Maintenance Information: Overview Oldsmobile Aurora I

Procedures 3 illustrations ~620 words

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp Air Bag
  2. 2 - 10 Amp Injectors
  3. 3 - 10 Amp ABS System
  4. 4 - 10 Amp Left Exterior Lamps
  5. 5 - 15 Amp Turn Signal Lamps
  6. 6 - 10 Amp Injectors
  7. 7 - 10 Amp Climate Controls, Magnetic Speed
  8. 8 - 10 Amp Right Exterior Lamps
  9. 9 - 10 Amp Chime (Ignition 1), Memory Set
  10. 10 - 10 Amp Powertrain Control Module (PCM), Cruise Control, VATS PASS-Key II
  11. 11 - 15 Amp Auxiliary Power
  12. 12 - 10 Amp Interior Lamps
  13. 13 - 15 Amp Brake-Transaxle Shift Interlock, Heated Oxygen Sensor, Linear EGR
  14. 14 - 15 Amp Dirver Information Center
  15. 15 - 10 Amp Radio
  16. 16 - 10 Amp Climate Control Relay
  17. 17 - 25 Amp Windshield Wipers
  18. 18 - 25 Amp Cigarette Lighter
  19. 19 - 10 Amp Crank, Air Bag Module
  20. 20 - 10 Amp Climate Control Blower

Scheme 2

Scheme 2: MAXI-FUSE/RELAY CENTER IDENTIFICATION (ENGINE COMPARTMENT)
Scheme 2: MAXI-FUSE/RELAY CENTER IDENTIFICATION (ENGINE COMPARTMENT)

Fuse Identification

  1. 1 - 25 Amp Air Conditioning Compressor
  2. 2 - Not Used
  3. 3 - Not Used
  4. 4 - 20 Amp Horn
  5. 5 - Not Used
  6. 6 - Not Used
  7. 7 - Not Used Cooling Fan #2
  8. 8 - Not Used Cooling Fan #3
  9. 9 - Not Used Cooling Fan
  10. 10 - Not Used ABS Main
  11. 11 - Not Used ABS Pump Motor
  12. 12 - Not Used
  13. 13 - Not Used Horn
  14. 14 - Not Used Flash to Pass

Scheme 3

Scheme 3: FUSE & RELAY PANEL IDENTIFICATION (UNDER REAR SEAT)
Scheme 3: FUSE & RELAY PANEL IDENTIFICATION (UNDER REAR SEAT)

Fuse & Relay Identification

  1. 1 - Interior Lamp Relay
  2. 2 - Electronic Level Control Relay
  3. 3 - Trunk Release Relay
  4. 4 - Not Used
  5. 5 - Fuel Pump Relay
  6. 6 - Driver Door Unlock Relay
  7. 7 - Not Used
  8. 8 - Not Used
  9. 9 - Not Used
  10. 10 - Not Used
  11. 11 - Rear Window Defogger Relay (Lower Zone)
  12. 12 - Rear Window Defogger Realy (Upper Zone)
  13. 13 - Not Used
  14. 14 - 20 Amp Spare
  15. 15 - 40 Amp Spare
  16. 16 - 60 Amp Spare
  17. 17 - Not Used
  18. 18 - Not Used
  19. 19 - Not Used
  20. 20 - Not Used
  21. 21 - Not Used
  22. 22 - Not Used
  23. 23 - Direct Accessory Power - Accessory Relay
  24. 24 - Direct Accessory Power - Ignition Relay

Scheme 4

Scheme 4: FUSE PANEL IDENTIFICATION (UNDER REAR SEAT)
Scheme 4: FUSE PANEL IDENTIFICATION (UNDER REAR SEAT)
  1. 1 - 10 Amp Spare
  2. 2 - 10 Amp Spare
  3. 3 - Not Used
  4. 4 - 25 Amp Circuit Breaker Power Windows, Sunroof
  5. 5 - 15 Amp Spare
  6. 6 - 15 Amp Spare
  7. 7 - Not Used
  8. 8 - 20 Amp Spare
  9. 9 - 20 Amp Spare
  10. 10 - Not Used
  11. 11 - 25 Amp Circuit Breaker Power Seats
  12. 12 - 25 Amp Spare
  13. 13 - 25 Amp Spare
  14. 14 - Not Used Spare
  15. 15 - 50 Amp Power Seats
  16. 16 - 20 Amp Circuit Breaker Headlights
  17. 17 - 30 Amp HVAC Blower Motor
  18. 18 - 20 Amp Power Control Module, PASS-Key II
  19. 19 - 60 Amp Ignition 3
  20. 20 - 60 Amp Ignition 1
  21. 21 - 60 Amp Rear Defogger
  22. 22 - 40 Amp Trunk and Fuel Door Release
  23. 23 - 20 Amp Heated Seat
  24. 24 - 60 Amp Electronic Level Control, Instrument Panel
  25. 25 - 60 Amp Exterior Lamps
  26. 26 - 20 Amp Bose Stereo (If Equipped)
  27. 27 - 20 Amp Power Door Locks
  28. 28 - 15 Amp Interior Lamps
  29. 29 - 20 Amp Hazard Lights, Stop Lights
  30. 30 - 15 Amp Parking Lamps
  31. 31 - 10 Amp Heated Outside Mirror
  32. 32 - 15 Amp Back-up Lamps
  33. 33 - 20 Amp Fuel Door Release
  34. 34 - Not Used
  35. 35 - 10 Amp Battery Termistor
  36. 36 - 10 Amp Instrument Panel - Power Antenna, Remote CD Changer, Radio Chassis
  37. 37 - 10 Amp Instrument Panel - Remote Accessory Power Module, Oil Level Indicator, ALDL
  38. 38 - 20 Amp Electronic Level Control
  39. 39 - 15 Amp Fuel Pump
