Maintenance Information: Overview Oldsmobile Achieva I

Procedures 2 illustrations ~1019 words

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp Back-Up Lights, Instrument Panel
  2. 2 - 5 Amp Audible Warning/Chime, Interior Lights Dimming, Radio/Audio Systems, Rear Window Defogger, Ride Control
  3. 3 - 10 Amp Cruise Control, Radio/Audio Systems
  4. 4 - 25 Amp Windshield Wiper/Washer
  5. 5 - 20 Amp Multiport Fuel Injection
  6. 6 - 10 Amp Anti-Lock Brake, Audible Warnings/Chime, Brake Transaxle Shift Interlock (BTSI), Instrument Panel, Keyless Entry, Rear Window Defogger
  7. 7 - 20 Amp Turn Signals, Hazard Lights, Stoplights
  8. 8 - 20 Amp Automatic Door Locks, Cigarette Lighter, Instrument Panel, Interior Lights, Horn
  9. 9 - 10 Amp Radio/Audio Systems
  10. 10 - 15 Amp Audible Warnings/Chime, Interior Lights, Luggage Compartment Light, Power Mirrors
  11. 11 - 5 Amp Keyless Entry
  12. 12 - 25 Amp Anti-Lock Brake, Engine Vent Heater, Headlights, Daytime Running Lights, Heater, Ride Control
  13. 13 - 30 Amp Circuit Breaker Power Windows
  14. 14 - 30 Amp Circuit Breaker Automatic Door Locks, Keyless Entry, Power Antenna, Power Seats, Rear Window Defogger
  15. 15 - 20 Amp Circuit Breaker Headlights, Daytime Running Lights
  16. 16 - 20 Amp Headlights
  17. 17 - 20 Amp Exterior Lights
  18. 18 - 20 Amp Multiport Fuel Injection: Ignition
  19. 19 - 15 Amp HVAC, Multiport Fuel Injection, Starter & Charging System
  20. 20 - 20 Amp Exterior Lights

Scheme 1

Scheme 1: FUSE PANEL IDENTIFICATION (1994-96 SKYLARK)
Scheme 1: FUSE PANEL IDENTIFICATION (1994-96 SKYLARK)
  1. 1 - 5 Amp Electronic PRNDL Display
  2. 2 - 20 Amp Fuel Pump, Injectors
  3. 3 - 20 Amp Stop/Hazard Lamps
  4. 4 - 15 Amp Ctsy, Door Lock Switches, Power Mirrors, Cigar Lighter
  5. 5 - 3 Amp Air Bag, Supplemental Inflatable Restraint, Crank Input
  6. 6 - 5 Amp Instrument Panel, Interior Lights Dimming
  7. 7 - 10 Amp Gauges, Rear Defog, Warning Lights
  8. 8 - 15 Amp Horn
  9. 9 - 15 Amp Alarm, Interior Lights, Chime, Auto Door Locks, Remote Keyless Entry
  10. 10 - 25 Amp Heater, A/C, ABS, Daytime Running Lights (Canada)
  11. 11 - 10 Amp Radio Power, Cruise Control
  12. 12 - 20 Amp Turn Signals
  13. 13 - 20 Amp Auto Door Lock
  14. 14 - 20 Amp Tail Lamps, Marker Lamps, License Lamps
  15. 15 - 30 Amp Circuit Breaker Power Window, Sunroof
  16. 16 - 25 Amp Windshield Wipers/Washers
  17. 17 - 15 Amp Engine Controls, Back-Up Lamps
  18. 18 - 10 Amp Auto Door Unlock Disable
  19. 19 - 20 Amp Flash-To-Pass (U.S.A.)
  20. 20 - 30 Amp Circuit Breaker ACC, Rear Window Defogger, Power Seats, Power Antenna
  21. 21 - 15 Amp Air Bag, Supplemental Inflatable Restraint
  22. 22 - 20 Amp ECM, Ignition System
  23. 23 - 20 Amp Circuit Breaker Headlamps

Scheme 2

Scheme 2: FUSE PANEL IDENTIFICATION (1992-96 ACHIEVA)
Scheme 2: FUSE PANEL IDENTIFICATION (1992-96 ACHIEVA)
  1. 1 - 10 Amp (1992-93) Back-Up Lights, Electronic PRNDL
  2. 1 - 5 Amp (1994) Electronic PRNDL display (automatic transaxle)
  3. 2 - 20 Amp Fuel Pump, Fuel Injectors
  4. 3 - 20 Amp Stoplights, Hazard Flashers, ABS Lights (1992-93), Brake/Transaxle Shift Interlock (1993)
  5. 4 - 10 Amp (1992) Radio Clock & Memory 15 Amp (1993-94) Power Door Locks, Cigarette Lighter, Power Mirrors
  6. 5 - 5 Amp (1992-93) Remote Keyless Entry
  7. 5 - 3 Amp (1994) Supplemental Inflatable Restraint (Air Bag)
  8. 6 - 5 Amp Instrument Panel Lights
  9. 7 - 10 Amp Gauges, Rear Window Defogger Relay, Warning Light (1994), Key Buzzer (1992-93), ABS Telltale (1992-93), Brake Transaxle Shift Interlock (1992-93), DRL Module (1993 Canada)
  10. 8 - 20 Amp (1992) Cigarette Lighter, Power Door Lock Relay, 15 Amp (1993-96) Horn
  11. 9 - 15 Amp Chime, Interior Lights, Trunk Light (1992-93), Glove Box Light (1992-93), Passive Restraints (1992-93), Automatic Door Locks (1994-96), Remote Lock Control (1994-96)
  12. 10 - 25 Amp Heater, Air Conditioner, Anti-Lock Brake System, DRL Canada), Ride Control (1992-93), Block Heater (1993)
  13. 11 - 10 Amp Radio, Cruise Control, EVO Steering (1992-93)
  14. 12 - 20 Amp Turn Signals
  15. 13 - Blank (1992) 20 Amp (1993-96) Power/Auto. Door Locks
  16. 14 - 20 Amp Taillights, Side Marker Lights, License Lights, Foglights, Instrument Panel Lighting (1992)
  17. 15 - 30 Amp Circuit Breaker Power Window, Sunroof (1994-96)
  18. 16 - 25 Amp Windshield Wipers/Washers
  19. 17 - 15 Amp Engine Controls, Back-Up Lights (1994-96)
  20. 18 - Blank (1992-93)
  21. 18 - 10 Amp (1994-96) Automatic Door Unlock (Remove to Disable)
  22. 19 - 20 Amp Flash-to-Pass (U.S. only)
  23. 20 - 30 Amp Circuit Breaker Power Door Lock (1992), Rear Window Defogger, Power Seat, Power Antenna (1993-96)
  24. 21 - Blank (1992-93)
  25. 21 - 15 Amp Supplemental Inflatable Restraint (Air Bag)
  26. 22 - 20 Amp Engine Control Module, Ignition System
  27. 23 - Blank
  28. 24 - 20 Amp Circuit Breaker Headlights, DRL Module (1993 Canada)
  1. 1 - 10 Amp (1992-93) Back-Up Lights, Electronic PRNDL
  2. 1 - 5 Amp (1994-96) Electronic PRNDL
  3. 2 - 20 Amp Fuel Pump, Fuel Injectors
  4. 3 - 20 Amp Turn/Stoplights, Hazard Flashers, ABS Light (1993), Brake/Transaxle Shift Interlock, (1993)
  5. 4 - 10 Amp (1992) Radio Clock & Memory 15 Amp (1993-96) Power Mirrors/Door Locks, Cigarette Lighter
  6. 5 - Blank (1992-93)
  7. 5 - 3 Amp (1994-96) Supplemental Restraint System (Air Bag)
  8. 6 - 5 Amp Instrument Panel Lights
  9. 7 - 10 Amp Gauges, Rear Window Defogger Relay, Key Buzzer (1992-93), ABS Light (1992-93), Brake Transaxle Shift Interlock 1992-93), DRL Module (1993 Canada), Warning Lights (1994-96)
  10. 8 - 20 Amp (1992) Cigarette Lighter, Power Door Lock Relay, Horn 15 Amp (1993-96) Horn
  11. 9 - 15 Amp Chime, Interior Lights, Trunk Light (1992-93), Glove Box Light (1992-93), Passive Restraint (1992-93), Auto Door Locks 1994-96), Remote Keyless Entry (1994-96)
  12. 10 - 25 Amp Heater, Air Conditioning, Anti-Lock Brake System, DRL Canada), Engine Block Heater (1993)
  13. 11 - 10 Amp Radio, Cruise Control, EVO Steering (1992-93)
  14. 12 - 20 Amp Turn Signals
  15. 13 - Blank (1992) 20 Amp (1993-96) Power/Auto Door Locks
  16. 14 - 20 Amp Taillights, Side Marker Lights, License Lights, Foglights, Instrument Panel Lighting (1992-93)
  17. 15 - 30 Amp Circuit Breaker Power Window
  18. 16 - 25 Amp Windshield Wipers
  19. 17 - 15 Amp Engine Controls, Back-Up Lamps (1994-96)
  20. 18 - Blank (1992-93)
  21. 18 - 10 Amp (1994-96) Automatic Door Unlock (Remove To Disable)
  22. 19 - 20 Amp Flash-to-Pass (U.S. only)
  23. 20 - 30 Amp Circuit Breaker Power Door Locks, Rear Window Defogger, Antenna (1994-96)
  24. 21 - Blank (1992-93)
  25. 21 - 15 Amp (1994-96) Supplemental Restraint System (Air Bag)
  26. 22 - 20 Amp Ignition System, Engine Control Module
  27. 23 - Blank
  28. 24 - 20 Amp Circuit Breaker Headlights, DRL Module (1993 Canada)
