Insert Radio Installation Frame Opel Agila A

Remove

1. 1. Remove radio • Insert removal bar KM-6067 until it engages in the aperture • Press both removal bars outwards and at the same time withdraw the radio from the holder.
2. 2. Remove radio, up to MY 2005

Note. Wiring harness plugs are clipped into the radio installation frame and are disconnected automatically when removing the radio.

3. 3. Remove radio, from MY 2005 • Release wiring harness plug (1) and disconnect • Disconnect aerial cable (2)

4. 4. Remove radio installation frame • Unscrew bolt (1) • Remove radio installation frame

Install

5. 5. Install radio installation frame • Insert radio installation frame – Tighten bolt
6. 6. Install radio, up to MY 2005 • Insert radio as far as the stop
7. 7. Install radio, from MY 2005 • Connect and lock wiring harness plug • Connect aerial cable
8. 8. Push radio in as far as the stop

Note. When inserting, push the wiring harness back as shown in the illustration to enable the radio to engage.

9. 9. Program volatile memories
