Fuses & Circuit Breakers Pontiac 6000 I

Fuses & Circuit Breakers 1 illustration ~1401 words

Scheme 2

Scheme 2: FUSE PANEL IDENTIFICATION (1983 6000)
Scheme 2: FUSE PANEL IDENTIFICATION (1983 6000)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp (Red) Diesel Engine Glow Plugs, Electronic Fuel Injection
  2. 2 - 10 Amp (Red) Fuel Pump (L4)
  3. 3 - 20 Amp (Yellow) Stoplights, Hazard Flasher, Audible Warning System
  4. 4 - 20 Amp (Yellow) Choke Heater, Coolant Fan, Warning Indicators
  5. 5 - 15 Amp (Light Blue) Turn Signal Flasher, Back-Up Lights
  6. 6 - 10 Amp (Red) Crank Signal To ECM
  7. 7 - 20 Amp (Yellow) Park, Side Marker, Tail, License Plate, Stoplights, Turn Signal Lights
  8. 8 - 25 Amp (White) Heater & Air Conditioner
  9. 9 - 10 Amp (Red) Gauges, Audible Warning System, Computer Command Control, Electronic Ride Control, BRAKE Warning Light, Torque Converter Clutch, Cruise Control
  10. 10 - 25 Amp (White) Windshield Wiper/Washer Motor
  11. 11 - 20 Amp (Yellow) Courtesy Light, Cigarette Lighter, Trunk Release, Horn, Interior Lights, Power Door Locks, Radio/Digital Clock, Display (ETR), Power Sport Mirrors, Electronic Ride Control
  12. 12 - 30 Amp (Circuit Breaker) Power Windows
  13. 13 - 5 Amp (Tan) Audible Warning System, Rear Window Defogger, Instrument Panel Lights, Radio Lights
  14. 14 - 10 Amp (Red) Radio
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats
  16. 16 - 10 Amp (Red) ECM (Computer Command Control)

FUSE PANEL IDENTIFICATION (1984 6000)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp (Red) Computer Command Control, Diesel Glow Plugs
  2. 2 - 10 Amp (Red) Fuel Pump Relay (Except STE), Oil Pressure Switch (L4), Cigarette Lighter (STE), Glove Box Light, Horn
  3. 3 - 20 Amp (Yellow) Stoplights, Hazard Flasher, Audible Warning System
  4. 4 - 20 Amp (Yellow) Choke Heater (V6)
  5. 5 - 15 Amp (Light Blue) Turn Signal Flasher, Back-Up Lights
  6. 6 - 10 Amp (Red) Crank Signal To ECM (Except STE), Air Conditioning Control Panel (STE)
  7. 7 - 20 Amp (Yellow) Taillights
  8. 8 - 25 Amp (White) Heater & Air Conditioner
  9. 9 - 10 Amp (Red) Gauges, Electronic Ride Control, Torque Converter Clutch Brake Switch, Air Conditioning Relay, Vehicle Speed Sensor, Electric Rear Window Defogger Switch
  10. 10 - 25 Amp (White) Windshield Wiper/Washer Motor
  11. 11 - 20 Amp (Yellow) Interior Lights, Cigarette Lighter (Except STE), Electric Trunk Release, Horn Relay (Except STE), Electronic Ride Control, Clock, Glove Box Light (Except STE), A/C Relay
  12. 12 - 30 Amp (Circuit Breaker) Power Windows
  13. 13 - 5 Amp (Tan) Instrument Panel Lights
  14. 14 - 10 Amp (Red) Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats
  16. 16 - Blank (Except STE); 10 Amp (Red) Electronic Instrument Cluster
  17. 17 - 10 Amp (Red) ECM (Computer Command Control)

FUSE PANEL IDENTIFICATION (1985-86 6000)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp (Red) (Except Diesel) Computer Command Control, ECM Ignition, Fuel Injection; 20 Amp (Yellow) (Diesel) Diesel Glow Plugs
  2. 2 - 10 Amp (Red) (Except STE) Fuel Pump Relay, Oil Pressure Switch (L4); 20 Amp (Yellow) (STE) Cigarette Lighter, Horn, Glove Box Light
  3. 3 - 20 Amp (Yellow) Stoplights, Hazard Flasher, Audible Warning System
  4. 4 - 20 Amp (Yellow)(Except Elec. I.P. Cluster) Choke Heater; 10 Amp (Red)(Electronic I.P. Cluster) Cooling Fan, I.P. Cluster, Electronics
  5. 5 - 15 Amp (Light Blue) Turn Signal Flasher, Back-Up Lights
  6. 6 - 10 Amp (Red) Crank Signal To ECM, Cold Start Injector
  7. 7 - 20 Amp (Yellow) Taillights
  8. 8 - 25 Amp (White) Heater & Air Conditioner
  9. 9 - 10 Amp (Red) Gauges, Electronic Ride Control, Torque Converter Clutch Brake Switch, Electric Rear Window Defogger Switch, Air Conditioning Relay, Vehicle Speed Sensor
  10. 10 - 25 Amp (White) Windshield Wiper/Washer Motor
  11. 11 - 20 Amp (Yellow) Interior Lights, Cigarette, Lighter (Except STE), Electric Trunk Release, Horn Relay (Except STE), Electronic Ride Control, Clock, Glove Box Light (Except STE), A/C Relay
  12. 12 - 30 Amp (Circuit Breaker) Power Windows, Rear Window Wiper/Washer (Wagon)
  13. 13 - 5 Amp (Tan) Instrument Panel Lights
  14. 14 - 10 Amp (Red) Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats
  16. 16 - 10 Amp (Red) Multi-Port Fuel Injection Engine Controls
  17. 17 - 10 Amp (Red) ECM - Computer Command Control (Except STE), Driver Information Center (STE)

FUSE PANEL IDENTIFICATION (1987-88 6000)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp (Red) Computer Command Control ECM Ignition, Fuel Injection
  2. 2 - 10 Amp (Red) Fuel Pump Relay, Oil Pressure Switch; 20 Amp (1987 STE) Cigarette Lighter, Glove Box Light, Horn Relay
  3. 3 - 20 Amp (Yellow) Stoplights, Hazard Flasher, Audible Warning System
  4. 4 - 20 Amp (Yellow)(Except Electronic I.P. Cluster) Choke Heater; 10 Amp (Red)(Electronic I.P. Cluster) Cooling Fan, I.P. Cluster Electronics
  5. 5 - 15 Amp (Light Blue) Turn Signal Flasher, Back-Up Lights
  6. 6 - 10 Amp (Red) Crank Signal To ECM, Cold Start Injector (1987)
  7. 7 - 20 Amp (Yellow) Taillights
  8. 8 - 25 Amp (White) Heater & Air Conditioner
  9. 9 - 10 Amp (Red) Gauges, Torque Converter Clutch Brake Switch, Electric Rear Window Defogger Switch, Air Conditioning Relay, Vehicle Speed Sensor Electronic Ride Control (1987)
  10. 10 - 25 Amp (White) Windshield Wiper/Washer Motor
  11. 11 - 20 Amp (Yellow) Interior Lights, Cigarette Lighter, Electric Trunk Release, Horn Relay, Clock, Glove Box Light, A/C Relay, Power Mirrors, Power Antenna Relay, Power Door Lock Relay, Electronic Ride Control (1987)
  12. 12 - 30 Amp (Circuit Breaker) Power Windows, Rear Window Wiper/Washer (Wagon), Power Sun Roof, Power Tailgate Release (Wagon)
  13. 13 - 5 Amp (Tan) Instrument Panel Lights
  14. 14 - 15 Amp Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats
  16. 16 - 10 Amp (Red)(Engine Code W) Multi-Port Fuel Injection Engine Controls
  17. 17 - 10 Amp (Red) ECM - Computer Command Control, Driver Information Center 1987)

FUSE PANEL IDENTIFICATION (1989 6000)

Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp (Blue) Computer Command Control ECM Ignition, Fuel Injection
  2. 2 - 20 Amp (Yellow) Lighter, Horn, ETR
  3. 3 - 10 Amp (Red) Engine Controls
  4. 4 - 10 Amp (Red) Cooling Fan
  5. 5 - 15 Amp (Light Blue) Turn Signal Flasher, Back-Up Lights
  6. 6 - 15 Amp (Light Blue) Foglights, ABS
  7. 7 - 20 Amp (Yellow) Taillights
  8. 8 - 25 Amp (White) Heater & Air Conditioner
  9. 9 - 10 Amp (Red) Gauges, Torque Converter Clutch Brake Switch, Electric Rear Window Defogger Switch, Air Conditioning Relay, Vehicle Speed Sensor
  10. 10 - 20 Amp (Yellow) Stop, Hazard, Audible Warning System
  11. 11 - 20 Amp (Yellow) Interior Lights, Cigarette Lighter Electric Trunk Release, Horn Relay, Clock, Glove Box Light, A/C Relay, Power Mirrors, Power Antenna Relay, Power Door Lock Relay
  12. 12 - 30 Amp (Circuit Breaker) Power Windows, Rear Window Wiper/Washer (Wagon), Power Sun Roof, Power Tailgate Release
  13. 13 - 5 Amp (Tan) Instrument Panel Lights
  14. 14 - 15 Amp Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats
  16. 16 - 25 Amp (White) Wiper
  17. 17 - 20 Amp (Yellow) I.P. Cluster Electronics

FUSE PANEL IDENTIFICATION (1990-91 6000)

Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp (1990) ECM Injectors, Direct Ignition System; 15 Amp (1991) ECM Control, MAF
  2. 2 - Blank (1990); 20 Amp (1991) Injector/Coil
  3. 3 - 10 Amp Engine Control, A/C Relay, EGR Solenoid, Canister Purge Solenoid, Diff./Lock Solenoid (1990)
  4. 4 - 10 Amp Electric Fan, Heater Resistor (1990), Generator, Daytime Running Lights Module, AWD Switch (1990)
  5. 5 - 15 Amp Turn Signals, Back-Up Lights, Trunk & Tailgate Release With Automatic Transaxle
  6. 6 - 15 Amp Fog Light Relay
  7. 7 - 20 Amp Taillights, Parking Lights, Side Marker Lights, License Lights, Stoplights, Turn Signals
  8. 8 - 25 Amp Heater & Air Conditioner
  9. 9 - 10 Amp Gauges, Warning Indicator, Torque Converter Clutch, Audible Warning System, Computer Command Control, Trunk Release, BRAKE Warning Light, Rear Window Defogger, Air Conditioning Relay (1990), Speedometer
  10. 10 - 20 Amp Stoplights, Hazard Flasher
  11. 11 - 20 Amp Interior Lights, Underhood Light, Ashtray, Courtesy Lights, Instrument Panel Lights, Trunk Light, Passive Restraint System, Deck-Lid Release, Door Locks, Horn, Automatic Leveling System, Power Antenna (1991)
  12. 12 - 30 Amp (Circuit Breaker) Tailgate Release, Power Windows, Rear Wiper/Washer
  13. 13 - 5 Amp Radio, Pod Lights, Ashtray, Console Light, Control Head - Heater & A/C, Defogger Switch, Headlight/Foglight Switch, AWD Switch (1990)
  14. 14 - 10 Amp Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Seats, Door Locks, Rear Wiper Motor, Rear Defogger
  16. 16 - 25 Amp Windshield Wiper/Washer
  17. 17 - Blank (1990); 20 Amp (1991) Cigarette Lighter

BATTERY

WARNINGWhen a battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN in the GENERAL INFORMATION section.

SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG SYSTEM)

WARNING(1990 Models Only) The Diagnostic Energy Reserve Module (DERM) can maintan enough voltage to cause a deployment of the Inflator Module for up to 10 minutes after the Ignition Switch is turned off and the battery is disconnected. Many of the service procedures require disconnection of the Inflator Module to avoid an accidental deployment.
