Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Brake Hose Bracket Retaining Bolts | 10 N.m | 89 lb in |
| Drive Axle Nut | 140 N.m | 103 lb ft |
| Lower Ball Joint Retaining Nuts | 110 N.m | 81 lb ft |
| Lower Control Arm Bracket Front Mounting Bolt | 260 N.m | 192 lb ft |
| Lower Control Arm Bracket Rear Mounting Bolt | 240 lb ft | 177 lb ft |
| Lower Control Arm to the Lower Control Arm Bracket Mounting Nuts | 110 N.m | 81 lb ft |
| Outer Tie Rod to the Steering Knuckle Retaining Nut | 45 N.m | 33 lb ft |
| Shock Absorber Retaining Nut | 45 N.m | 33 lb ft |
| Shock Module Upper Retaining Nuts | 45 N.m | 33 lb ft |
| Shock Module Yoke to the Lower Control Arm Retaining Nut | 110 N.m | 81 lb ft |
| Shock Module Yoke to the Shock Absorber Pinch Bolt | 70 N.m | 52 lb ft |
| Stabilizer Shaft Insulator Clamp Mounting Bolts | 55 N.m | 41 lb ft |
| Stabilizer Shaft Link Retaining Nuts | 105 N.m | 77 lb ft |
| Upper Ball Joint Pinch Bolt | 40 N.m | 30 lb ft |
| Upper Control Arm Mounting Bolts | 150 N.m | 111 lb ft |
| Wheel Hub and Bearing Mounting Bolts | 105 N.m | 77 lb ft |
| Wheel Stud | 130 N.m | 95 lb ft |
| Wheel Speed Sensor to the Wheel Hub and Bearing Mounting Bolt | 18 N.m | 13 lb ft |
Fastener Tightening Specifications
Scheme 8
- Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/oldsmobile/bravada/iii-2001-2004/remont/hoistjack/#lifting-and-jacking-the-vehicle) in General Information.
- Remove the stabilizer shaft links to the stabilizer shaft retaining nuts. Refer to «Stabilizer Shaft Link Replacement»(ref-189862-S38474895312005091200000).
- Remove the stabilizer shaft insulator clamp mounting bolts.
- Remove the stabilizer shaft insulator clamp from the stabilizer shaft insulator.
- Remove the stabilizer shaft insulators from the stabilizer shaft.
- Remove the stabilizer shaft from the vehicle.
