Maintenance Information: Component Locations Oldsmobile Cutlass VI

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

FUSE PANEL LOCATIONS

There are three fuse panel locations. There are two fuse panels located in the instrument panel. One is located on the right hand side of the instrument panel and the other is located on the left hand side. The third fuse panel is located in the engine compartment on the driver's side near the air cleaner.

Scheme 1

1. A - Radio
2. B - Wipers
3. C - Trunk Release & Remote Lock Control
4. D - Turn Signals
5. E - Power Mirrors
6. F - Air Bag
7. G - Body Function Control Module
8. H - Powertrain Control Module
9. J - Door Locks
10. K - Body Function Control Module, Cluster
11. STOP LPS - Stop Lamps
12. HAZARD LPS - Hazard Lamps
13. IPC/HVAC BATT - Cluster, Climate Control
14. MICRO RELAY TRUNK REL - Remote Trunk Release
15. CIRCUIT BRKR PWR SEATS - Power Seats
16. MICRO RELAY DR UNLOCK - Door Locks
17. MICRO RELAY DR LOCK - Door Locks
18. MICRO RELAY DRIVERS DR LOCK - Not Used

Scheme 2

1. A - Instrument Panel Lights, Dimmer
2. B - Cruise Control
3. C - Climate Control System
4. D - Cruise Control
5. E - Fog Lamps
6. F - Interior Lamps, Body Function Control Module
7. G - Radio
8. H - Sunroof
9. CIRCUIT BRKR PWR WINDOWS - Power Windows
10. MICRO RELAY FOG LPS - Fog Lamps

Scheme 3

Maxi-Fuses

1. 1 - Ignition Switch
2. 2 - Left Hand Electrical Center-Power Seats, Power Mirrors, Door Locks, Trunk Release & Remote Lock Control
3. 3 - Left Hand Electrical Center-Stop Lamps, Hazard Lamps, Body Function Control Module, Cluster, Climate Control System
4. 4 - Right Hand Electrical Center-Fog Lamps, Radio, Body Function Control Module, Interior Lamps
5. 5 - Ignition Switch
6. 6 - Not Used
7. 7 - Anti-Lock Brakes
8. 8 - Cooling Fans

Mini-Relays

1. 9 - Rear Defog
2. 10 - Not Used
3. 11 - Anti-Lock Brakes
4. 12 - Cooling Fan
5. 13 - HVAC Blower (Climate Control)
6. 14 - Cooling Fans
7. 15 - Cooling Fans

Micro-Relays

1. 16 - Air Conditioning Compressor
2. 17 - Not Used
3. 18 - Fuel Pump
4. 19 - Automatic Light Control
5. 20 - Automatic Light Control
6. 21 - Horn
7. 22 - Daytime Running Lamps

Mini-Fuses

1. 23-32 - Spare Fuse Holder
2. 33 - Rear Defog
3. 34 - Accessory Power Outlets, Cigar Lighter
4. 35 - Anti-Lock Brakes
5. 36 - Anti-Lock Brakes
6. 37 - Air Conditioning Compressor, Body Function Control Module
7. 38 - Automatic Transaxle
8. 39 - Powertrain Control Module, Ignition
9. 40 - Anti-Lock Brakes
10. 41 - Ignition System
11. 42 - Back-Up Lamps, Brake Transaxle Shift Interlock
12. 43 - Horn
13. 44 - Powertrain Control Module
14. 45 - Parking Lamps
15. 46 - Rear Defog, Daytime Running Lamps, Climate Control System
16. 47 - Canister Purge Valve, Powertrain Control Module, Exhaust Gas Recirculation, Heated O2 Sensor
17. 48 - Fuel Pump, Injectors
18. 49 - Generator
19. 50 - Right-Hand Headlamp
20. 51 - Left-Hand Headlamp
21. 52 - Cooling Fan
22. 53 - HVAC Blower (Climate Control)
23. 54 - Fuse Puller For Mini-Fuses
24. 55 - Tach Test Point for Diagnostic Testing
