Frame and Underbody: Other Pontiac Aztek I

Tools Required

J 45296 Frame Insulator Remover/Installer

Scheme 38

Scheme 39

1. Raise and support the vehicle. Refer to LIFTING AND JACKING THE VEHICLE in General Information.
2. Disconnect the steering intermediate shaft. Refer to INTERMEDIATE STEERING SHAFT REPLACEMENT in Steering Wheel and Column.
3. Install a jackstand under the center of the frame, between the front frame insulators.
4. Remove the front frame bolts and retainers.
5. Lower the front of the frame.
6. Remove the frame front upper insulators.
7. Install the J 45296 to the front frame insulator you are removing.
8. Using J 45296, remove the front frame insulator from the frame.

Scheme 40

Scheme 41

1. Clean the front frame insulator opening.
2. Apply a thin coat of rubber lubricant GM P/N 1051717, Canadian P/N 5728223, or equivalent to the inside of the front frame insulator opening.
3. Apply a thin coat of rubber lubricant GM P/N 1051717, Canadian P/N 5728223, or equivalent to the front frame insulator.
4. Align the front frame insulator to the front frame opening with the front frame alignment tabs facing to the front.
5. Using J 45296, install the front frame insulator to the front frame.
6. Install the frame front upper insulators.
7. Raise the front of the frame. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) .
8. Install the front frame bolts and retainers. Tighten Tighten the front frame bolts to 150 N.m (111 lb ft).
9. Remove the jackstand.
10. Connect the steering intermediate shaft. Refer to INTERMEDIATE STEERING SHAFT REPLACEMENT in Steering Wheel and Column.
11. Lower the vehicle.
