Electronic Suspension System - Automatic Level Control: Specifications Oldsmobile Bravada III

Electronic Suspension 6 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Air Spring Compressor to Frame Mounting Bolts20 N.m15 lb ft
Air Spring Leveling Sensor to Frame Mounting Bolts8 N.m71 lb in
Air Supply Lines to Air Spring Compressor2.25 N.m20 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Suspension Controls Schematics
Scheme 1: Suspension Controls Schematics

Scheme 2

Scheme 2: Suspension Controls Component Views
Scheme 2: Suspension Controls Component Views
CalloutComponent Name
1Air Suspension Sensor, RR
2Upper Control Arm, RR
3Frame

Scheme 3

Scheme 3
Scheme 3
CalloutComponent Name
1Wiring, Switch-to-Compressor
2Wire Harness Connector
3Frame
4Air Suspension Compressor
5Rear Floor Panel

Scheme 4

Scheme 4
Scheme 4
CalloutComponent Name
1Lower Trim Panel
2Air Suspension Inflator Switch

Scheme 5

Scheme 5
Scheme 5
CalloutComponent Name
1Lower Side Trim Panel
2Indicator

Scheme 6

Scheme 6
Scheme 6
CalloutComponent Name
1Air Suspension Compressor
2Frame
3Wiring, Compressor-to-Switch
4Rear Floor Panel
