COMPONENT LOCATIONS
Note. For component locations, refer to illustrations. see scheme 6- see scheme 8.
| Component | Location |
|---|---|
| A/C Clutch Relay | In Underhood Fuse Block. |
| Cruise Control Module | At Left Side Of Engine Compartment, On Strut Tower. (Scheme 32) |
| Dash Integration Module (DIM) | Behind Right Side Of Instrument Panel. (Scheme 33) |
| FOG LP Relay | In Underhood Fuse Block. |
| HDLP HI BM Relay | In Underhood Fuse Block. |
| HDLP LO BM Relay | In Underhood Fuse Block. |
| Horn Relay | In Underhood Fuse Block. see scheme 13 |
| RR FOG LP Relay | In Rear Fuse Block. |
| Turn Signal/Hazard Flasher Module | Behind Left Side Of Dash, Above Data Link Connector. |
