Pedal Position Sensor
| Measurement: | Plot of voltage at the signal output or the pedal position sensor. |
|---|---|
| Check Objective: | Check the electrical and mechanical operation. |
Preparation
Switch off the engine and ignition.
Connections
| INPUT A | COM/TRIGGER |
|---|---|
| Connect the red measurement lead to pin 1 of the connection plug on the pedal position sensor. Connect the ground lead to pin 4. |
Procedure
Switch on ignition.
Press the accelerator pedal once quickly down to the limit stop and then release it again.
Reference Curve
Fault Scheme 1
Symptoms:
Plot of signal is overlaid with interference spikes or has downward pointing disruption.
| Possible Causes | Countermeasures |
|---|---|
| Faulty pedal position sensor. | Replace pedal position sensor. |
