Contents Section: Procedures All sections

Maintenance Information Oldsmobile Cutlass Supreme I

Procedures 19 illustrations ~2629 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 11

Scheme 11: VIN Code ID Explanation

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Severe Service

  1. Short Trips (4 Miles Or Less)
  2. Towing Or Heavily Loaded
  3. Severe Dust Conditions
  4. Hot Weather, Stop-And-Go Driving
  5. Extensive Idling Conditions (Taxi Or Delivery Type Service)

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Severe Service Operating Conditions

CAMSHAFT TIMING BELT REPLACEMENT INFORMATION (1991-96 3.4L)

CAUTIONFailure to replace a faulty camshaft timing belt may result in serious engine damage.

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

  1. Cracks Or Tears In Belt Surface
  2. Missing, Damaged, Cracked Or Rounded Teeth
  3. Oil Contamination
  4. Damaged Or Faulty Tensioners
  5. Incorrect Tension Adjustment

Scheme 12

Scheme 12: SERVICE POINT LOCATIONS

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Note. For more information regarding camshaft timing belt service refer to the 3.4L V6 DOHC - VIN (X) article in the ENGINE MECHANICAL section.

Scheme 18

Scheme 18

Note. For more information regarding jacking or hoisting the vehicle, refer to the JACKING & HOISTING article in the WHEEL ALIGNMENT section.

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

WHEEL & TIRE SPECIFICATIONS

Information regarding wheels and tires can be found on the decal attached to either the inside of the trunk lid or on the rear of the driver's door.

WHEEL TIGHTENING

Tighten all standard wheel lug nuts to 100 ft. lbs. (136 N.m). Compact spare is tightened to 80 ft. lbs. (108 N.m).

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See the COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM

Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.

The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.

When performing maintenance on air bag equipped vehicles always observe proper safety precautions.

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section.
CAUTIONDisconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation

ANTI-LOCK BRAKE SYSTEM (ABS)

CAUTIONNever mix different diameter tires. On loose or uneven surfaces, the ABS system may require longer stopping distances than conventional brake systems. Exercise caution when removing mud or snow from the wheels so as not to damage the ABS wiring or speed sensors.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below.

REPLACING BLOWN FUSES

Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

CAUTIONContinued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

CAUTIONTo avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C); Ethylene-Glycol -35° F (-37°C) - 263° F (128°C).
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

ENGINE OIL

CAUTIONNever use non-detergent or straight mineral oil.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component (fuel injection models).

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

SPARK PLUGS

Note. Allow engine to cool before removing spark plugs from aluminum cylinder heads.

WARRANTY INFORMATION

CAUTIONDue to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options.

BUMPER-TO-BUMPER PLUS COVERAGE LIMITED WARRANTY

Everything covered for 3 years or 50,000 miles, whichever occurs first. Covered by this warranty are any repairs to vehicle which have proven defective during material and workmanship in normal use (tires excluded). Warranty repairs (parts and labor) will be made by the Dealer at no charge using new or remanufactured parts by the Dealer. This warranty is subject to a 100 deductible for each repair visit after the first year or 12,000 miles, whichever occurs first. Maintenance items are covered up to their first scheduled replacement interval only.

Note. 1992-93 vehicles are covered for 3 years or 36,000 miles with no deductible.

SUPPLEMENTAL INFLATABLE RESTRAINT COVERAGE

Covers supplemental restraint system (if equipped) for 3 years, regardless of mileage.

CORROSION COVERAGE

Any body sheet-metal panel that is perforated due to corrosion is covered for 6 years or 100,000 miles, whichever occurs first.

EMISSIONS "DEFECT" & "PERFORMANCE" WARRANTIES (EXCEPT CALIFORNIA)

Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.

The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a federally required state or local emissions test.

Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.

EMISSION "PERFORMANCE" WARRANTY (CALIFORNIA)

If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

EMISSION "DEFECT" WARRANTY (CALIFORNIA)

If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.

FUSES & CIRCUIT BREAKERS

The fuse box is located behind a panel in the glove box. The electrical centers are located under the hood. For fuse identification of models and years not shown, refer to Fuse Usage chart on fuse panel cover.

Scheme 19

Scheme 19: FUSE PANEL IDENTIFICATION (1988 CUTLASS SUPREME)

Fuse & Circuit Breaker Identification

  1. 1 - 5 Amp Instrument Panel Lights, Reminder Lights
  2. 2 - 20 Amp Choke Heater
  3. 3 - Blank
  4. 4 - Blank
  5. 5 - 25 Amp Heater/Air Conditioner, Cruise Control
  6. 6 - 3 Amp Computer Command Control, SERVICE ENGINE SOON Light
  7. 7 - 10 Amp Computer Command Control
  8. 8 - 25 Amp Wiper/Washer
  9. 9 - 20 Amp Stoplights/Hazard Flashers, Computer Command Control, Trailer Adapter
  10. 10 - 20 Amp Computer Command Control, Charging System, Cruise Control, Gauges, Indicator Lights, Rear Defogger, Pulse Wiper, Torque Converter Clutch
  11. 11 - 20 Amp Outside Lights, Clock, Underhood Light, Music System, Lighter Trailer Adapter, Reminder Lights, Glove Box Light
  12. 12 - 10 Amp Music System, Power Antenna
  13. 13 - 20 Amp Back-Up Lights, Turn Signals
  14. 14 - 20 Amp Clock, Key Reminder, Chimes, Power Antenna
  15. 15 - 20 Amp Clock, Console, Dome Light, Inside Light, Power Door Locks
  16. 16 - Blank
  17. 17 - Blank

Scheme 20

Scheme 20: FUSE PANEL IDENTIFICATION (1989-90 CUTLASS SUPREME)
  1. 1 - 5 Amp Instrument Panel Lights, Reminder Lights
  2. 2 - 20 Amp Choke Heater
  3. 3 - Blank
  4. 4 - Blank
  5. 5 - 25 Amp Heater/Air Conditioner, Cruise Control
  6. 6 - 3 Amp Computer Command Control, SERVICE ENGINE SOON Light
  7. 7 - 10 Amp Computer Command Control
  8. 8 - 25 Amp Wiper/Washer
  9. 9 - 20 Amp Stoplights/Hazard Flashers, Computer Command Control, Trailer Adapter
  10. 10 - 20 Amp Computer Command Control, Charging System, Cruise Control, Gauges, Indicator Lights, Rear Defogger, Pulse Wiper, Torque Converter Clutch
  11. 11 - 20 Amp Outside Lights, Clock, Underhood Light, Music System, Lighter Trailer Adapter, Reminder Lights, Glove Box Light
  12. 12 - 10 Amp Music System, Power Antenna
  13. 13 - 20 Amp Back-Up Lights, Turn Signals
  14. 14 - 20 Amp Clock, Key Reminder, Chimes, Power Antenna
  15. 15 - 20 Amp Clock, Console, Dome Light, Inside Light, Power Door Locks
  16. 16 - Blank
  17. 17 - Blank
  1. 1 - 10 Amp Redundant Steering Wheel Control, Radio, Power Antenna
  2. 2 - 15 Amp Driver Info. System Memory, Radio, Clock, Trip Odometer
  3. 3 - 15 Amp Horn
  4. 4 - 25 Amp Wiper/Washer
  5. 5 - 10 Amp Instrument Cluster, Speedometer/Odometer, TCC, Rear Defogger
  6. 6 - 15 Amp Courtesy Lights, Power Locks, Cigarette Lighter
  7. 7 - 15 Amp ECM
  8. 8 - 10 Amp Turn Signals
  9. 9 - 15 Amp Stoplights/Hazard Flashers, Chime Module
  10. 10 - 10 Amp Instrument Cluster, HVAC Controls, Cruise Control, Driver Info. System
  11. 11 - 5 Amp Panel Lights, Switch Backlighting
  12. 12 - 10 Amp Music System, Power Antenna, Anti-Lock Brakes
  13. 13 - 20 Amp Back-Up Lights, Turn Signals, Park/Taillights, Foglight Relay
  14. 14 - Blank
  15. 15 - 20 Amp Clock, Console, Dome Light, Inside Light, Power Door Locks, HVAC Blower Motor
  16. 16 - 10 Amp Passive Restraint Belts
  17. 17 - Blank
  18. 18 - 10 Amp HVAC Controls

Scheme 21

Scheme 21: FUSE PANEL IDENTIFICATION (1992-93 CUTLASS SUPREME)
  1. 1 - 10 Amp Radio, Clock
  2. 2 - 15 Amp Radio, Clock, Passive Restraint, Lockout, Passive Restraint Timer, DID, Cluster
  3. 3 - 15 Amp Door Lock, Courtesy/Glove Box/Underhood/Trunk/Header Lights, Cigarette Lighter, Lighted Inside Rearview Mirror, Outside Power Mirrors
  4. 4 - 25 Amp Windshield Wiper/Washer
  5. 5 - 10 Amp Temp Door Motor, DRL Module, Instrument Cluster, HUD Dimmer, HUD Module
  6. 6 - 15 Amp Brakelights, ABS Control Module, Chime Module
  7. 7 - 15 Amp ECM
  8. 8 - 20 Amp Taillights, HVAC, Chime Module, DRL Module
  9. 9 - 15 Amp Hazard Warning Flasher
  10. 10 - 10 Amp Rear Defogger Timer Relay, Instrument Cluster, Chime Module, Cruise Control, DRL Module, Light Driver Module, ABS Light Driver
  11. 11 - 5 Amp Instrument Panel Console, Switch Lights
  12. 12 - 25 Blower Motor
  13. 13 - 10 Amp Turn Signals/Flasher, Computer Center
  14. 14 - Not Used
  15. 15 - 10 Amp ABS Control Module
  16. 16 - Not Used
  17. 17 - Not Used
  18. 18 - Not Used

Scheme 22

Scheme 22: FUSE PANEL IDENTIFICATION (1994-96 CUTLASS SUPREME)
  1. 1 - 10 Amp Radio, Clock, Steering Wheel Radio Switches
  2. 2 - 10 Amp Headlight Sw., Air Bag Diagnostic Module, ABS Lamp Driver Module, Daytime Running Lights Module (w/DRL), TCC/Brake Sw., Cruise Control Cut-Out Sw., Instrument Cluster, Chime Module, Rear Defogger Timer Relay
  3. 3 - 20 Amp A/C HI Blower Relay
  4. 4 - 25 Amp Windshield Wiper/Washer
  5. 5 - 10 Amp Turn Signal Flasher
  6. 6 - 15 Amp TCC/Brake Sw., Hazard Flasher
  7. 7 - 10 Amp (Cutlass Supreme) Courtesy, Glove Box, Underhood, Trunk, Header Lights: Lighted Inside Rearview Mirror
  8. 8 - 15 Amp Air Bag Diagnostic Module
  9. 9 - 20 Amp Power Door Locks, Remote Keyless Entry System
  10. 10 - 15 Amp Cigar Lighter
  11. 11 - 5 Amp Theft Deterrent Decoder Module
  12. 12 - 15 Amp Heater, Vent, A/C Solenoid Box, A/C LO Blower
  13. 13 - 15 Amp Chime Module, Electronic Brake Control Module, Theft Deterrent Decoder Module, Radio, Passive Restraint Timer Relay, Low Oil Level Module
  14. 14 - 15 Amp Air Temp. Valve Motors, Instrument Cluster, Daytime Running Lights Module (w/DRL), HVAC Control Assembly, Multi-Function Lever, Heated O2 Sens. #2, Passenger Temp. Control
  15. 15 - 5 Amp Elecronic Brake Control Module, Underhood Electrical Center 2, ABS Relay
  16. 16 - 10 Amp Antenna Relay, Outside Mirror Control, Front Window/Door Lock Switches, Front Door Handle Switches
  17. 17 - Not Used
  18. 18 - 5 Amp Air Bag Diagnostic Module

Scheme 23

Scheme 23: DRIVER-SIDE UNDERHOOD ELECTRICAL CENTER ID (TYPICAL 1988-93)
  1. 1 - Not Used
  2. 2 - Not Used
  3. 3 - Not Used
  4. 4 - Not Used
  5. 5 - Not Used
  6. 6 - Not Used
  7. 7 - Not Used
  8. 8 - 5 Amp ABS Control Module
  9. 9 - 15 Amp Foglights
  10. 10 - 10 Amp Horn
  11. 11 - Not Used
  12. 12 - Not Used
  13. 13 - 60 Amp ABS Controller
  14. 14 - 50 Amp Exterior Lights
  15. 15 - Relay Horn
  16. 16 - Relay Foglights
  17. 17 - Relay ABS

Scheme 24

Scheme 24: DRIVER-SIDE UNDERHOOD ELECTRICAL CENTER ID (TYPICAL)

Fuse & Relay Identification

  1. 1 - Not Used
  2. 2 - Not Used
  3. 3 - Not Used
  4. 4 - 10 Amp FOG LPS
  5. 5 - 25 Amp PARK LPS - Headlight Sw.
  6. 6 - 15 Amp HORN - HORN Relay, Underhood Light
  7. 7 - Not Used
  8. 8 - Not Used
  9. 9 - Not Used
  10. 10 - 40 Amp IGN SW2 - I/P Fuse Block: PWR WDO and Circuit Breaker "D"; Passenger Side Underhood Electrical Center: TCC and ENG EMIS Fuses
  11. 11 - 40 Amp IGN SW1 - I/P Fuse Block: Radio, Wiper HVAC, ABS & Turn Signal Fuses; Passenger Side Underhood Electrical Center: F/IJN, ECM IGN and ELEK IGN Fuses
  12. 12 - 30 Amp HD LPS - 30 amp Circuit Breaker to Headlight Sw.
  13. 13 - 60 Amp ABS - ABS Relay
  14. 14 - Relay ABS - Anti Lock Brake System
  15. 15 - Relay FOG LPS
  16. 16 - Relay HORN

Scheme 25

Scheme 25: PASSENGER-SIDE UNDERHOOD ELECT. CENTER ID (TYPICAL 1988-93)
  1. 1 - 20 Amp AIR Pump (3.4L Manual)
  2. 2 - 15 Amp Trunk Release, Back-Up Lights (1993)
  3. 3 - 20 Amp ECM, Fuel Pump
  4. 4 - Not Used
  5. 5 - Not Used
  6. 6 - Not Used
  7. 7 - 10 Amp Direct Ignition System
  8. 8 - 10 Amp Fuel Injectors Not Used Cutlass Supreme
  9. 9 - Not Used
  10. 10 - 15 Amp Ignition, Back-Up Lights, A/C Coil, Secondary Cooling Fan, Generator, Digital EGR, Purge Canister, Back-Up Lights
  11. 11 - 10 Amp TCC, AIR Pump (3.4L Manual), Primary Cooling Fan (3.1L)
  12. 12 - Relay Fuel Pump
  13. 13 - Relay AIR Pump (3.4L)
  14. 14 - Relay Secondary Cooling Fan
  15. 15 - Relay Primary Cooling Fan
  16. 16 - Relay A/C Clutch Coil
  17. 17 - 60 Amp Starter Solenoid
  18. 18 - 60 Amp Cooling Fan
  19. 19 - 60 Amp Blower Motor
  20. 20 - 60 Amp Cooling Fan
  21. 21 - 30 Amp Fuse Block

Scheme 26

Scheme 26: PASSENGER-SIDE UNDERHOOD ELECT. CENTER ID (TYPICAL)
  1. 1 - Not Used
  2. 2 - 15 Amp R/CMPT REL - Remote Trunk Release
  3. 3 - 20 Amp ECM BAT - Powertrain Control Module (PCM), Fuel Pump/Oil Press. Sw., Fuel Pump Relay, Fan Cont #1 Relay
  4. 4 - 15 Amp TCC - Automatic Transaxle, Transaxle Range Sw. (w/VIN M only)
  5. 5 - 15 Amp ENG EMIS - Generator, Digital Exhaust Recirculation (DERG) Valve, Evaporative Emissions (EVAP) Canister Purge Valve Solenoid, Heated O2 Sens., Fan Cont #2 Relay, A/C CMPR Relay VIN M only)
  6. 6 - 15 Amp (3.4L VIN X) CRUISE - Cruise Control Module, A/C CMPR Relay
  7. 7 - 15 Amp F/INJN - Fuel Injectors, High Resolution 24X Crankshaft Position Sensor, Camshaft Position Sensor
  8. 8 - 15 Amp (3.4L VIN X) ECM IGN - Powertrain Control Module (PCM), Mass Air Flow MAF) Sensor
  9. 9 - 15 Amp ELEK IGN - Electronic Ignition (EI) Control Module
  10. 10 - 60 Amp I/P Fuse Block
  11. 11 - 60 Amp FAN CONT #1 Relay
  12. 12 - 60 Amp Pasenger Side Underhood Electrical Center & I/P Fuse Block: Fuses 5, 14, 23 and 32
  13. 13 - 60 Amp FAN CONT #2 Relay & I/P Fuse Block: Fuse 16, Power Seat Circuit Breaker "D"
  14. 14 - Relay FUEL PUMP
  15. 15 - Relay A/C CMPR
  16. 16 - Relay FAN CONT #2 - Secondary Cooling Fan (Passenger Side)
  17. 17 - Relay FAN CONT #1 - Primary Cooling Fan (Driver Side)
  18. 18 - Not Used

Scheme 27

Scheme 27: FORWARD LIGHT ELECTRICAL CENTER IDENTIFICATION

Relay Identification

  1. 1 - Foglight Relay Fuse (15 Amp)
  2. 2 - Foglight Relay
  3. 3 - Horn Relay
  4. 4 - Park/Turn Module

Scheme 28

Scheme 28: ANTI-LOCK BRAKE POWER CENTER IDENTIFICATION
  1. 1 - Front Enable Relay
  2. 2 - Rear Enable Relay
  3. 3 - Pump Motor Fusible Element (30 Amp)
  4. 4 - Electronic Brake Valve Fusible Element (30 Amp)
  5. 5 - Controller Fuse (10 Amp)
  6. 6 - Electronic Brake Valve Fuse (15 Amp)

Scheme 29

Scheme 29: COMPONENT CENTER IDENTIFICATION
  1. 1 - Defogger Timer Relay
  2. 2 - Air Conditioning Blower Relay
  3. 3 - Air Conditioning Blower Relay
  4. 4 - Rear Defogger Circuit Breaker (30 Amp)
  5. 5 - Power Accessories Circuit Breaker (30 Amp)
  6. 6 - Power Windows Circuit Breaker (30 Amp)
  7. 7 - Headlight Circuit Breaker (20 Amp)
  8. 8 - Blank
  9. 9 - Chime Module
  10. 10 - Hazard Flasher

See also:
• 3.4L V6 DOHC - VIN (X)
