Engine System — Multec — wiring diagram (2007) Opel Corsa C

Components on these wiring diagrams 93

Click a component to highlight it on every diagram it appears on.

• 12 — Engine2
• 5 — Body, Rear, Left
• 5 — Volt Reference
• 8 — Chassis
• A/C — Compressor Clutch Relay Control
• A/C — Refrigerant Pressure Sensor Signal
• A40 — Ignition Coil - Direct Ignition
• A84A — Control Unit - Multec2
• Accelerator — Pedal Position Low Reference
• Accelerator — Pedal Position Signal
• Air — Conditioning
• Alternative — Fuel Switch Signal
• Alternative — Fuel Telltale Signal
• B18 — Sensor - Pressure, Air Conditioning
• B28 — Sensor - Camshaft
• B29 — Sensor - Pressure, Compressed Natural Gas
• B30 — Impulse Sensor - Crankshaft
• B39 — Sensor - Temperature, Coolant
• B41 — Sensor - Engine Oil Level
• B57 — Sensor - Oxygen, Catalytic Converter Check
• B64 — Sensor - Temperature, Intake Air
• B65 — Sensor - Knock Control
• B67 — Sensor - Absolute Pressure, Intake Manifold
• Camshaft — Position Sensor 5V Control
• Camshaft — Position Sensor Signal
• Check — Engine Indicator Control
• Clutch — Switch
• Cng — Injection Valves Fused Control2
• Cng — Tank Pressure Sensor Signal
• Cng — Tank Valve 1 Control
• Cng — Tank Valve 2 Control
• Cng — Tank Valve Control2
• Cooling — Fan Relay Coil Control
• Crankshaft — Sensor Low Reference
• Crankshaft — Sensor Signal
• Cruise — Control
• Cruise — Control Clutch Pedal Position Switch Signal
• Dlc — Class 2 Serial Data
• Electrical — Power Steering
• Engine — Coolant Temperature Sensor Signal
• Engine — Cooling
• Engine — Load Signal
• Engine — Main Relay Coil Control
• Engine — Z16Yng2
• Engine — Z16Yng, Multec S3
• Evap — Canister Purge Solenoid Control
• Fuel — Gauge Signal
• Fuel — Injector Control2
• Fuel — Level Data Signal
• Fuel — Pump
• Fuel — Pump Control
• Fuel — Pump Engine Z16Yng
• Fuel — Pump Primary Relay Control
• Fuel — Sender Low Reference
• Ground2
• High — Speed Cooling Fan Relay Control
• High — Speed Gmlan Serial Data
• Ignition — Control
• Immobiliser
• Injection — Valve Cng 1 Control
• Injection — Valve Cng 2 Control
• Injection — Valve Cng 3 Control
• Injection — Valve Cng 4 Control
• Intake — Air Temperature Sensor Signal
• K26 — Relay - Engine Control Unit
• K35 — Relay - Fuel Pump
• K89 — Relay - Compressed Natural Gas
• Knock — Sensor Signal
• Low — Speed Cooling Fan Relay Control
• Manifold — Absolute Pressure Sensor Low Reference
• Manifold — Absolute Pressure Sensor Signal
• Oil — Level Switch Signal
• Oil — Pressure Switch Signal
• Pedal — Position Sensor
• Powertrain — Main Relay Fused Supply
• Previous
• Relay — Fuel Mode Control
• Relay — Fuel Mode Gasoline Output Supply2
• S87 — Switch - Oil Pressure
• Signal — Ground2
• Stop — Lamp Control
• Stop — Lamp Switch
• Stop — Lamp Switch Signal
• Throttle — Actuator Control Close
• Throttle — Actuator Control Open
• Throttle — Position Sensor Low Reference
• Throttle — Position Sensor Signal
• Vehicle — Speed Signal
• X1 — Instrument Panel & Body Front
• X11 — Body Front & Blower
• X14 — Body Front & Body Rear, Left
• X18 — Body Front & Engine2
• Y57 — Solenoid Valve - Tank Ventilation
