Recirculation Actuator Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the fuse labeled HVAC CTRL (BATT). Remove the instrument panel (I/P) carrier. Refer to Instrument Panel Carrier Replacement . |
| 1 | Recirculation Housing Screw (Qty: 4) Caution: Refer to Fastener Caution in the Preface section. Tighten 1.5 N·m (13 lb in) |
| 2 | Recirculation Housing |
| 3 | Recirculation Actuator Screw (Qty: 3) Tighten 1.5 N·m (13 lb in) |
| 4 | Recirculation Actuator Procedure • Disconnect the actuator electrical connector. • Recalibrate the actuator. Refer to Actuator Recalibration |
