Injector (Multi-Point Fuel Injection)
| This multi-point fuel injection system is a conventional fuel injection system with a cut-off control system. In this case, the signal plot only has one voltage spike. | |
|---|---|
| Measurement: | Injector signal. |
| Check Objective: | Checking control and operation of the injector. |
Preparation
Engine oil temperature > 80 �C. Switch off all electrical loads. Switch off the engine and ignition.
Connections
| INPUT A | COM/TRIGGER |
|---|---|
| Connect the red measurement lead to the injector connection plug. | |
| Control lead colour: BRXX | |
| Except SINTRA: XXSW | |
| Connect ground lead to ground. |
Procedure
Start the engine and allow it to idle.
Reference Curve
Fault Scheme 1
Symptoms:
Injection period too short (> 4.5 ms).
| Possible Causes | Countermeasures |
|---|---|
| Exhaust too lean | Check Lambda sensor signal. |
| If ok, check and repair electronic engine system as specified in checking procedure. |
Fault Scheme 2
Symptoms:
Injection period too short (< 1.5 ms).
| Possible Causes | Countermeasures |
|---|---|
| Exhaust too rich | Check Lambda sensor signal. |
| If ok, check and repair electronic engine system as specified in checking procedure. |
