Performance Test
The performance test determines whether the temperature of outflowing air, low pressure and high pressure correspond to the specifications at a certain ambient temperature and engine speed.
- Connect service station to high and low pressure service connection.
The following conditions must be noted:
- Close windows and doors, carefully lower bonnet.
- Start engine and switch on AC.
- Set driver's and co�driver's pre�selected temperature to LO (max. cooling).
- Maximum fan setting (9), recirculating air switch OFF.
- All flaps 100% open
- Allow engine to run for 15 minutes at idle speed.
- After 15 minutes enter vehicle and after 5 minutes set engine speed to 1500 rpm.
Measure ambient temperature and temperature at ventilator nozzles with gauge TP�82 and compare with performance data (see Chapter 8.3).
Read low pressure and high pressure at service station and compare with performance data (see Chapter 8.3).
Service Connections for Performance Test
Low Pressure Service Connection (1)
25DT engine: cylinder head cover (4) bulkhead (3)
V6 engine: vacuum connection, brake servo (8) oil filler cap, cylinder head cover (7)
4-cyl. engine: spark plug connector (11) dipstick (12)
High Pressure Service Connection (2)
25DT engine: alternator (5) ribbed V-belt (6)
V6 engine: vacuum unit (9) radiator (10)
4-cyl. engine: tensioning roller (13) radiator (14)
Performance Data
| Ambient temperature | High pressure | Low pressure | Interior temperature (Air outflow from ventilator nozzles) | ||
|---|---|---|---|---|---|
| �C | kPa | bar | kPa | bar | �C |
| 15 | 800-1100 | 8-11 | 190-230 | 1.90-2.30 | 6-9 |
| 20 | 1200-1600 | 12-16 | 155-200 | 1.55-2.00 | 6-9 |
| 25 | 1450-2000 | 14.5-20 | 160-205 | 1.60-2.05 | 8-11 |
| 30 | 1400-1900 | 14-19 | 185-225 | 1.85-2.25 | 10-13 |
| 35 | 1600-1900 | 16-19 | 220-260 | 2.20-2.60 | 13-16 |
