ADJUSTMENTS
Note. While performing following procedures, perform rear wheel alignment first to ensure proper front alignment angles.
CAMBER ADJUSTMENT
To adjust front camber, loosen 2 strut-to-steering knuckle bolts. (Scheme 1) Move top of wheel in or out to obtain correct camber specification. While holding wheel in position, tighten 2 strut-to-steering knuckle bolts. Rear camber is not adjustable. If rear camber is not to specification, repair or replace damaged or worn suspension or body parts.
Scheme 1
CASTER ADJUSTMENT
Caster is not adjustable. If caster is not to specification, check for worn or damaged suspension or body parts. Repair or replace as necessary.
TOE-IN ADJUSTMENT (FRONT)
Loosen tie rod end lock nut. (Scheme 2) Loosen steering gear dust boot clamp(s) at tie rod end. Turn inner tie rod to obtain correct toe-in. Tighten lock nut to specification. See TORQUE SPECIFICATIONS. Ensure steering gear dust boot is straight after adjustment. Tighten dust boot clamp.
Scheme 2
TOE-IN ADJUSTMENT (REAR)
Rear toe-in is not adjustable. If rear toe-in is not to specification, repair or replace worn or damaged components.
| Application | Preferred | Range | |
|---|---|---|---|
| Camber (1) | |||
| Front | 0 | 0.7 To 0.7 | |
| Rear | 0.25 | 0.85 To 0.35 | |
| Caster (1) (2) | 1.45 | 0.45 To 2.45 | |
| Toe-In (1) | |||
| Front | 0 | 0.2 To 0.2 | |
| Rear | 0 | 0.35 To 0.35 | |
| Toe-In (3) | |||
| Front | 0 | 0.1 To 0.1 (-2.5 To 2.5) | |
| Rear | 0 | 0.17 To 0.17 (-4 To 4) | |
| (1) Measurement is in degrees. (2) Left-to-right caster differential must not exceed 1 1/2°. (3) Measurement is in inches (mm). | |||
| (1) | Measurement is in degrees. |
| (2) | Left-to-right caster differential must not exceed 1 1/2°. |
| (3) | Measurement is in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS
