Controls
All control elements required for heating and air conditioning are located in the controls.
- Seat heating rotary switch
- Adjustment of air distribution
- Switch, heated rear screen
- AC switch
- Recirculating air switch
- Adjustment of fan speed (4-speed)
- Adjustment of air temperature
The coolant cut-off valve is activated when the air conditioning is switched on and set to maximum cooling, and the recirculating air function is deactivated for defrosting via micro-switches:
The air conditioning is standard equipment in the Zafira Elegance and is optionally available for all other equipment versions.
6.1.1 Controls Bulb Change: Detach Fan Speed Rotary Switch and Remove Bulb.
| I | Replace fan switch (1): |
|---|---|
| Unclip fan switch (arrows): When installing the switch, note unique position of rotary switches to avoid damaging the micro-switches (see Service Instructions). | |
| II | Adjustment of mixed air flap Bowden cable: |
| Air temperature rotary switch setting to maximum cold. Pull (toward vehicle interior) mixed air flap at air distribution housing with setting on cold. Clip on Bowden cable adjustment clip (2). |
