The Flex Fix system is available as an option for the Corsa-D.
The Flex Fix system is located behind the rear axle and allows up to two adult bikes and one child's bike to be fitted outside the vehicle to a pull-out fastening bar which is incorporated into the vehicle floor.
The Flex Fix system has been designed in such a way that the user can set up the system and attach the bicycles in approx. three minutes.
Other mounting brackets, for example for skis or snowboards, are available as optional accessories for the carrier system.
When the Flex Fix system is not being used, it is located under the vehicle floor in the rear bumper and is not visible from outside.
Pull-out Flex Fix system fastening bar incorporated into the vehicle floor
Safety Instructions for the Flex Fix System
To pull out the Flex Fix system, the carrier system must be released using the lever (1). Once released, the Flex Fix system springs out of the rear bumper by about 15 cm .
Important: Therefore ensure that no one is in the vicinity of the carrier system when it is being pulled out, otherwise there is a risk of injury as a result of the carrier system extending quickly from the bumper.
The Flex Fix system must be pulled out fully by hand in the direction of the arrow until it audibly engages.
Flex Fix System Fastening Points
The Flex Fix system is fastened to the vehicle floor with four bolts. In addition to being bolted to the floor, the carrier system is also attached to a separate strut at the rear by means of two more bolts.
To remove the Flex Fix system, detach the rear bumper and the underbody guard to expose all the fastening points for the system.
The arrows indicate the position of the fastening points; the bolts are fastened from below.
