Scheme 1
| CAUTION | If an electrical device stops working, ensure ignition switch and control switch are in the ON positions. If component still does not operate, check fuse that protects circuit. |
1 - 15 Amp
Cigarette Lighter (1990-94), Remote Controlled Mirror (1992).
2 - 10 Amp
Radio.
3 - 10 Amp
A/C Control Unit (1992), A/C Switch (1992), Blower Switch (1992), Power Window Relay (1992), Transistor Relay (1992) (Canada), Daytime Running Light Relay 2 (1992) (Canada), ABS Relay (1992), Heater Relay (1990-94), Defogger Relay (1991-94).
4 - 10 Amp
Automatic Seat Belt (1990-94), Headlight Pop-Up Switch (1991), Buzzer Assembly (1992), Foglight Relay (1992), Key Reminder Switch (1992) (USA).
5 - 10 Amp
Turn Signals (1990-94), Hazard Flasher Unit (1992).
6 - 10 Amp
Meters (1990-94), Auto-Cruise Control Unit (1992), Auto-Cruise Control Actuator (1992), Automatic Seat Belt Control Unit (1992), Buzzer Assembly (1992), Combination Meter (1992), Seat Belt Warning Light (1992).
7 - 10 Amp
Horn (1990-94), Headlight Relay (1991-94), Daytime Running Light Relay 1 (1992) (Canada).
8 - 15 Amp
Wiper (1990-94), Washer Motor (1992).
9 - 10 Amp
A/T Fluid Temperature Warning Light, 4-Speed Auto. Transaxle Control Unit (1990-94), Auto-Cruise Control Unit (A/T).
10 - 15 Amp
(Door Locks).
11 - 10 Amp
Dome Light, 4-Speed Auto. Transaxle Control Unit (1992), Door-Ajar Warning Light (1992), Foot Light (1992), Ignition Key Light (1992), Luggage Compartment Light (1992), MPI Control Unit (1992), Radio (1992), ABS Relay (1992), Automatic Seat Belt Control Unit (1992), ABS Control Unit (1992), Door Lock Control Unit (1992), Clock (1993-94).
12 - 10 Amp
Back-Up Lights, Dome Light Relay (1992).
13 - 15 Amp
Stoplights.
14 - 30 Amp
Heater (1990-94), Blower Motor (1992).
15 - Spare Fuse
Not Used.
