Wiper System & Washer System: Specifications Oldsmobile Bravada III

Wiper/washer Systems 12 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Front Wiper Arm Nuts30 N.m22 lb ft
Front Wiper Motor Cover Screws3 N.m27 lb in
Rear Wiper Arm Nut20 N.m15 lb ft
Rear Wiper Arm Park Ramp Bolts9 N.m79 lb in
Rear Wiper Motor Bolts8 N.m71 lb in
Rear Wiper Motor Shaft Nut8 N.m71 lb in
Washer Solvent Container Assembly Nuts10 N.m89 lb in
Wiper Transmission Assembly Bolts8 N.m71 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Wiper/Washer System Schematics
Scheme 1: Wiper/Washer System Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: Wiper/Washer System Component Views
Scheme 5: Wiper/Washer System Component Views
CalloutComponent Name
1Windshield Washer Fluid Level Switch
2Headlamp Washer Fluid Pump
3Windshield Washer Fluid Pump
4Rear Window Washer Fluid Pump
5Air Cleaner Housing

Scheme 6

Scheme 6
Scheme 6
CalloutComponent Name
1Instrument Panel Harness
2Windshield Wiper Motor

Scheme 7

Scheme 7
Scheme 7
CalloutComponent Name
1Headliner Harness
2Inside Rearview Mirror
3Outside Moisture Sensor

Scheme 8

Scheme 8
Scheme 8
CalloutComponent Name
1Windshield Wiper Switch
2C201

Scheme 9

Scheme 9
Scheme 9
CalloutComponent Name
1Instrument Panel
2Headlamp Washer Switch

Scheme 10

Scheme 10
Scheme 10
CalloutComponent Name
1Rear Window Wiper/Washer Switch, Chevrolet
2Trim Panel

Scheme 11

Scheme 11
Scheme 11
CalloutComponent Name
1Trim Panel-GMC
2Trim Panel-Oldsmobile
3Rear Window Wiper/Washer Switch-Oldsmobile
4Rear Window Wiper/Washer Switch-GMC

Scheme 12

Scheme 12
Scheme 12
CalloutComponent Name
1Liftgate
2Rear Wiper Motor
