Entertainment System: Overview Oldsmobile Bravada III

Entertainment Systems 27 illustrations ~490 words

Entertainment Schematic Icons

Entertainment Schematic Icons Icon Icon Definition CAUTION: This vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment Personal injury Unnecessary SIR system repairs In order to avoid the above conditions, observe the following guidelines: Refer to COMPONENT LOCATIONS in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM in SIR. IMPORTANT: Twisted-pair wires provide an effective "shield" that helps protect sensitive electronic components from electrical interference. If the wires were covered with shielding, install new shielding. In order to prevent electrical interference from degrading the performance of the connected components, you must maintain the proper specification when making any repairs to the twisted-pair wires shown : The wires must be twisted a minimum of 9 turns per 31 cm (12 in) as measured anywhere along the length of the wires. The outside diameter of the twisted wires must not exceed 6.0 mm (0.2 in)

Scheme 1

Scheme 1: Entertainment Schematic Icons
Scheme 1: Entertainment Schematic Icons

Scheme 2

Scheme 2: Radio/Audio System Schematics
Scheme 2: Radio/Audio System Schematics

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9: Voice Recorder Schematics
Scheme 9: Voice Recorder Schematics

Scheme 10

Scheme 10: Video System Schematics
Scheme 10: Video System Schematics

Scheme 11

Scheme 11: Entertainment Component Views
Scheme 11: Entertainment Component Views
CalloutComponent Name
1Cowl
2Radio Antenna Cable
3Hood Hinge Bracket

Scheme 12

Scheme 12
Scheme 12
CalloutComponent Name
1Radio Antenna Cable
2Air Distributor Duct
3Instrument Carrier Support

Scheme 13

Scheme 13
Scheme 13
CalloutComponent Name
1Overhead Console
2Voice Recorder
3C305

Scheme 14

Scheme 14
Scheme 14
CalloutComponent Name
1Instrument Panel (IP)
2Speaker-RF IP

Scheme 15

Scheme 15
Scheme 15
CalloutComponent Name
1Instrument Panel
2Body Harness
3C203, Body Harness
4C203, I/P Harness

Scheme 16

Scheme 16
Scheme 16
CalloutComponent Name
1HVAC Control Switch
2Radio Control Switch
3Driver Information Switch
4Driver Information Switch-Fuel/Trip

Scheme 17

Scheme 17
Scheme 17
CalloutComponent Name
1Instrument Panel
2Radio Antenna
3Radio
4Instrument Panel Harness

Scheme 18

Scheme 18
Scheme 18
CalloutComponent Name
1Cellular Microphone
2Noise Reduction Microphone
3Overhead Console

Scheme 19

Scheme 19
Scheme 19
CalloutComponent Name
1DVD Display Screen
2Overhead Console

Scheme 20

Scheme 20
Scheme 20
CalloutComponent Name
1Headliner Harness
2Diversity Antenna
3A-Pillar

Scheme 21

Scheme 21
Scheme 21
CalloutComponent Name
1Door-LF
2Speaker-LF Door

Scheme 22

Scheme 22
Scheme 22
CalloutComponent Name
1Rear Seat Audio (RSA)

Scheme 23

Scheme 23
Scheme 23
CalloutComponent Name
1Door-LR
2Speaker-LR Door

Scheme 24

Scheme 24
Scheme 24
CalloutComponent Name
1Body Side Inner Lower Panel-Right
2Audio Amplifier

Scheme 25

Scheme 25
Scheme 25
CalloutComponent Name
1Audio Amplifier
2Body Side Inner Panel-Left

Scheme 26

Scheme 26
Scheme 26
CalloutComponent Name
1Headliner
2Radio Antenna Module

Scheme 27

Scheme 27
Scheme 27
CalloutComponent Name
1Headliner
2Radio Antenna Buffer

Test Description

The numbers below Refer to the step numbers on the diagnostic table.

  1. 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
  2. 5: The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.
StepActionYesNo
1Install a scan tool. Turn ON the ignition, with the engine OFF. Does the scan tool power up?Go to Step 2Go to SCAN TOOL DOES NOT POWER UP in Data Link Communications
2Attempt to establish communication with the following: Radio Amplifier Body control module (BCM) Auxiliary HVAC control module Does the scan tool communicate with the radio, amplifier, BCM, and auxiliary HVAC control module?Go to Step 3Go to SCAN TOOL DOES NOT COMMUNICATE WITH CLASS 2 D in Data Link Communications
3IMPORTANT: The engine may start during the following step. Turn OFF the engine as soon as you have observed the Crank power mode. Access the Class 2 Power Mode in the Diagnostic Circuit Check on the scan tool. Rotate the ignition switch through all positions while observing the ignition switch power mode parameter. Does the ignition switch parameter reading match the ignition switch position for all switch positions?Go to Step 4Go to POWER MODE MISMATCH in Body Control System
4Select the following display DTCs function on the scan tool: Radio Amplifier Body control module (BCM) Auxiliary HVAC control module Does the scan tool display any DTCs?Go to Step 5Go to Symptoms - Entertainment
5Does the scan tool display any DTCs which begin with a "U"?Go to SCAN TOOL DOES NOT COMMUNICATE WITH CLASS 2 D in Data Link CommunicationsGo to Step 6
6Does the scan tool display DTC B1000?Go to Diagnostic Trouble Code (DTC) List in Body Control SystemGo to Step 7
7Does the scan tool display DTC B1327?Go to DIAGNOSTIC TROUBLE CODE (DTC) LISTGo to Diagnostic Trouble Code (DTC) List
IMPORTANT
The engine may start during the following step. Turn OFF the engine as soon as you have observed the Crank power mode.

Diagnostic System Check - Entertainment System

The number below Refer to the step number on the diagnostic table.

  1. 2: This step verifies that the steering wheel convenience switch is stuck. The convenience switches operate in the 123-247 count range. The value given is the normal condition that exists when no switch is activated.
StepActionValue(s)YesNo
Schematic Reference: Radio/Audio System Schematics
1Did you perform the Diagnostic System Check - Entertainment System?Go to Step 2Go to Diagnostic System Check - Entertainment System
2Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, observe the Steering Wheel Controls parameter in the TBC data list. Does the Steering Wheel Controls parameter indicate the specified range?0-7 CountsGo to Diagnostic AidsGo to Step 3
3Replace the steering wheel control switch. Refer to STEERING WHEEL CONTROL SWITCH ASSEMBLY in Steering Wheel and Column. Did you complete the replacement?Go to Step 4
4Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset?Go to Step 2System OK

DTC B2815

Symptoms - Entertainment

IMPORTANTPerform the Diagnostic System Check - Entertainment System before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link. Review the system operation in order to familiarize yourself with the system functions. Refer to : Radio/Audio System Description and Operation Video Entertainment System Description and Operation

Radio/Audio System Description and Operation

The entertainment system on this vehicle is configured with a radio, antenna, and speakers.

The following list shows the radios available for this vehicle

  1. Radio (UN0) - AM/FM, CD
  2. Radio (UP0) - AM/FM, Cassette and CD
  3. Radio (UC6) - AM/FM, Integral Multi Disc CD Changer
ControlsAll Radios
PowerPush the PWR/PUSH/VOL knob to turn the radio on.
VolumeThe volume is adjusted by rotating the PWR/PUSH/VOL knob.
Automatic Volume ControlPress the AUTOVOL button.
TuneTurn the TUNE/SELECT/PUSH RCL knob.
SeekMomentarily press the SEEK/SCAN button.
ScanHold the SEEK/SCAN button at least 4 seconds.
Presets6 AM, 6 FM1 and 6 FM2
Preset SavingPress and hold the desired button until an audible beep is heard.
Set ClockPress and hold the HR or MN button until an audible beep indicates the time set mode has been entered. Once the beep is heard, the time can be set by tapping each button to incrementally adjust the time. Holding down each button will rapidly change the time.
RecallPush the TUNE/SELECT/PUSH RCL knob.
Fade or BalancePress the BAL/FADE button to select and adjust w/SELECT knob.
Bass, Treble or MidrangePress the TONE button to select and adjust w/SELECT knob.
Automatic TonePress the AUTO TONE button.

Radio Features

ControlsUP0 Radio
EjectEJECT button
Fast ForwardPreset button 1
ReversePreset button 4
Auto ReverseYes
SidePreset button 5
PreviousPreset button 1
NextPreset button 2
DolbyPreset button 6
RepeatNA

Cassette Features

ControlsUN0 RadioUP0 RadioUC6 Radio
EjectEJECT button
Fast ForwardPreset button 1
ReversePreset button 4
DiscPreset button 5
PreviousPreset button 1
NextPreset button 2
DolbyPreset button 6
RepeatNA
RandomPreset button 6

Compact Disc Features

Each item in the list below represents topics covered in detail below.

  1. AM/FM Reception
  2. Diversity Antenna System
  3. Audio Amplifier
  4. Theft Deterrent
  5. Integral Multi Disc CD Changer (IMDX)
  6. Remote Playback Device
  7. Radio Data System (RDS)
  8. Tape/CD Player Error Messages
  9. Rear Seat Audio (RSA)
