Electronic suspension — Computer command ride Pontiac Bonneville IX

Components on these wiring diagrams 35

Click a component to highlight it on every diagram it appears on.

• Abs/Ccr/Elc
• Computer Command Ride Control Module
• Data Link Connector
• Diagnostic Test In
• Diagnostic Test Out
• Driver Shift Select Switch
• Ground
• Ground Ppl Ground
• I/P Fuse Block
• Junction Connector
• Lateral Accel Sw In
• Lateral Accel Sw Out Ppl Wot Input
• Lateral Acceleration Switch
• Left Front Strut Sensor
• Left Rear Strut Sensor
• Lf Motor Drive
• Lf Position In
• Lf Position Output
• Lr Motor Drive
• Lr Position In
• Lr Position Output
• Powertrain Control Module
• Rf Motor Drive
• Rf Position In
• Rf Position Output
• Right Front Strut Sensor
• Right Rear Strut Sensor
• Rr Motor Drive
• Rr Position In
• Rr Position Output
• Switch 2
• Switch 3
• Vehicle Speed Input
• Vehicle Speed Output
• Wot/Brake Control
