4wd circuit, with auto trac for Oldsmobile Bravada II (1995-2001)

11 13 1049 241 CLASS II DATA IGN 3 ATC FUSE BARE BARE BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE BODY RELAY BLOCK (BEHIND LEFT SIDE OF DASH) BRN WIRE CLASS II SERIAL DATA IGN 3 (RUN) DK GRN WIRE DK GRN/WHT WIRE FT SHAFT SPEED SIG FT SHAFT SPEED RTN FUSE 15 GAUGES FUSE 4 GRY WIRE HOT AT ALL TIMES HOT IN HOT IN RUN OR START I/P FUSE BLOCK (ON LEFT END OF DASH) INSTRUMENT CLUSTER LT BLU WIRE MODULE GND MOTOR/MODULE PWR GND MOTOR FEED B MOTOR FEED A NCA WIRE ORG/ WIRE PNK WIRE PPL PPL DATA LINK CONNECTOR (DLC) (PARTIAL) (UNDER LEFT SIDE OF DASH) RED WIRE RR SHAFT SPEED SIG RR SHAFT SPEED RTN RUN WIRE SERVICE SOLID STATE SPLICE PACK TRANSFER CASE ENCODER MOTOR (ON TRANSFER CASE, BELOW SPEED SENSOR) TRANSFER CASE FRONT PROPSHAFT SPEED SENSOR TRANSFER CASE REAR PROPSHAFT SPEED SENSOR TRANSFER CASE SHIFT CONTROL MODULE (BEHIND RIGHT FRONT KICK PANEL) UNDERHOOD FUSE BLOCK UNDERHOOD FUSE BLOCK (ON TOP OF LEFT FRONT FENDER) VEHICLE CONTROL MODULE (VCM) (RIGHT FRONT OF ENGINE COMPT) YEL WIRE
