Air conditioning — Compressor circuit Oldsmobile Cutlass VI

Components on these wiring diagrams 17

Click a component to highlight it on every diagram it appears on.

• 2.4L L4
• 3.1L V6
• 5 Volts Sensor Signal
• A/C Bfc Fuse
• A/C Compressor Clutch
• A/C Compressor Clutch Diode
• A/C Compressor Clutch Relay
• A/C Refrigerant Pressure Sensor
• A/C Req
• Body Function Controller A/C Request Input
• Clutch Rly Ctrl
• Heater, A/C Control Assembly
• Left I/P Junction Block
• Powertrain Control Module
• Sensor — Ground
• Serial Data Cls 2
• Underhood Junction Block
