Suspension Control System - Suspension Leveling: Specifications Pontiac Aztek I

Electronic Suspension 6 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Air Compressor Bracket to Body Bolts10 N.m89 lb in
Air Compressor Bracket to Body Nuts10 N.m89 lb in
Air Compressor to Bracket Bolts6 N.m53 lb in
Air Dryer Bracket Screw6 N.m53 lb in
Air Line Tube Repair Nut8 N.m70 lb in
Automatic Level Control Relay Bolt6 N.m53 lb in
Automatic Level Control Shield Bolt6 N.m53 lb in
Height Sensor Ball Stud4 N.m35 lb in
Height Sensor Bracket to Body Bolts85 N.m63 lb ft
Inflator Fill Valve Nut6 N.m53 lb in
Inflator Solenoid Screws6 N.m53 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Automatic Level Control Suspension Schematics
Scheme 1: Automatic Level Control Suspension Schematics

Scheme 2

Scheme 2: Automatic Level Control Suspension Component Views
Scheme 2: Automatic Level Control Suspension Component Views

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4: Automatic Level Control Suspension Connector End Views
Scheme 4: Automatic Level Control Suspension Connector End Views

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
