PCM Harness Resistance
Turn ignition switch to LOCK position. Disconnect PCM and appropriate component harness connectors. Check for open or short circuits between appropriate PCM harness connector terminal and appropriate component harness connector terminal. See POWERTRAIN CONTROL MODULE (PCM) table. See WIRING DIAGRAMS. If harness is open or shorted, repair as necessary.
Scheme 6
| Connector | Terminal | Wire Color | Function |
|---|---|---|---|
| C1 | 1 & 2 | ***** | Not Used |
| C1 | 3 | BRN/WHT | CMP 1x Signal |
| C1 | 4-6 | ***** | Not Used |
| C1 | 7 | TAN | HO2S Bank 2 Sensor 1 Low |
| C1 | 8 | PNK/BLK | CMP Sensor Ground |
| C1 | 9 | PPL | Fuel Level Output |
| C1 | 10 | TAN/BLK | TCC Solenoid Control |
| C1 | 11 & 12 | ***** | Not Used |
| C1 | 13 | WHT | 3-2 Shift Solenoid Control |
| C1 | 14 | ***** | Not Used |
| C1 | 15 | YEL/BLK | VSS Output Signal (EBCM) |
| C1 | 16-18 | ***** | Not Used |
| C1 | 19 | PPL/WHT | HO2S Bank 1 Sensor 1 Signal |
| C1 | 20 | ***** | Not Used |
| C1 | 21 | PPL | HO2S Bank 2 Sensor 1 Signal |
| C1 | 22 | PPL/WHT | HO2S Bank 1 Sensor 3 Signal |
| C1 | 23 & 24 | ***** | Not Used |
| C1 | 25 | TAN/WHT | HO2S Bank 1 Sensor 1 Low |
| C1 | 26 | TAN/WHT | HO2S Bank 1 Sensor 3 Low |
| C1 | 27 | ***** | Not Used |
| C1 | 28 | PPL | CKP Sensor Ground |
| C1 | 29 | LT GRN/BLK | VSS Low |
| C1 | 30 | PPL/WHT | VSS High |
| C1 | 31 | YEL | CKP 3X Sensor Signal |
| C1 | 32 | ***** | Not Used |
| C2 | 1 | ***** | Not Used |
| C2 | 2 | WHT | EVAP Canister Vent Solenoid Control |
| C2 | 3 | ***** | Not Used |
| C2 | 4 | YEL/BLK | 2-3 Shift Solenoid Control |
| C2 | 5 | ***** | Not Used |
| C2 | 6 | LT GRN | 1-2 Shift Solenoid Control |
| C2 | 7 | BRN | TCC PWM Solenoid Control |
| C2 | 8 | BLK | Fuel Injector No. 1 Control |
| C2 | 9 | YEL/BLK | Fuel Injector No. 6 Control |
| C2 | 10 | BRN | EGR Pintle Position Signal |
| C2 | 11 & 12 | ***** | Not Used |
| C2 | 13 | LT GRN/WHT | IAC Coil B High |
| C2 | 14 | LT BLU/WHT | IAC Coil A High |
| C2 | 15 | LT GRN/BLK | Fuel Injector No. 2 Control |
| C2 | 16 | PNK/BLK | Fuel Injector No. 3 Control |
| C2 | 17 & 18 | ***** | Not Used |
| C2 | 19 | DK BLU | KS Signal |
| C2 | 20 | WHT | Tachometer Output |
| C2 | 21 | LT GRN | MAP Sensor Signal |
| C2 | 22 | TAN | IAT Sensor Signal |
| C2 | 23 | YEL | ECT Sensor Signal |
| C2 | 24 | DK BLU | TP Sensor Signal |
| C2 | 25 | DK GRN | Fuel Tank Pressure Sensor Signal |
| C2 | 26 | ***** | Not Used |
| C2 | 27 | YEL/BLK | TFT Sensor Signal |
| C2 | 28 | YEL | MAF Sensor Signal |
| C2 | 29 | LT GRN/BLK | IAC Coil B Low |
| C2 | 30 | LT BLU/BLK | IAC Coil A Low |
| C2 | 31 | BLK/WHT | Fuel Injector No. 5 Control |
| C2 | 32 | LT BLU/BLK | Fuel Injector No. 4 Control |
| C3 | 1 | DK GRN/WHT | A/C Compressor Enable Relay Control |
| C3 | 2 | DK GRN/WHT | EVAP Canister Purge Solenoid Control |
| C3 | 3 | ***** | Not Used |
| C3 | 4 | BLK | ECT/TP Sensor Ground |
| C3 | 5 | RED | Generator Control/ Monitoring |
| C3 | 6 | RED/BLK | Pressure Control Solenoid High |
| C3 | 7 & 8 | ***** | Not Used |
| C3 | 9 | WHT | IC Control |
| C3 | 10 | ***** | Not Used |
| C3 | 11 | RED | Transmission Range C Signal |
| C3 | 12 | GRY | TP Sensor Reference Voltage |
| C3 | 13 | PPL | Fuel Level Sensor Signal |
| C3 | 14 & 15 | ***** | Not Used |
| C3 | 16 | LT BLU/WHT | Pressure Control Solenoid Low |
| C3 | 17 | BLK/WHT | VCM Ground |
| C3 | 18 | BLK/WHT | VCM Ground |
| C3 | 19 | BLK | Sensor Ground (IAT/MAP/EGR/Fuel Tank Pressure) |
| C3 | 20 | ***** | Not Used |
| C3 | 21 | ORG | Battery Voltage |
| C3 | 22 | DK BLU | Transmission Range B Signal |
| C3 | 23 | PNK | Transmission Range A Signal |
| C3 | 24 | ***** | Not Used |
| C3 | 25 | GRN/WHT | A/C Request Signal |
| C3 | 26 | WHT | PRNDL P Signal |
| C3 | 27 | GRY | Reference Voltage |
| C3 | 28 | GRY | PRNDL C Signal |
| C3 | 29 | ***** | Not Used |
| C3 | 30 | GRN | A/C Pressure Signal |
| C3 | 31 | BLK/WHT | PRNDL A Signal |
| C3 | 32 | YEL | PRNDL B Signal |
| C4 | 1 | DK GRN/WHT | Fuel Pump Relay Control |
| C4 | 2 | ***** | Not Used |
| C4 | 3 | DK GRN/WHT | VSS Output Signal (TCCM, Cruise & TBC Modules) |
| C4 | 4 | BRN/WHT | VSS Output Signal (Speedometer) |
| C4 | 5 | BRN/WHT | MIL Control |
| C4 | 6-9 | ***** | Not Used |
| C4 | 10 | PPL | Brake Signal |
| C4 | 11 | PPL | Serial Data (Class I) |
| C4 | 12 | ***** | Not Used |
| C4 | 13 | BRN | Ignition Voltage |
| C4 | 14 | YEL | Serial Data (Class II) |
| C4 | 15 | ***** | Not Used |
| C4 | 16 | RED | EGR Valve Control |
| C4 | 17 | PNK | Ignition Voltage |
| C4 | 18 | PNK | Ignition Voltage |
| C4 | 19 | BLK/WHT | 4WD Front Wheel Lock Input |
| C4 | 20 | WHT | EGR Valve Low |
| C4 | 21 | ***** | Not Used |
| C4 | 22 | BRN/WHT | CPP Switch Signal |
| C4 | 23 | GRY/BLK | 4WD Low Signal |
| C4 | 24 | LT BLU/BLK | Cruise Engaged Signal |
| (1) (Scheme 6) | |||
| (1) | (Scheme 6) |
POWERTRAIN CONTROL MODULE (PCM) (1)
