Shock Absorber and Spring Assembly Replacement
| Callout | Component Name |
|---|---|
| Preliminary Procedures Remove the tires and wheels. Refer to Tire and Wheel Removal and Installation . Separate the rear adjustment link from the suspension knuckle. DO NOT loosen the adjustment jamb nut. Refer to Adjustment Link Replacement . | |
| 1 | Upper Shock Module Mounting Nut (Qty: 2) Notice: Refer to Fastener Notice in the Preface section. Tighten 47 N·m (35 lb ft) |
| 2 | Lower Shock Module Mounting Nut (Qty: 2) Tighten 28 N·m (21 lb ft) |
| 3 | Lower Shock Module Mounting Bolt |
| 4 | Shock Module Tip Remove the shock module toward the rear of the vehicle. |
