Replace Winter Program Pushbutton Switch (AF13-II) Opel Corsa D

Automatic Transmission Front Wheel Drive 4 illustrations

Remove

  1. 1. Unclip the selector lever bellows (2) and fold upward
  2. 2. Remove selector lever cover (1) • Unclip cover
  1. 3. Release wiring harness plug (1) and separate.
  2. 4. Unclip the selector display with the winter program switch (2) from the selector lever cover

Install

  1. 5. Clip the selector display with the winter program switch (2) into the selector lever cover
  2. 6. Connect and latch wiring harness plug (1)
  1. 7. Attach selector lever cover (1) • Clip in cover
  2. 8. Clip in the selector lever bellows (2)
