Starter: Specifications Oldsmobile Achieva I

Starter 9 illustrations

TORQUE SPECIFICATIONS

Application		Ft. Lbs. (N.m)
Starter Mounting Bracket-To-Engine
2.0L		20 (27)
2.2L		24 (33)
Starter-To-Engine Mounting Bolts
2.0L		37 (50)
2.2L, 3.1L, 3.4L, 3.8L & 4.9L		32 (43)
2.3L		74 (100)
4.3L & 5.7L (VIN P)		35 (47)
4.6L		22 (30)
INCH Lbs. (N.m)
Flywheel Inspection Cover Bolts
3.4L VIN X		89 (10)

TORQUE SPECIFICATIONS

Fig. 13: Starter System Schematic (Eldorado, Seville & DeVille 4.6L)

Scheme 13: Starter System Schematic (Eldorado, Seville & DeVille 4.6L)

Fig. 14: Starter System Schematic (Cavalier)

Scheme 14: Starter System Schematic (Cavalier)

Fig. 15: Starter System Schematic (Sunbird)

Scheme 15: Starter System Schematic (Sunbird)

Fig. 16: Starter System Schematic (DeVille 4.9L)

Scheme 16: Starter System Schematic (DeVille 4.9L)

Fig. 17: Starter System Schematic (Beretta, Corsica)

Scheme 17: Starter System Schematic (Beretta, Corsica)

Fig. 18: Starter System Schematic (Achieva, Grand Am, Skylark)

Scheme 18: Starter System Schematic (Achieva, Grand Am, Skylark)

Fig. 19: Starter System Schematic (Cutlass Supreme & Regal)

Scheme 19: Starter System Schematic (Cutlass Supreme & Regal)

Fig. 20: Starter System Schematic (Grand Prix)

Scheme 20: Starter System Schematic (Grand Prix)

Fig. 21: Starter System Schematic (Lumina)

Scheme 21: Starter System Schematic (Lumina)
