Wiper System & Washer System: Specifications Pontiac Aztek I

Wiper/washer Systems 12 illustrations

Specifications

ApplicationSpecification
MetricEnglish
Rear Wiper Arm Nut25 N.m18 lb ft
Rear Wiper Motor Screws6 N.m53 lb in
Washer Solvent Container Screws10 N.m89 lb in
Wiper Arm Nut48 N.m35 lb ft
Wiper Motor Cover Screws3 N.m27 lb in
Wiper System Drive Module Bolts9 N.m80 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Schematic and Routing Diagrams
Scheme 1: Schematic and Routing Diagrams

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Wiper/Washer System Component Views
Scheme 3: Wiper/Washer System Component Views

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6: Wiper/Washer System Connector End Views
Scheme 6: Wiper/Washer System Connector End Views

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
