Terminal Assignment Opel Corsa B

ABS 4 illustrations

Terminal Assignments

K50 ABS control unit terminal assignments:
Ter. 1Rear left wheel sensor ground connection
Ter. 2Rear left wheel sensor signal line
Ter. 3Front right wheel sensor ground connection
Ter. 5Front right wheel sensor signal line
Ter. 6Front left wheel sensor ground connection
Ter. 7Front left wheel sensor signal line
Ter. 8Rear left wheel sensor ground connection
Ter. 9Rear left wheel sensor signal line
Ter. 11Diagnostic data line
Ter. 14Brake light switch signal line
Ter. 15Ignition ON (terminal 15)
Ter. 16pump motor ground connection
Ter. 17Battery (Terminal 30)
Ter. 18Battery (Terminal 30)
Ter. 19Control unit ground connection
Ter. 21ABS telltale
X13 Diagnosis 16P
Ter. 4Battery Term. 31
Ter. 5Battery Term. 31
Ter. 12Diagnostic data line
K95 ABS control unit & TC
K31 Airbag control unit
Ter. 16Battery Term. 30
X17 instrument panel & Instrument 26P
Ter. 22H26 ABS telltale
Instrument panel X6 & front body 45P
Ter. 52Control unit ground connection
Ter. 63ABS telltale
Ter. 64Brake light switch signal line
Ter. 65Diagnostic data line
Ter. 67Rear left wheel sensor ground connection
Ter. 68Rear right wheel sensor signal line
Ter. 69Rear left wheel sensor signal line
Ter. 70Rear right wheel sensor ground connection
Ter. 71Terminal 15 (Ignition ON)
Ter. 78Battery (Terminal 30) only LHD
Ter. 79Battery (Terminal 30) only LHD
X7 instrument panel & rear body 50P
Ter. 24Rear left wheel sensor signal line
Ter. 25Rear right wheel sensor ground connection
Ter. 46Rear left wheel sensor ground connection
Ter. 47Rear right wheel sensor signal line
