Oldsmobile Silhouette II (1996-2004) Anti-lock brake circuits

102 302 251 2050 BATTERY BATTERY GROUND GROUND ANTI-LOCK BRAKE IND BLK WIRE BLK/WHT WIRE BRAKE FLUID LEVEL SWITCH (ON RIGHT SIDE OF BRAKE FLUID RESERVOIR) BRAKE IND BRAKE PRESSURE MODULATOR VALVE BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (DLC) (BELOW STEERING COLUMN, ON KNEE BOLSTER) DELIVERED TORQUE DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (AT LOWER LEFT SIDE OF ENGINE COMPT) FUSIBLE LINK Y FUSIBLE LINK Z GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (RIGHT SIDE OF DASH) INSTRUMENT PANEL CLUSTER LEFT FRONT WHEEL SPEED SENSOR LEFT REAR WHEEL SPEED SENSOR LT BLU WIRE MULTI- FUNCTION SWITCH NCA WIRE ORG/ WIRE ORG/BLK WIRE PCM/ABS FUSE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (SECURED IN AIR CLEANER ASSEMBLY) PPL PUMP MOTOR REAR FOG LAMP/ TCS SWITCH RED WIRE RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR WHEEL SPEED SENSOR SERVICE TRACTION SYSTEM SPLICE PACK STOP LAMP SW OUT SERIAL DATA SIG DESIRED TORQUE STOPLAMP FUSE STOPLIGHT SWITCH (TOP OF BRAKE PEDAL SUPPORT) TAN WIRE TAN/BLK WIRE TRAC OFF IND TRACTION ACTIVE TRACTION CTRL ON/OFF SIG UNDERHOOD JUNCTION BLOCK VENT TUBE WHT WIRE YEL WIRE
