Block Diagram, Engine Cooling Module Opel Corsa C

Cooling System 1 illustration ~118 words

Block Diagram for Engine Cooling Module

The fan for the engine cooling module of engines Z 10 XE and Z 12 XE has one speed. The fan of the engine cooling module of engines Z 14 XE, Y 17 DT and Y 17 DTL has two speeds and is switched at the first speed via a series resistor.

The fans are activated via relays that are installed in the central electrics module (relay box in engine compartment).

The coolant temperature is measured by just one coolant temperature sensor and analysed by the engine control unit. Depending on the coolant temperature, the radiator fan relays are activated.

10.8.1 Block Diagram for Engine Cooling Module

30Battery positive (terminal 30)
31Ground (terminal 31)
A84_AMotronic ME 1.5.5 control unit
A84_BMultec�S (F) control unit
A84_CMultec�S (F) control unit
A84_DDiesel control unit (EDC�ECD V5)
B39Coolant temperature sensor
F52Fuse
K30(1)Radiator fan relay
K30(2)Radiator fan relay
M7Radiator fan motor (pulling)
M27Radiator fan motor (pulling)
RSeries resistor for radiator fan motor
