right Side Of Instrument Panel |
| Throttle Position Sensor | On Throttle Body Assembly |
| Transaxle Range Switch | Left Side Of Engine Compartment, On Top Of Transaxle |
| Underhood Junction Block | Left Side Of Engine Compartment |
| Vehicle Speed Sensor | Rear Of Engine/Transaxle |
COMPONENT LOCATIONS (2.2L VIN F - ALERO & GRAND AM)
COMPONENT LOCATIONS (3.1L VIN J - CENTURY)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | Left Side Of Engine Compartment, On Liquid Line |
| Camshaft Position Sensor | Right Side Of Engine, Below Intake Plenum |
| Crankshaft Position Sensor (7X) | Right Side Of Engine, Below Exhaust Manifold |
| Crankshaft Position Sensor (24X) | Right Front Side Of Engine, Behind Harmonic Balancer |
| Cruise Control Module | Left Side Of Engine Compartment, Mounted To Strut Tower |
| Data Link Connector | Under Left Side Of Instrument Panel, Right Of Steering Column |
| EGR Valve | Upper Left Side Of Engine, Near Throttle Body |
| Engine Coolant Temperature Sensor | Top Left Side Of Engine, Below Throttle Body |
| Engine Oil Level Switch | In Oil Pan, Lower Front Center |
| Engine Oil Pressure Switch | Front Of Engine, Above Starter |
| EVAP Canister Purge Solenoid | Top Rear Of Engine, Behind Ignition Control Module |
| EVAP Canister Vent Solenoid | Behind Left Rear Fascia Splash Shield, In Wheelwell |
| Fuel Injectors | In Intake Manifold |
| Fuse Block | Right Side Of Instrument Panel, In Door Opening |
| Idle Air Control Valve | On Throttle Body |
| Ignition Control Module | Top Rear Of Engine |
| Intake Air Temperature Sensor | Left Front Of Engine Compartment, On Air Intake Duct |
| Knock Sensor (Bank No. 1) | Front Of Engine, Above Starter |
| Manifold Absolute Pressure Sensor | Top Rear Of Engine |
| Mass Airflow Sensor | Left Front Of Engine, In Air Intake Duct |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Left Side Of Engine, In Air Cleaner Assembly |
| Pre-Converter Oxygen Sensor | Behind Center Of Engine, In Exhaust Manifold |
| Throttle Position Sensor | On Throttle Body |
| Transaxle Range Switch | Left Of Engine, On Transaxle |
| Underhood Junction Block | Right Side Of Engine Compartment, Mounted To Strut Tower |
| Vehicle Speed Sensor | Lower Right Side Of Engine Compartment, On Transaxle |
COMPONENT LOCATIONS (3.1L VIN J - CENTURY)
COMPONENT LOCATIONS (3.1L VIN J - MALIBU)
| Component | Location |
|---|---|
| A/C Compressor Clutch Relay | Left Side Of Engine Compartment, In Underhood Junction Block |
| A/C Refrigerant Pressure Sensor | Front Of Engine Compartment |
| Camshaft Position Sensor | Top Rear Of Engine |
| Cooling Fan Control Relays No. 1 & 2 | Left Side Of Engine Compartment, In Underhood Junction Block |
| Crankshaft Position Sensor (7X) | Lower Rear Of Engine |
| Crankshaft Position Sensor (24X) | Lower Rear Of Engine |
| Cruise Control Module | Right Side Of Engine Compartment |
| Data Link Connector | Under Left Side Of Instrument Panel |
| EGR Valve | Top Rear Of Engine |
| Engine Coolant Level Switch | In Right Side Of Engine Compartment |
| Engine Coolant Temperature Sensor | Top Left Of Engine |
| Engine Oil Level Switch | Rear Of Engine |
| Engine Oil Pressure Sensor | Top Left Of Engine |
| EVAP Canister Purge Solenoid | Lower Front Of Engine |
| EVAP Canister Vent Solenoid | Under Rear Of Vehicle |
| Fuel Injectors | In Intake Manifold |
| Fuel Pump Relay | Left Side Of Engine Compartment, In Underhood Junction Block |
| Fuel Tank Pressure Sensor | Under Rear Of Vehicle |
| Idle Air Control Valve | Top Left Side Of Engine |
| Ignition Control Module | Top Rear Of Engine |
| Intake Air Temperature Sensor | Top Left Side Of Engine |
| Knock Sensor | On Front Of Engine |
| Left Instrument Panel Junction Block | Left Side Of Instrument Panel |
| Manifold Absolute Pressure Sensor | Top Rear Of Engine |
| Mass Airflow Sensor | Top Left Side Of Engine |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Below Left Side Of Instrument Panel, Near Steering Column |
| Pre-Converter Oxygen Sensor | Rear Of Engine, In Left Exhaust Manifold |
| Right Instrument Panel Junction Block | Right Side Of Instrument Panel |
| Throttle Position Sensor | Top Left Side Of Engine |
| Transaxle Range Switch | Left Side Of Engine |
| Underhood Junction Block | On Left Side Of Engine Compartment |
| Vehicle Speed Sensor | Rear Of Engine/Transaxle |
COMPONENT LOCATIONS (3.1L VIN J - MALIBU)
COMPONENT LOCATIONS (3.1L VIN J - GRAND PRIX)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | Left Side Of Engine Compartment, On Accumulator |
| Body Control Module | Below Left Side Of Instrument Panel, Left Of Steering Column |
| Camshaft Position Sensor | Right Side Of Engine, Below Intake Plenum |
| Crankshaft Position Sensor (7X) | Lower Right Side Of Engine Below Exhaust Manifold |
| Crankshaft Position Sensor (24X) | Front Of Engine, Behind Harmonic Balancer |
| Cruise Control Module | Left Side Of Engine Compartment, Mounted To Strut Tower |
| Data Link Connector | Under Instrument Panel, Right Of Steering Column |
| EGR Valve | Top Right Rear Of Engine, Near Throttle Body |
| Engine Coolant Temperature Sensor | Top Left Rear Of Engine, Below Throttle Body |
| Engine Oil Level Switch | Center Of Engine Oil Pan |
| Engine Oil Pressure Switch | Front Of Engine, Above Starter |
| EVAP Canister Purge Solenoid | Top Right Side Of Engine, Behind Ignition Control Module |
| EVAP Canister Vacuum Switch | Top Rear Of Engine, On Intake Manifold, Behind Ignition Control Module |
| EVAP Canister Vent Solenoid | Behind Left Rear Fascia Splash Shield, In Wheelwell |
| Fuel Injectors | In Intake Manifold |
| Fuse Block | Right Side Of Instrument Panel |
| Idle Air Control Valve | On Throttle Body |
| Ignition Control Module | Top Right Side Of Engine |
| Intake Air Temperature Sensor | Left Front Of Engine Compartment, On Air Intake Duct |
| Knock Sensor | Left Side Of Engine, Above Starter |
| Manifold Absolute Pressure Sensor | Top Right Side Of Engine, Above Valve Cover |
| Mass Airflow Sensor | Left Front Of Engine Compartment, In Air Intake Duct |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Left Side Of Engine Compartment, Inside Air Cleaner Assembly |
| Pre-Converter Oxygen Sensor | In Exhaust Manifold |
| Throttle Position Sensor | On Throttle Body |
| Transaxle Range Switch | Left Of Engine Compartment, On Transaxle |
| Underhood Junction Block | Right Side Of Engine Compartment, Mounted To Strut Tower |
| Vehicle Speed Sensor | Right Rear Of Engine Compartment, On Transaxle |
COMPONENT LOCATIONS (3.1L VIN J - GRAND PRIX)
COMPONENT LOCATIONS (3.4L VIN E - ALERO & GRAND AM)
| Component | Location |
|---|---|
| A/C Compressor Clutch Relay | Left Side Of Engine Compartment, In Underhood Junction Block |
| A/C Refrigerant Pressure Sensor | Front Of Engine Compartment |
| Camshaft Position Sensor | Top Rear Of Engine |
| Crankshaft Position Sensor (7X) | Lower Rear Of Engine |
| Crankshaft Position Sensor (24X) | Lower Rear Of Engine |
| Cruise Control Module | Right Side Of Engine Compartment |
| Data Link Connector | Under Left Side Of Instrument Panel |
| EGR Valve | Top Rear Of Engine |
| Engine Coolant Level Switch | Right Side Of Engine Compartment |
| Engine Coolant Temperature Sensor | Top Left Of Engine |
| Engine Oil Level Switch | Rear Of Engine |
| Engine Oil Pressure Sensor | Top Left Of Engine |
| EVAP Canister Purge Solenoid | Lower Front Of Engine |
| EVAP Canister Vent Solenoid | Under Rear Of Vehicle |
| Fuel Injectors | In Intake Manifold |
| Fuel Pump Relay | Left Side Of Engine Compartment, In Underhood Junction Block |
| Fuel Tank Pressure Sensor | Under Rear Of Vehicle |
| Idle Air Control Valve | Top Left Side Of Engine |
| Ignition Control Module | Top Rear Of Engine |
| Intake Air Temperature Sensor | Top Left Side Of Engine |
| Knock Sensor | On Front Of Engine |
| Left Instrument Panel Junction Block | Left Side Of Instrument Panel |
| Manifold Absolute Pressure Sensor | Top Rear Of Engine |
| Mass Airflow Sensor | Top Left Side Of Engine |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Under Left Side Of Instrument Panel, Near Steering Column |
| Pre-Converter Oxygen Sensor | Rear Of Engine, In Exhaust Manifold |
| Right Instrument Panel Junction Block | Right Side Of Instrument Panel |
| Throttle Position Sensor | Top Left Side Of Engine |
| Transaxle Range Switch | Left Side Of Engine |
| Underhood Junction Block | Left Side Of Engine Compartment |
| Vehicle Speed Sensor | Rear Of Engine/Transaxle |
COMPONENT LOCATIONS (3.4L VIN E - ALERO & GRAND AM)
COMPONENT LOCATIONS (3.4L VIN E - IMPALA & MONTE CARLO)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | Left Side Of Engine Compartment On Liquid Line |
| Camshaft Position Sensor | Right Side Of Engine, Below Intake Plenum |
| Crankshaft Position Sensor (7X) | Middle Rear Of Engine, Below Exhaust Manifold |
| Crankshaft Position Sensor (24X) | Right Front Of Engine, Behind Harmonic Balancer |
| Cruise Control Module | Left Side Of Engine Compartment |
| Data Link Connector | Bottom Of Instrument Panel, Right Of Steering column |
| EGR Valve | Upper Left Side Of Engine |
| Engine Coolant Temperature Sensor | On Top Left Side Of Engine |
| Engine Oil Level Switch | Right Side Of Engine, Bottom Of Oil Pan |
| Engine Oil Pressure Switch | Front Of Engine Above Starter |
| EVAP Canister Purge Solenoid | Top Rear Of Engine, On Intake Manifold |
| EVAP Canister Vent Solenoid | Under Left Rear Side Of Vehicle |
| Fuel Injectors | In Intake Manifold |
| Fuel Tank Pressure Sensor | Top Of Fuel Sending Unit |
| Idle Air Control Valve | Top Of Engine, Front Of Throttle Body |
| Ignition Control Module | Top Center Rear Of Engine |
| Intake Air Temperature Sensor | Left Front Of Engine Compartment, On Air Duct |
| Knock Sensor | Front Of Engine, Above Starter |
| Left Instrument Panel Junction Block | Left Side Of Instrument Panel |
| Manifold Absolute Pressure Sensor | Top Rear Of Engine |
| Mass Airflow Sensor | Left Front Of Engine Compartment, In Air Cleaner Duct |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Left Side Of Engine Compartment, Inside Air Box |
| Pre-Converter Oxygen Sensor | Rear Of Engine, In Exhaust Manifold |
| Right Instrument Panel Junction Block | Right Side Of Instrument Panel |
| Throttle Position Sensor | Top Of Engine, On Lower Front Of Throttle Body |
| Underhood Junction Block | Right Side Of Engine Compartment |
| Vehicle Speed Sensor | Rear Of Engine/Transaxle |
COMPONENT LOCATIONS (3.4L VIN E - IMPALA & MONTE CARLO)
COMPONENT LOCATIONS (3.5L VIN H - AURORA)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | Front Side Of Engine, On A/C Line, Behind A/C Compressor |
| Camshaft Position Sensor | Right Top Front Corner Of Engine, On Cam Carrier |
| Crankshaft Position Sensor | Left Rear Of Engine, Above Starter |
| Exhaust Gas Recirculation Valve | Top Of Engine, Rear Of Intake Manifold |
| Engine Coolant Temperature Sensor | Left Rear Of Engine, Below EGR Mount |
| Engine Oil Level Switch | Front Of Engine Oil Pan |
| EVAP Canister Purge Solenoid | Top Of Engine, Near Front Of Intake Manifold |
| Fuel Pump Relay | In Underhood Fuse Block |
| Fuel Tank Pressure Sensor | On Top Of Fuel Tank |
| Idle Air Control Valve | Top Of Engine, Front Of Throttle Body |
| Ignition Control Modules | Top Of Right & Left Cam Covers |
| Intake Air Temperature Sensor | Left Of Engine Compartment, In Air Cleaner Duct |
| Knock Sensor | On Rear Of Engine, Near Engine Oil Pressure Switch |
| Manifold Absolute Pressure Sensor | Top Of Engine, Rear Of Intake Manifold |
| Mass Air Flow Sensor | On Throttle Body Air Intake Duct |
| Post-Converter Oxygen Sensor | Behind Catalytic Converter |
| Powertrain Control Module | Left Side Of Engine Compartment, Under Air Cleaner |
| Pre-Converter Oxygen Sensor | Rear Of Engine, On Exhaust Manifold |
| Throttle Position Sensor | On Throttle Body |
| Vehicle Speed Sensor | Top Right Side Of Transaxle Output Housing |
COMPONENT LOCATIONS (3.5L VIN H - AURORA)
COMPONENT LOCATIONS (3.5L VIN H - INTRIGUE)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | Left Center Of Engine Compartment |
| Air Solenoid Valve | On Bracket, Mounted To Upper Engine Mount |
| A/T Fluid Pressure Valve Position Switch | Inside Transaxle |
| A/T Fluid Temperature Sensor | Inside Transaxle |
| A/T Input Speed Sensor | Inside Transaxle |
| Camshaft Position Sensor | Right Top Front Corner Of Engine, On Cam Carrier |
| Crankshaft Position Sensor | Left Rear Of Engine, Above Starter |
| Cruise Control Module | Left Side Of Engine Compartment, Near Strut Tower |
| Data Link Connector | Under Left Side Of Instrument Panel, Right Of Steering Column |
| EGR Valve | Top Right Rear Of Engine |
| Electronic Brake Traction Control Module | Left Rear Of Engine Compartment, On Master Cylinder |
| Engine Coolant Temperature Sensor | On Bank 2 Cylinder Head |
| Engine Oil Level Switch | Bottom Of Engine Oil Pan |
| Engine Oil Pressure Switch | Right Front Of Engine Block |
| EVAP Canister Purge Solenoid | Right Rear Top Of Engine |
| EVAP Canister Vent Solenoid | Behind Left Rear Fascia Splash Shield, In Wheelwell |
| Fuel Injectors | In Intake Manifold |
| Fuse Block | Right Side Of Instrument Panel, In Door Opening |
| Idle Air Control Valve | On Throttle Body |
| Ignition Control Modules | On Top Of Engine Valve Covers |
| Intake Air Temperature Sensor | In Air Cleaner Housing |
| Knock Sensor | On Left Front Of Engine, Above Starter |
| Manifold Absolute Pressure Sensor | Left Top Of Engine |
| Mass Airflow Sensor | In Engine Air Cleaner Duct |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Front Left Side Of Engine, Inside Of Air Cleaner Assembly |
| Pre-Converter Oxygen Sensor | Rear Of Engine, In Exhaust Manifold |
| Pressure Control Solenoid (A/T) | Inside Transaxle |
| Secondary Air Injection Pump | Near Left Headlight Assembly |
| TCC PWM Solenoid (A/T) | Inside Transaxle |
| Throttle Position Sensor | Top Left Of Engine, On Throttle Body |
| Transaxle Range Switch | On Top Left Of Automatic Transaxle |
| Underhood Junction Block | On Right Side Of Engine Compartment, On Strut Tower |
| Vehicle Speed Sensor | Right Rear Of Engine Compartment, On Transaxle |
| 1-2 Shift Solenoid (A/T) | Inside Transaxle |
| 2-3 Shift Solenoid (A/T) | Inside Transaxle |
COMPONENT LOCATIONS (3.5L VIN H - INTRIGUE)
COMPONENT LOCATIONS (3.8L VIN K & 1 - BONNEVILLE & LESABRE)
| Component | Location |
|---|---|
| A/C Compressor Clutch Relay | On Front Right Side Of Engine Compartment, In Underhood Junction Block |
| A/C Refrigerant Pressure Sensor | Front Side Of Engine, On A/C Line Behind A/C Compressor |
| Body Control Module | Under Right Side Of Instrument Panel |
| Camshaft Position Sensor | Right Side Of Engine, Below Water Pump |
| Crankshaft Position Sensor | Lower Right Side Of Engine, Behind Crankshaft Pulley |
| Cruise Control Module | Left Side Of Engine Compartment, On Left Strut Tower |
| Data Link Connector | Under Left Side Of Instrument Panel |
| EGR Valve | On Top Of Engine, Rear Of Intake Manifold |
| Electronic Brake Traction Control Module | Front Left Lower Corner Of Engine Compartment, Under Air Cleaner Housing |
| Engine Coolant Temperature Sensor | Left Front Of Engine, Under Thermostat Housing |
| Engine Cooling Fan Relays (High & Low) | Center Rear Of Engine Compartment, Below Left Junction Block |
| Engine Oil Level Switch | Front Of Engine, In Oil Pan |
| EVAP Canister Purge Solenoid | On Top Of Engine Front Of Intake Manifold |
| EVAP Canister Vent Solenoid | Left Front Corner Of Engine Compartment, On Top Of Vapor Canister |
| Fuel Injectors | In Intake Manifold |
| Fuel Tank Pressure Sensor | In Fuel Tank |
| Fuel Pump Relay | Under Left Side Of Rear Passenger Compartment Seat, In Fuse Block |
| Idle Air Control Valve | Left Of Engine, In Top Of Throttle Body |
| Ignition Control Module | Top Left Front Of Engine |
| Intake Air Temperature Sensor | On Top Of Air Intake Hose between Throttle Body & Air Cleaner Housing |
| Knock Sensor (Bank No. 1) | Front Of Engine, Above Starter |
| Knock Sensor (Bank No. 2) | Rear Of Engine |
| Left Instrument Panel Fuse Block | Left Side Of Instrument Panel |
| Manifold Absolute Pressure Sensor | Top Of Engine, Rear Of Intake Manifold |
| Mass Airflow Sensor | Top Right Side Of Engine, On Throttle Body |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Left Front Of Engine Compartment, In Air Cleaner Housing |
| Pre-Converter Oxygen Sensor | Front Of Engine, In Exhaust Manifold |
| Supercharger Boost Control Solenoid | Front Top Of Engine, Left Of Termostat Housing |
| Supercharger Bypass Valve Actuator | Front Top Of Engine, Left Of TPS |
| Throttle Position Sensor | Center Left Of Engine, On Throttle Body |
| Transaxle Range Switch | Left Side Of Transaxle, Below EGR Valve |
| Underhood Fuse Block | Front Right Side Of Engine Compartment |
| Vehicle Speed Sensor | Top Right Side Of Transaxle |
COMPONENT LOCATIONS (3.8L VIN K & 1 - BONNEVILLE & LESABRE)
COMPONENT LOCATIONS (3.8L VIN K - CAMARO & FIREBIRD)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | On A/C Evaporator Hose, Near Right Shock Tower |
| Body Control Module | Under Right Side Of Instrument Panel, Near Blower Motor |
| Camshaft Position Sensor | On Front of Engine, Below water pump |
| Crankshaft Position Sensor | On Front Of Engine, Next To Crankshaft |
| Data Link Connector | Under Instrument Panel, Right Of Steering Column |
| Electronic Brake Control Module | Mounted With Brake Pressure Modulator Valve, On Top Of Left Frame Rail |
| EGR Valve | On Top Left Front Side Of Engine |
| Engine Coolant Temperature Sensor | On Top Front Of Engine, Next To Throttle Body |
| Engine Oil Level Switch | On Lower Left Side Of Engine, On Oil Pan |
| EVAP Canister Purge Solenoid | On Right Side Of Engine, Next To Injector No. 2 |
| EVAP Canister Vent Solenoid | Top Right Of Engine, Part Of EVAP Canister |
| Fuel Injectors | In Intake Manifold |
| Fuel Pump Relay | In Left Front Of Engine Compartment, In Underhood Electrical Center |
| Instrument Panel Fuse Block | Behind Left Side Of Instrument Panel |
| Ignition Control Module | On Top Left Front Side Of Engine |
| Intake Air Temperature Sensor | On Air Duct, In Front Of Intake Manifold |
| Knock Sensors | On Top Of Engine Below Intake Manifold |
| Manifold Absolute Pressure Sensor | Mounted To Right Side Of Intake Manifold |
| Mass Airflow Sensor | On Air Duct, In Front Of Intake Manifold |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | In Engine Compartment, Behind Right Shock Tower |
| Pre-Converter Oxygen Sensors | In Right And Left Exhaust Manifolds |
| Throttle Actuator Control Module | On Accelerator Pedal Bracket |
| Transmission Range Switch | Under Center Console, At Base Of Shift Lever |
| Underhood Electrical Center | In Left Front Of Engine Compartment, In Front Of Wheelwell |
| Vehicle Speed Sensor | On Rear Left Side Of Transmission |
COMPONENT LOCATIONS (3.8L VIN K - CAMARO & FIREBIRD)
COMPONENT LOCATIONS (3.8L VIN K & 1 - GRAND PRIX)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | Left Side Of Engine Compartment, On Accumulator |
| Body Control Module | Below Left Side Of Instrument Panel, Left Of Steering Column |
| Camshaft Position Sensor | Right Side Of Engine, Below Intake Plenum |
| Crankshaft Position Sensor | Right Front Of Engine, Behind Harmonic Balancer |
| Cruise Control Module | Left Side Of Engine Compartment, Mounted On Strut Tower |
| Data Link Connector | Under Left Side Of Instrument Panel, Right Of Steering Column |
| EGR Valve | Upper Left Side Of Engine, Near Throttle Body |
| Electronic Brake Traction Control Module | Left Side Of Engine Compartment, On Strut Tower |
| Engine Coolant Temperature Sensor | Top Left Side Of Engine, Below Throttle Body |
| Engine Oil Level Switch | Front Of Engine, On Oil Pan |
| Engine Oil Pressure Switch | Lower Left Front Of Engine, Near Starter |
| EVAP Canister Purge Solenoid | At Top Rear Of Engine, On Intake Manifold, Near Fuel Injectors |
| EVAP Canister Vent Solenoid | Behind Left Rear Fascia Splash Shield, In Wheelwell |
| Fuel Injectors | In Intake Manifold |
| Fuse Block | Behind Right Side Of Instrument Panel |
| Idle Air Control Valve | Top Of Engine, On Front Of Throttle Body |
| Ignition Control Module | Top Right Of Engine |
| Intake Air Temperature Sensor | Left Front Of Engine Compartment, In Air Intake Duct |
| Knock Sensor (Bank No. 1) | On Front Of Engine, Above Starter |
| Knock Sensor (Bank No. 2) | On Rear Of Engine, Below Exhaust Manifold |
| Manifold Absolute Pressure Sensor (VIN K) | Top Right Side Of Intake Manifold |
| Manifold Absolute Pressure Sensor (VIN 1) | Top Rear Of Engine, Near Fuel Injectors |
| Mass Airflow Sensor | On Left Front Of Engine, Part Of Throttle Body |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Left Side Of Engine Compartment, Inside Air Cleaner Assembly |
| Pre-Converter Oxygen Sensor | Rear Of Engine, In Exhaust Manifold |
| Supercharger Boost Control Solenoid | Top Front Of Engine, Near Fuel Injectors |
| Supercharger Bypass Valve Actuator | Front Top Of Engine, Left Of TPS |
| Throttle Position Sensor | Top Of Engine, On Throttle Body |
| Transaxle Range Switch | Left Rear Of Engine Compartment, On Transaxle |
| Underhood Junction Block | Right Side Of Engine Compartment, Mounted To Strut Tower |
| Vehicle Speed Sensor | Right Rear Of Engine Compartment, In Transaxle |
COMPONENT LOCATIONS (3.8L VIN K & 1 - GRAND PRIX)
COMPONENT LOCATIONS (3.8L VIN K - IMPALA & MONTE CARLO)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | Left Side Of Engine Compartment, On Liquid Line, Forward Of Strut Tower |
| Camshaft Position Sensor | Right Side Of Engine, Above Crankshaft Pulley |
| Crankshaft Position Sensor | Right Front Of Engine, Behind Crankshaft Pulley |
| Cruise Control Module | Left Side Of Engine Compartment, Near Strut Tower |
| Data Link Connector | Under Instrument Panel, Right Of Steering Column |
| EGR Valve | Top Left Rear Of Engine |
| Engine Coolant Temperature Sensor | Top Left Side Of Engine |
| Engine Oil Level Switch | Front Center Of Engine Oil Pan |
| Engine Oil Pressure Switch | Right Rear Of Engine, Above Oil Filter Adapter |
| EVAP Canister Purge Solenoid | Top Front Of Engine, Near Center Of Upper Intake Plenum |
| EVAP Canister Vent Solenoid | Behind Left Side Of Rear Fascia Splash Shield In Wheelwell |
| Fuel Injectors | In Intake Manifold |
| Fuse Block | Behind Instrument Panel, Right Of Steering Column |
| Idle Air Control Valve | Top Of Engine, Top Front Of Throttle Body Assembly |
| Ignition Control Module | Top Right Front Of Engine, Below Ignition Coils |
| Intake Air Temperature Sensor | Left Front Of Engine Compartment, On Air Intake Duct |
| Knock Sensor (Bank No. 1) | Front Of Engine, Above Starter |
| Knock Sensor (Bank No. 2) | Lower Right Rear Of Engine, Below Exhaust Manifold |
| Manifold Absolute Pressure Sensor | Top Of Engine, Right Of Upper Intake Plenum |
| Mass Airflow Sensor | Left Top Of Engine, On Top Of Throttle Body |
| Pre-Converter Oxygen Sensor | Rear Of Engine, In Exhaust Manifold |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Left Side Of Engine Compartment, Forward Of Strut Tower, Inside Air Filter |
| Theft Deterrent Module | Behind Right Side Of Instrument Panel |
| Throttle Position Sensor | Top Of Engine, On Throttle Body |
| Transaxle Range Switch | Inside Automatic Transaxle |
| Underhood Junction Block | Right Side Of Engine Compartment, Forward Of Strut Tower |
| Vehicle Speed Sensor | Right Rear Of Engine, On Transaxle |
COMPONENT LOCATIONS (3.8L VIN K - IMPALA & MONTE CARLO)
COMPONENT LOCATIONS (3.8L VIN K & 1 - PARK AVENUE)
| Component | Location |
|---|---|
| A/C Compressor Clutch Relay | On Front Right Side Of Engine Compartment, In Underhood Junction Block |
| A/C Refrigerant Pressure Sensor | On Right Front Side Of Engine, Near A/C Compressor, On Hose Assembly |
| Body Control Module | Under Right Side Of Instrument Panel |
| Camshaft Position Sensor | Right Side Of Engine, Below Water Pump |
| Crankshaft Position Sensor | Lower Right Side Of Engine, Behind Crankshaft Pulley |
| Cruise Control Module | In Center Rear Of Engine Compartment, Near Power Brake Master Cylinder |
| Data Link Connector | Under Left Side Of Instrument Panel |
| EGR Valve | On Left Rear Corner Of Engine, Near Throttle Body |
| Electronic Brake Traction Control Module | In Left Front Of Engine Compartment, Near Base Of Radiator Support |
| Engine Coolant Temperature Sensor | Left Front Of Engine, Near Thermostat Housing |
| Engine Oil Level Switch | Front Of Engine, In Oil Pan |
| Engine Oil Pressure Switch | On Right Rear Corner Of Engine, Below Power Steering Pump |
| EVAP Canister Purge Solenoid | On Right Rear Of Engine, Near Generator |
| EVAP Canister Vent Solenoid | In Left Rear Corner of Vehicle, Under Rear Compartment |
| Fuel Injectors | In Intake Manifold |
| Fuel Tank Pressure Sensor | In Fuel Tank |
| Fuel Pump Relay | Under Left Side Of Rear Passenger Compartment Seat, In Fuse Block |
| Idle Air Control Valve | Left Of Engine, In Top Of Throttle Body |
| Ignition Control Module | On Right Top Of Engine, Under Ignition Coils |
| Intake Air Temperature Sensor | Left Front Of Engine Compartment, In Air Intake Duct |
| Knock Sensor (Bank No. 1) | Front Of Engine, Above Starter |
| Knock Sensor (Bank No. 2) | Rear Of Engine, Under Exhaust Manifold |
| Left Instrument Panel Fuse Block | Under Right Side Of Instrument Panel |
| Manifold Absolute Pressure Sensor | Left Rear Of Engine, Near EGR Valve |
| Mass Airflow Sensor | On Center Left Of Engine, On Top Of Throttle Body |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Left Front Of Engine Compartment, In Air Cleaner Housing |
| Pre-Converter Oxygen Sensor | Rear Of Engine, In Exhaust Manifold |
| Right Instrument Panel Fuse Block | Right Side Of Instrument Panel |
| Supercharger Boost Control Solenoid | On Top Right Rear Side Of Engine, Right Of Thermostat Housing |
| Supercharger Bypass Valve Actuator | On Front Top Of Engine, Left Of TPS |
| Theft Deterrent Module | In Left Front Of Passenger Compartment, In Steering Column |
| Throttle Position Sensor | Left Side Of Engine, On Throttle Body |
| Transaxle Range Switch | Inside Transaxle |
| Underhood Fuse Block | Front Right Side Of Engine Compartment |
| Vehicle Speed Sensor | Right Rear Of Transaxle, Below Power Steering Pump |
COMPONENT LOCATIONS (3.8L VIN K & 1 - PARK AVENUE)
COMPONENT LOCATIONS (3.8L VIN K & 1 - REGAL)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | Left Side Of Engine Compartment, On Liquid Line, Forward of Strut Tower |
| Camshaft Position Sensor | Right Side Of Engine, Above Crankshaft Pulley |
| Crankshaft Position Sensor | Right Front Of Engine, Behind Harmonic Balancer |
| Cruise Control Module | Left Side Of Engine Compartment, Mounted On Strut Tower |
| Data Link Connector | Under Left Side Of Instrument Panel, Right Of Steering Column |
| EGR Valve | Left Rear Top Of Engine |
| Electronic Brake Traction Control Module | Left Rear Of Engine Compartment, On Left Strut Tower |
| Engine Coolant Temperature Sensor | Left Side Of Engine, Below Thermostat Outlet |
| Engine Oil Level Switch | Front Of Engine, In Center Of Oil Pan |
| Engine Oil Pressure Switch | Lower Right Rear Of Engine, Above Transaxle |
| EVAP Canister Purge Solenoid (VIN K) | Top Of Engine, Near Center Of Valve Cover |
| EVAP Canister Purge Solenoid (VIN 1) | Rear Top of Engine, Near Center Of Valve Cover |
| EVAP Canister Vent Solenoid | Behind Left Side Of Rear Fascia Splash Shield In Wheelwell |
| Fuel Injectors | In Intake Manifold |
| Fuse Block | Right Side Of Instrument Panel, In Door Opening |
| Idle Air Control Valve | Top Of Engine, Top Front Of Throttle Body |
| Ignition Control Module | Top Right Front Of Engine |
| Intake Air Temperature Sensor | Left Front Of Engine Compartment, In Air Intake Duct |
| Knock Sensor (Bank No, 1) | On Front Of Engine, Above Starter |
| Knock Sensor (Bank No. 2) | On Rear Of Engine, Below Exhaust Manifold |
| Manifold Absolute Pressure Sensor (VIN K) | Top Of Engine, Right of Upper Intake Plenum |
| Mass Airflow Sensor | Left Front Of Engine, Part Of Throttle Body Assembly |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Front Left Side Of Engine, Inside Air Cleaner Assembly |
| Pre-Converter Oxygen Sensor | Rear Of Engine, In Exhaust Manifold |
| Supercharger Boost Control Solenoid | Top Left Of Engine, Above Valve Cover |
| Supercharger Bypass Valve Acuator | On Front Top Of Engine, Left Of TPS |
| Throttle Position Sensor | Top Of Engine, On Throttle Body |
| Transaxle Range Switch | Left Of Engine, On Transaxle |
| Underhood Junction Block | Right Side Of Engine Compartment, Mounted To Strut Tower |
| Vehicle Speed Sensor | Behind Engine, On Top Right End Of Automatic Transaxle |
COMPONENT LOCATIONS (3.8L VIN K & 1 - REGAL)
COMPONENT LOCATIONS (4.0L VIN C - AURORA)
| Component | Location |
|---|---|
| Camshaft Position Sensor | On Front Of Right Cylinder Head |
| Crankshaft Position Sensor "A" & "B" | Lower Left Side Of Engine Near Oil Filter |
| Engine Coolant Temperature Sensor | Left Rear Of Engine, Below EGR Mount |
| Engine Oil Level Switch | Front Of Oil Pan |
| Engine Oil Pressure Sensor | Right Front Side Of Engine, Near Oil Filter Housing |
| EVAP Canister Purge Solenoid | On Top Of Engine, At Rear Of Throttle Body |
| Exhaust Gas Recirculation Valve | On Top Of Engine, Rear Of Intake Manifold |
| Fuel Sender | Top Of Fuel Tank |
| Fuel Tank Pressure Sensor | Under Fuel Sensor Access Panel |
| Idle Air Control Valve | On Top Of Engine, At Front Of Throttle Body |
| Ignition Control Module (Right & Left) | Top Of Right & Left Cam Covers |
| Knock Sensor | On Engine, Beneath Intake Manifold |
| Manifold Absolute Pressure Sensor | Top Rear Of Engine, At Rear of Intake Manifold |
| Mass Airflow Sensor | On Left Side Of Engine Compartment, Attached To Throttle Body Intake Air Duct |
| Post-Converter Oxygen Sensor | On Exhaust Pipe Behind Catalytic Converter |
| Powertrain Control Module | Left Side Of Engine Compartment, Under Air Cleaner |
| Pre-Converter Oxygen Sensors | In Front & Rear Exhaust Manifolds |
| Throttle Position Sensor | On Top Right Side Of Engine, Near Throttle Body |
| Vehicle Speed Sensor | Top Right Side Of Transaxle Output Housing |
COMPONENT LOCATIONS (4.0L VIN C - AURORA)
COMPONENT LOCATIONS (4.6L VIN Y & 9 - DEVILLE, ELDORADO & SEVILLE)
| Component | Location |
|---|---|
| Camshaft Position Sensor | Right Rear Of Engine, In Cam Carrier |
| Cooling Fan Relays | Rearward Of Radiator, Center Bottom Between Cooling Fans |
| Crankshaft Position Sensors | Front Center Of Engine |
| Cruise Control Module | Left Side Of Engine Compartment, On Left Strut Tower |
| Data Link Connector | Under Instrument Panel, Near Steering Column |
| EGR Valve | Left Rear Of Engine, Behind Throttle Body |
| Engine Coolant Temperature Sensor | Left Rear Corner Of Engine, Below EGR Valve |
| Engine Oil Level Switch | Bottom Front Of Engine, Near A/C Compressor |
| Engine Oil Pressure Switch | Front Center Of Engine, Near Top Of Oil Filter |
| EVAP Canister Purge Solenoid | Left Rear Of Engine, Next To Throttle Body |
| EVAP Canister Vent Solenoid | Beneath Rear Compartment, On Left Side Of Vehicle |
| Fuel Injectors | In Intake Manifold |
| Idle Air Control Valve | Left Side Of Engine, In Front Of Throttle Body |
| Ignition Control Modules | Under Intake Manifold Top Cover, On Front & Rear Camshaft Covers |
| Intake Air Temperature Sensor | In MAF Sensor |
| Knock Sensor | Center Top Of Engine, Under Intake Manifold Top Cover |
| Manifold Absolute Pressure Sensor | Top Left Side Of Engine, On Throttle Body |
| Mass Airflow Sensor | Left Side Of Engine Compartment, In Air Intake Tube |
| Post-Converter Oxygen Sensor | Rear Of Catalytic Converter |
| Powertrain Control Module | Left Front Of Engine Compartment, Under Air Cleaner Assembly |
| Pre-Converter Oxygen Sensors | Center Front And Rear Of Engine Compartment, On Front And Rear Exhaust Manifold |
| Rear Oxygen Sensor | Center Rear Of Engine, In Exhaust Manifold |
| Throttle Position Sensor | Top Left Side Of Engine, On Throttle Body |
| Transaxle Range Switch | Inside Transaxle |
| Underhood Junction Block | In Engine Compartment, Forward Of Left Strut Tower |
| Vehicle Speed Sensor | Right Center Of Engine Compartment, On Transaxle Case Extension |
COMPONENT LOCATIONS (4.6L VIN Y & 9 - DEVILLE, ELDORADO & SEVILLE)
COMPONENT LOCATIONS (5.7L VIN G - CAMARO & FIREBIRD)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | On A/C Evaporator Hose Near Right Shock Tower |
| A/C Compressor Clutch Relay | In Left Front Corner Of Engine Compartment, In Underhood Electrical Center |
| Air Pump Relay | In Left Front Corner Of Engine Compartment, In Underhood Electrical Center |
| Air Solenoid Relay | In Left Front Corner Of Engine Compartment, In Underhood Electrical Center |
| Body Control Module | Under Right Side Of Instrument Panel, Near Blower Motor |
| Camshaft Position Sensor | Mounted In Top Rear Center Of Engine |
| Crankshaft Position Sensor | Lower Right Side Of Engine, Behind Starter |
| Cruise Control Module | At Front Left Frame, In Front Of Wheelwell |
| Data Link Connector | Under Instrument Panel, Right Of Steering Column |
| Electronic Brake Control Module | Mounted On Top Of Left Front Frame Rail, With Brake Pressure Modulator Valve |
| Engine Coolant Temperature Sensor | On Lower Left Side Of Engine, Above Generator |
| Engine Cooling Fan Relay | In Left Front Corner Of Engine Compartment, In Underhood Electrical Center |
| Engine Oil Level Switch | On Lower Right Side Of Engine, In Oil Pan |
| EVAP Canister Purge Solenoid | On Left Side Of Engine, Mounted To Intake Manifold |
| EVAP Canister Vent Solenoid | On Top Of Fuel Tank, Part Of EVAP Canister |
| Fuel Injectors | In Intake Manifold |
| Fuel Pump Relay | In Left Front Corner Of Engine Compartment, In Underhood Electrical Center |
| Idle Air Control Valve | On Right Front Of Engine, On Throttle Body |
| Ignition Coil | On Valve Cover At Top Of Each Cylinder |
| Ignition Control Module | On Valve Cover At Top Of Each Cylinder |
| Inflatable Restraint Sensing & Diagnostic Module | On Floor Tunnel, Below Rear Of Console |
| Instrument Panel Fuse Block | Behind Left Side Of Instrument Panel |
| Intake Air Temperature Sensor | On Air Duct, In Front Of Intake Manifold |
| Knock Sensors | On Center Of Engine, Below Intake Manifold |
| Manifold Absolute Pressure Sensor | On Top Rear Center Of Engine |
| Mass Airflow Sensor | On Air Duct, In Front Of Intake Manifold |
| Post-Converter Oxygen Sensors | Rear Of Catalytic Converter |
| Powertrain Control Module | On Right Side Of Engine Compartment, Rear Of Wheelwell |
| Pre-Converter Oxygen Sensors | Rear Of Engine, In Exhaust Manifold |
| Reverse Lock-Out Solenoid | On Rear Left Side Of Transmission |
| Secondary Air Injection Pump Motor | On Front Left Frame Rail, In Engine Compartment |
| Skip Shift Solenoid | On Center Left Side Of Transmission |
| Star Connector | Under Left Side Of Instrument Panel, Near DLC |
| Throttle Position Sensor | Mounted On Left Side Of Throttle Body |
| Underhood Electrical Centers | In Left Front Corner Of Engine Compartment |
| Vehicle Speed Sensor (A/T) | On Left Rear Side Of Transmission |
COMPONENT LOCATIONS (5.7L VIN G - CAMARO & FIREBIRD)
COMPONENT LOCATIONS (5.7L VIN G - CORVETTE)
| Component | Location |
|---|---|
| A/C Refrigerant Pressure Sensor | Attached To A/C High Side Line |
| Body Control Module | Mounted On Toe Board |
| Cooling Fan Relays | In Right Side Of Engine Compartment, In Underhood Electrical Center |
| Data Link Connector | Under Left Side Of Instrument Panel |
| Engine Coolant Temperature Sensor | Left Side Of Engine, Below Generator |
| Engine Oil Level Switch | Right Side Of Oil Pan |
| Engine Oil Pressure Sensor | Top Center, Rear Of Engine |
| EVAP Canister Purge Solenoid | At Left Side Of Engine, On Intake Manifold |
| EVAP Canister Vent Solenoid | Right Side Rear Compartment Brace, Inside Rear wheelwell Panel |
| Fuel Injectors | In Intake Manifold |
| Ignition Control Modules | On Valve Cover At Top Of Each Cylinder |
| Intake Air Temperature Sensor | Part Of MAF Sensor |
| Knock Sensors | Center Of Engine, Below Intake Manifold |
| Manifold Absolute Pressure Sensor | Rear Of Intake Manifold |
| Mass Airflow Sensor | In Intake Duct Before Air Filter Assembly |
| Post-Converter Oxygen Sensors | Rear Of Catalytic Converters |
| Powertrain Control Module | On Right Side Of Engine Compartment, Rear Of Wheelwell |
| Pre-Converter Oxygen Sensors | Rear Of Engine, In Exhaust Manifolds |
| Throttle Actuator Control Module | Mounted On Side Of Powertrain Control Module, Below Battery |
| Throttle Actuator Motor | Left Side Of Throttle Body |
| Throttle Position Sensor | On Throttle Body |
| Transaxle Range Switch | Left Side Of Transmission |
| Underhood Electrical Center | Right Side Of Engine Compartment, Between Wheelwell & Instrument Panel |
| Vehicle Speed Sensor | At Top Right Of Differential |
COMPONENT LOCATIONS (5.7L VIN G - CORVETTE)
