RIDING HEIGHT SPECIFICATIONS
Maximum variation between side-to-side and front-to-rear should not exceed .47" (12 mm).
| Application | (1) Front Dimension "A" In. (mm) | (2) Rear Dimension "B" In. (mm) |
|---|
| Cutlass & Malibu | 9.4 (238) | 9.6 (243) |
| (1) Location "A" is measured 31.5" (800 mm) from center of front axle. Dimension "A" is measured from floor to rocker panel. (Scheme 1) (2) Location "B" is measured 22.0" (560 mm) from center of rear axle. Dimension "B" is measured from floor to rocker panel. (Scheme 1) |
| (1) | Location "A" is measured 31.5" (800 mm) from center of front axle. Dimension "A" is measured from floor to rocker panel. (Scheme 1) |
| (2) | Location "B" is measured 22.0" (560 mm) from center of rear axle. Dimension "B" is measured from floor to rocker panel. (Scheme 1) |
RIDING HEIGHT SPECIFICATIONS
Scheme 1
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Strut-To-Steering Knuckle Nut | 133 (180) |
| Tie Rod End Lock Nut | 50 (68) |
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 0.2 | 1.2 To 0.8 |
| Rear | 0.40 | 0.9 To 0.10 |
| Caster (1) | 4.3 | 3.30 To 5.30 |
| Toe-In (1) |
| Front | 0.1 | 0.15 To 0.35 |
| Rear | 0 | 0.20 To 0.20 |
| Toe-In (2) |
| Front | 0.05 (1.5) | 0.07 To 0.17 (- 1.5 To 4.0) |
| Rear | 0 | 0.10 To 0.10 (- 2.5 To 2.5) |
| (1) Measurement is in degrees. (2) Measurement is in inches (mm). |
| (1) | Measurement is in degrees. |
| (2) | Measurement is in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS
