Wiring diagram: Air conditioning — Automatic a/c circuit Oldsmobile Bravada II

Components on these wiring diagrams 31

Click a component to highlight it on every diagram it appears on.

• 5 Volt Ref
• 6 5 Solid State
• 7 9 Gnd
• A/C Comp Rly Ctrl A/C Request Sig A/C Cycling Sw Sig 25 30
• A/C Compres- Sor Clutch
• A/C Compres- Sor Clutch Diode
• A/C Compressor Clutch Relay
• A/C Compressor High Pressure Switch
• A/C Compressor Pressure Cycling Switch
• A/C Fuse
• A/C Heater Defrost
• A/C Request Sensor Gnd Electric Sensor Rtn 552 1791
• Air Temperature Valve Sensor, Motor
• Blower Motor
• Class 2
• Data Link Connector
• Electronic Climate Control Module
• Heater/ Defrost
• Hvac Solenoid
• Ign E Fuse
• Ignition Illumination
• Inside Air Temperature Sensor
• Inside Temp Sens Sig Outside Temp Sens Sig
• Lower Discharge Air Temperature Sensor
• Outside Air Temperature Sensor
• Rdo Batt Fuse 19
• Rr Defog Mode 4 Drv Mode 2 Drv
• Sun Load Temp Sens Upper Disc Temp Sens Lower Disc Temp Sens Elec Actuator Fbck
• Sunload Sensor
• Underhood Fuse Block
• Vehicle Control Module
