Sliding Door Basic Setting Check Sliding Door Basic Setting:
- Remove rear right storage compartment (1)
- Check that the points (4) align with the marks on the casing.
Correct sliding door basic setting:
- Actuate tip switch (system operational)
- Manually open sliding door slightly, until square aperture (2) in sliding door module is free
- Insert suitable square bar (5) and leave inserted for following adjustment
- Insert hex (3)
- Turn hex anti-clockwise until left mark (4) aligns
- Remove square bar
- Manually open sliding door completely
- Manually close sliding door completely
- Manually open sliding door slightly, until square aperture (2) in sliding door module is free
- Check that both marks align
- If this is not the case, repeat steps 3 to 11
Initialisation of Electrical Sliding Door System
After a power interruption or a drop in the battery voltage below approx. 10 volts, the sliding door electrics must be reprogrammed:
- Close sliding door
- Ignition off
- Press tip switch (deactivate electrical actuation)
- Manually open sliding door completely
- Manually close sliding door completely
- Remove fuse F18
- Insert fuse F18 after approx. 30 seconds
- Approx. 10 seconds after reinserting fuse F18, reactivate electrical actuation (press tip switch)
- Open sliding door by pressing an actuation switch
- Close sliding door by pressing an actuation switch
- After approx. 5 seconds, repeat steps 9 and 10
