Engine Controls - System & Component Testing: Component Locations Pontiac Aztek I

Testing & Diagnostics 11 illustrations

COMPONENT LOCATIONS

Note. For component locations, refer to COMPONENT LOCATIONS table or illustrations. (Scheme 14)- (Scheme 24).

ComponentLocation
Body Control ModuleInside Center Console, Above Fuse Block
Camshaft Position SensorRight Side Of Engine, Above A/C Compressor Clutch
Crankshaft Position Sensor (7x)Lower Rear Of Engine
Crankshaft Position Sensor (24x)Right Front Side Of Engine, Behind Harmonic Balancer
Data Link ConnectorBelow Steering Column, Bottom Of Knee Bolster
Engine Coolant Temperature SensorTop Left Of Engine
Engine Oil Level SwitchRight Side Of Engine Oil Pan
Engine Oil Pressure Indicator SwitchFront Of Engine, Above Starter
EVAP Canister Purge SolenoidTop Rear Of Engine, Between EGR Valve & Throttle Body Assembly
EVAP Canister Vent SolenoidBelow Center Of Vehicle, Near Fuel Tank
Exhaust Gas Recirculation ValveTop Left Side Of Engine, Left Of Manifold
Fuel InjectorsTop Of Engine, At Each Cylinder Intake Port
Fuel Pump RelayIn Underhood Fuse Block
Fuel Tank Pressure SensorInside Fuel Tank
Heated Oxygen Sensor No. 1Rear Of Engine, In Exhaust Manifold
Heated Oxygen Sensor No. 2In Exhaust System, Rear Of Catalytic Converter
Idle Air Control ValveTop Of Engine, Top Of Throttle Body
Ignition Control ModuleTop Center Rear Of Engine
Intake Air Temperature SensorLeft Side Of Engine Compartment, On Air Intake Duct, Near Throttle Body
Knock SensorFront Of Engine, Above Starter
Manifold Absolute Pressure SensorRight Top Of Engine
Mass Airflow SensorIn Air Cleaner Duct, Left Front Side Of Engine Compartment
Powertrain Control ModuleEngine Compartment, Secured In Air Cleaner Assembly
Secondary AIR Injection PumpFront Of Vehicle, Behind Left Fog Light, Below Horn
Secondary AIR Injection SolenoidLower Rear Of Engine
Throttle Position SensorTop Of Engine, On Rear Side Of Throttle Assembly
Vehicle Speed SensorLower Right Rear Of Engine Compartment, Mounted To Right Side Of Transaxle

COMPONENT LOCATIONS

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 24
