CONNECTOR IDENTIFICATION
Note. Circuit location may vary on some connectors.
| Connector | Figure | |
|---|---|---|
| A/C Compressor Relay | (Scheme 3) | |
| Auto Shutdown (ASD) Relay | (Scheme 4) | |
| Battery Temperature Sensor | (Scheme 5) | |
| Brakelight Switch | (Scheme 6) | |
| Camshaft Position (CMP) Sensor | (Scheme 7) | |
| Clockspring 2-Pin Speed Control Connector | (Scheme 8) | |
| Crankshaft Position (CKP) Sensor | (Scheme 9) | |
| Engine Coolant Temperature (ECT) Sensor | (Scheme 10) | |
| Evaporative Solenoid | (Scheme 11) | |
| Exhaust Gas Recirculation (EGR) Solenoid | (Scheme 12) | |
| Fuel Pump Motor | (Scheme 13) | |
| Fuel Pump Relay | (Scheme 14) | |
| Generator Field | (Scheme 15) | |
| Idle Air Control (IAC) Motor | (Scheme 16) | |
| Ignition Coil | (Scheme 17) | |
| Injector | (Scheme 18) | |
| Intake Air Temperature/Manifold | ||
| Absolute Pressure (IAT/MAP) | (Scheme 19) | |
| Knock Sensor | (Scheme 20) | |
| Leak Detection Pump Connector | (Scheme 21) | |
| O2S 1/2 Connector (Harness Side) | (Scheme 22) | |
| Park/Neutral Position Switch | (Scheme 23) | |
| Powertrain Control Module (PCM) | (Scheme 24) | |
| Radiator Fan Relay | (Scheme 25) | |
| Speed Control Servo | (Scheme 26) | |
| Throttle Position (TP) Sensor | (Scheme 27) | |
| Torque Converter Clutch (TCC) Solenoid | (Scheme 28) | |
| Transmission Range Sensor | (Scheme 29) | |
| Vehicle Speed Sensor (VSS) | (Scheme 30) | |
| 16-Pin Data Link Connector (DLC) | (Scheme 31) | |
CONNECTOR IDENTIFICATION DIRECTORY
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
TEST NS-7A - CHECKING IDLE AIR CONTROL MOTOR OPERATION
Note. Perform TEST NS-2A before proceeding.
- Hold throttle 1/4 depressed and attempt to start engine. If engine started and stayed running, go to next step. If engine did not start and stay running, go to TEST NS-8A.
- Release throttle and turn ignition off. Disconnect Idle Air Control (IAC) motor connector. Connect IAC motor connector to a known functional IAC motor. Turn ignition on. Using scan tool, actuate IAC motor. Observe tip of IAC motor. Go to next step.
- If IAC motor tip is moving in and out, replace original IAC motor. Perform TEST VER-1A. If IAC motor did not move in and out, check for other related IAC motor trouble codes. If other related IAC motor related trouble codes are present, repair as necessary. If no other related IAC trouble codes are present, replace Powertrain Control Module (PCM). Perform TEST VER-1A.
