Block Diagram
| 30 | Battery Plus (Terminal 30) |
|---|---|
| 15 | Ignition ON (Terminal 15) |
| 31 | Ground (Terminal 31) |
| H28 | Telltale ABS |
| K50 | Control Unit ABS |
| K117 | Control Unit Immobiliser |
| P17 | Sensor Revolution, Front Left |
| P18 | Sensor Revolution, Front Right |
| P19 | Sensor Revolution, Rear Left |
| P20 | Sensor Revolution, Rear Right |
| S8 | Switch Brake Light |
| WSS | Vehicle Speed Signal |
| X13 | Diagnostic Link |
